Elite Screens Starling Tab-Tension 2 Series Replacement Instructions

Weight bar ca

Weight Bar Cap Replacement Instructions

for Starling Tab-Tension 2 Series

For technical support or further assistance, call 877-511-1211 x604

ATTENTION: Elite Screens does not recommend making unnecessary adjustments to the screen, as

improper adjustments will damage the unit and void your warranty.

1. Using a Philips head screw driver, remove the 2 screws securing the cap on the weight bar

Screw location

Cap on weight bar removed

2. Next, remove the U washer from the center rod by prying it out with a flat head screwdriver.

U washer

Updated 04/04/2017

www.elitescreens.com

Table of Contents

Do you have a question about the Starling Tab-Tension 2 Series and is the answer not in the manual?

Page 1 Starling Tab-Tension 2 Series For technical support or further assistance, call 877-511-1211 x604 ATTENTION: Elite Screens does not recommend making unnecessary adjustments to the screen, as improper adjustments will damage the unit and void your warranty. 1. Using a Philips head screw driver, remove the 2 screws securing the cap on the weight bar...
Page 2 6. A Lastly, untie the knot that tightens the string to the knob. This will then allow for you to pull out the broken weight bar cap. 7. To install the new cap, simply follow these instructions in reverse order. For a local Elite Screens contact or Technical Support, please visit www.elitescreens.com Updated 04/04/2017...
