Key
CANopen
nn Heartbeat error, nn = triggering node.
F23
CM module identification
Unknown CM module. Verify compatibility of firmware and CM module
F24 00
EM module identification
Unknown EM module. Verify compatibility of firmware and EM module
F25 00
Industrial Ethernet
Industrial Ethernet error. Please note the instructions on the Ethernet module used.
F27 nn
User error VPLC
Internal PLC function error caused by the user. Please refer to VPLC user manual.
F30 3n
Optional components
Data transmission from control unit KP 500 to the frequency inverter not possible. At least one
F0A 10
file must be stored in the control unit.
The communication module was fitted to slot B without disconnection of the mains voltage,
F0B 13
switch mains voltage off.
Internal monitoring
This error is triggered after 6 warm starts in less than 3 minutes because there will probably be
F0C 40 an error in the programming in the PLC or the function table. In addition the function table will
be stopped (P.1399 = 0 in RAM only).

11.1.2 Output signals in the case of error messages

Errors are signaled via digital signals.
162 - 1)
Error Signal
3 - 2)
1) For linking to frequency inverter functions
In addition to fault messages mentioned, there are further fault messages. However these messages are
only used for internal purposes and are not listed here. If you receive fault messages which are not listed
here, please contact the BONFILGLIOLI customer service.
Please save the parameter file on your PC before.
11.2

Error environment

The parameters of the error environment help troubleshooting both in the settings of the frequency inverter
and also in the complete application. The error environment documents the operational behavior of the
frequency inverter at the time of the last four faults.
Error environment
No.
330 DC-Link Voltage
331 Output voltage
335 Phase Current Ia
336 Phase Current Ib
337 Phase Current Ic
11/17
A monitoring function reports an error displayed via Parameter
259.
2) For output via a digital output
Description Function
Direct voltage in DC-link.
Calculated output voltage (motor voltage) of the frequency
inverter.
Measured current in motor phase U.
Measured current in motor phase V.
Measured current in motor phase W.
Operating Instructions AEC
Meaning
Current Error
