BONFIGLIOLI Vectron AEC Series Operating Instructions Manual page 82

No.
453 Error/Warning Behavior
454 Point X1
455 Point Y1
456 Point X2
457 Point Y2
510 Setting Frequency
517 Setting Frequency Off Delta
518 Minimum Reference Percentage
519 Maximum Reference Percentage
520 Fixed Percentage 1
530 Op. Mode Digital Output 1
535 Op. Mode ext. Error
540 Op. Mode Comparator 1
550 Operation Mode
551 Voltage 100%
552 Voltage 0%
553 Analog Operation
554 Digital Operation
652 Offset
653 Amplification
801 Reference DC-Link Voltage
802 Max. DC-Link Voltage Deviation
804 Max. Feed Current
805 Max. Feedback Current
810 Operation Mode
811 Relative Short-Circuit Voltage
82
Description
Digital Outputs
Percentage Value Limits
Digital Outputs
Multifunction output 1
PWM-/repetition frequency input
DC-link
Voltage controller
Filter compensation
Operating Instructions AEC
Unit Setting range
- Selection
% 0.00 ... 100.00
% -100.00 ... 100.00
% 0.00 ... 100.00
% -100.00 ... 100.00
Hz 0.00 ... 599.00
Hz 0.00 ... 599.00
% 0.00 ... 300.00
% 0.00 ... 300.00
% 0.00 ... 300.00
- Selection
- Selection
- Selection
- Selection
V 0.0 ... 24.0
V 0.0 ... 24.0
- Selection
- Selection
% -100.00 ... 100.00
% 5.0 ... 1000.0
V 0.0 ... Udmax
V 0.0 ... Udmax
A 0.0 ... Imax
A 0.0 ... Imax
- Selection
% 0.0 ... 30.0
