CPX-E-...AI-U-I
Analogue input module
Instructions | Operating
8126658
2020-01a
[8126660]
Translation of the original instructions
© 2020 all rights reserved to Festo SE & Co. KG
1

About this document

This document describes the use of the above-mentioned product.
Certain aspects of use are described in other documents and must be observed
è 1.1 Applicable Documents.
1.1 Applicable Documents
All available documents for the product è www.festo.com/pk.
Document
Description of the automation system CPX-E
(CPX-E-SYS)
Instruction manual for automation system CPX-E
(CPX-E-SYS)
Description of analogue input module
CPX-E-...AI-U-I (CPX-E-...AI-U-I)
Documentation of the components in an
automation system CPX-E and the connected
peripherals
Documentation for the higher-order controller
and the additional participants in the network
Tab. 1 Applicable Documents
1.2

Product version

This document refers to the following product versions:
Product Version
CPX-E-4AI-U-I Analogue input module CPX-E-4AI-U-I, revision 1 or later
Tab. 2 Product version
The product version can be identified from the product labelling or with the help
of appropriate software from Festo.
Appropriate software for determining the product version can be found in the
Festo Support Portal è www.festo.com/sp.
Information on using the software can be found in the integrated Help function.
There may be an updated version of this document for these or later product ver-
sions è www.festo.com/sp.
1.3

Product labelling

The product labelling is located on the left-hand side of the module. Scanning the
printed Data Matrix Code with an appropriate device opens the Festo Support
Portal, with the information appropriate for the product. Alternatively, the Product
Key (11-digit alphanumeric code on the product labelling) can be entered in the
search field of the Support Portal.
You can find detailed information on the product labelling in the description of the
module è 1.1 Applicable Documents.
Festo SE & Co. KG
Ruiter Straße 82
73734 Esslingen
Germany
+49 711 347-0
www.festo.com
8126658
Contents
Detailed description of the
automation system CPX-E
Instruction manual and important information on
Assembly, electrical installation and mainten-
ance tasks for an automation system CPX-E
Detailed description of product function and
parameterisation options
Information on using the components
Information on commissioning and paramet-
erisation of the components
1.4

Specified standards

Version status
EN 60529:2013-10
EN 61000-6-2:2005-08
Tab. 3 Standards specified in the document
1.5

UL/CSA Certification

In combination with the UL inspection mark on the product, the information in this
section must also be observed in order to comply with the certification conditions
of Underwriters Laboratories Inc. (UL) for USA and Canada.
UL certification information
Product category code NRAQ/NRAQ7
File number E239998
Considered standards UL 61010-1, 3rd Edition, May 11, 2012, revised April 29, 2016
CAN/CSA-C22.2 No. 61010-1-12, 3rd Edition, revision dated April
29, 2016
UL 61010-2-201, 1st Edition, revised February 20, 2017
CSA-C22.2 No. 61010-2-201: 14, 1st Edition, issue date January
01, 2014
UL mark
Tab. 4 UL/CSA Certification Information
– Technical Data and environmental conditions may be subject to change in
order to comply with Underwriters Laboratories Inc. (UL) certification require-
ments for the USA and Canada.
Observe deviations è Technical data.
– The unit shall be supplied by a power source which fulfils the requirements
on a limited-energy circuit in accordance to IEC/EN/UL/CSA 61010-1 or on a
Limited Power Source (LPS) in accordance to IEC/EN/UL/CSA 60950-1 or
IEC/EN/UL/CSA 62368-1 or a Class 2 circuit in accordance to NEC or CEC.
2 Safety
2.1

Safety instructions

– Take into consideration the legal regulations for the respective destination.
– Use the product only within the defined values
è 13 Technical Dataè Tab. 13 Ambient Conditions UL/CSA.
– Observe labelling on the product.
– Observe further applicable documents.
– Store the product in a cool, dry, UV-protected and corrosion-protected envir-
onment. Ensure that storage times are kept to a minimum.
– Before working on the product: switch off the power supply and secure it
against being switched on again.
– Comply with the handling specifications for electrostatically sensitive devices.
2.2

Intended Use

The product described in this document is intended only for use in an Automation
system CPX-E.
Use the product only as follows:
– Use only in an industrial environment. Outside industrial environments,
e.g. in commercial and residential/mixed-use areas, it may be necessary to
take measures to suppress radio interference.
– Use only in combination with modules and components that are permissible
for the respective product variant è www.festo.com/catalogue.
– Only use the product if it is in perfect technical condition.
– Only use the product in original status without unauthorised modifications.
Only the conversions or modifications described in this and the further applic-
able documents are permitted.
2.3

Training of Qualified Personnel

Installation, commissioning, maintenance and disassembly should only be con-
ducted by qualified personnel. The qualified personnel must be familiar with
installation of electrical control systems.
3

Further information

– Accessories è www.festo.com/catalogue.
– Spare parts è www.festo.com/spareparts.
4 Service
Contact your regional Festo contact person if you have technical questions
è www.festo.com.
5

Product overview

5.1

Function

In an Automation system CPX-E, the product provides analogue inputs for record-
ing analogue input signals.
EN 61000-6-4:2007-01
IEC 60204-1:2014-10
