BiWire Flexi Fire Panel EFBW8ZONE-FLEXI / EFBW4ZONE-FLEXI / EFBW2ZONE-FLEXI
Installation and Operation manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BiWire Flexi and is the answer not in the manual?

Questions and answers

Summary of Contents for Eaton BiWire Flexi

  • Page 1 BiWire Flexi Fire Panel EFBW8ZONE-FLEXI / EFBW4ZONE-FLEXI / EFBW2ZONE-FLEXI Installation and Operation manual...
  • Page 2: Table Of Contents

    Zone Fire Detection Check ..... . . 20 2 . tHe BIWIre FleXI FIre deteCtIon & alarm sYstem 3 Zone Fault Detection Check ..... . 20 2.1 CONTROL AND INDICATION EQUIPMENT (CIE) .
  • Page 3: Introduction

    Control and Indication Equipment (CIE) and Power Supply Equipment (PSE). The BiWire Flexi fire alarm system is certified to EN54 part 2 and part 4 and is designed to meet the recommendations in The components of the CIE and PSE have been selected for BS5839.
  • Page 4: Control And Indication Equipment (Cie)

    The panel continuously monitors the state of each zone for Fire and Fault conditions which are only indicated on the The BiWire Flexi Fire Panel is designed as an Analogue affected zone. Once a Fire condition is detected on a zone non-addressable system.
  • Page 5: Power Supply Equipment (Pse)

    High internal resistance of the battery • Figure 2 shows the location of the power supply. “Individual Figure 2 . BiWire Flexi power supply equipment Zone Test” on page 25 provides a full technical specification for the power supply. BatterY dIsposal InstruCtIons...
  • Page 6: Eolm-3

    The EOLM-1™ module can be installed in the base of the last manual call point or detector base. CautIon IF tHIs deVICe Is not Installed WItH tHe InCorreCt polarItY a Fault WIll Be dIsplaYed on tHe FIre panel Figure 4 . eolm-1 module InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 7: System Wiring

    5K1 EOLR embedded in the last device. Standard conventional and BiWire detection and alarm devices cannot be wired onto an intrinsically safe conventional zone. Figure 5 . BiWire Flexi system Wiring diagram InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 8: Status Indications

    SLOW The panel is in self test mode Individual Zone SLOW Individual zone is in test mode test active and awaiting fire activation Walk test SLOW Panel is in walk test mode and active awaiting fire activation InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 9: Control Panel Inputs And Outputs

    (BWeXtr 24V or 230V) FItted to tHe sYstem, Be aWare tHese WIll CHanGe state and reQuIre a panel reset to return to QuIesCent mode . WarnInG no VoltaGe sHould Be applIed to tHIs Input InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 10: Fire Relay

    The Interlink Relay in conjunction with a non-latching zone can be used to link two BiWire Flexi fire panels together (Figure 12) or to link a BiWire Flexi to a BiWire Ultra panel. It is recommended to use a non-latching zone in the BiWire mode and fit the EOLM-3 at the interlink relay of each panel.
  • Page 11: Detector Zone Inputs

    Short and Open circuit faults. Even if the conventional sounder circuits are not in use they must be terminated by the 6K8 resistors inside the panel. InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 12: Installation Instructions

    3.1 Before you begin note WarnInG dIp sWItCH settInGs onlY taKe eFFeCt onCe tHe WHen InstallInG tHe BIWIre FleXI FIre sYstem panel Has Been poWer CYCled or tHe Hard reset Care sHould Be taKen to ensure tHat tHe Button Is pressed .
  • Page 13: Panel Installation

    Well VentIlated plaCe, and not In dIreCt sunlIGHt . temperatures In eXCess oF 40°C and BeloW 5°C maY Cause malFunCtIons, IF In douBt Consult eaton eleCtrICal sYstems . tHe panel sHould Be loCated aWaY From anY potentIal HaZard, In a posItIon WHere It Is...
  • Page 14 If the panel is wall mounted, pull the cabling through the • glands ready for wiring. Fit the door back onto the back box by following the reverse • instructions in Figure 15. Figure 20 . secure the panel to the wall InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 15: Connecting The Mains Supply

    ConneCtor sCreWs too tIGHt . Keep polarItY tHrouGHout . non Coloured ConduCtors sHould Be permanentlY marKed . Figure 22 . Battery cover removal Figure 21 . mains supply connection to pse InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 16: Battery Connections

    Connect the cables (clearly labelled with the zone numbers) to the appropriate zone +/- terminals, observing the correct polarity. Figure 24 shows how different types of zone can be connected to a BiWire Flexi Fire Panel. If any of the zones are not used then the EOLM-3 must remain fitted to the terminals of that zone to ensure the system remains fault free.
  • Page 17: Connecting The Input/Output Cables

    (see Figure 24). To enable the repeater output switch 2 of SW12 on the panel main board must be changed to the Repeater Output On setting (see Figure 27) InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 18: Option Board Installation

    These outputs are not monitored so there is no need for a 6K8 termination resistor. Change the jumpers on the zonal relays to get them to operate in either normally open or normally closed during a fire alarm condition. InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 19: Panel Configuration

    SW3.7 = OFF SW3.7 = ON SW5.7 = ON SW5.7 = OFF SW5.7 = OFF SW3.8 = N/A SW3.8 = OFF SW3.8 = ON SW5.8 = ON SW5.8 = OFF SW5.8 = OFF InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 20: Detector Fitting

    “Individual Zone Test” on page 25). Activate a manual call point (or a detector if there is no call • point on the zone) in that zone and then check the following: InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 21: Fire Outputs & Battery Check

    Fire relay has switched over to C/NO. • All fire alarm devices are sounding. • Perform a soft reset and then check that the panel and interlinked panel have returned to the normal condition with mains fault. InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 22: Maintenance

    To be conducted by the Competent Person. Carry out the weekly test and record the results in the log • book. Carry out the Quarterly testing. • Test all fire detection devices and manual call points. • InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 23: Operating Instructions

    The panel will return to the normal condition after • completing the indicator test routine which turns each indicator on in turn and then turns them off in turn. note WHen perFormInG a reset, anY test Cases WIll Be Cleared InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 24: Mute Buzzer

    1 (3 times) + 3 1 (5 times) + 3 1 (9 times) + 3 fitted) FPE (if 1 (4 times) + 3 1 (6 times) + 3 1 (10 times) + 3 fitted) InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 25: Individual Zone Test

    Each indicator on the front of the panel will turn on in turn • and then turn off in turn (excluding the Power On indicator). This function will immediately exit back to Access Level 1. InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 26: Self-Test Mode

    If no fire detection device or manual call point is triggered within 10 minutes of the walk test being started, the test mode will timeout and return back to access level 1/normal condition. InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 27: Technical Specification

    Repeater Port Type RS485 Nodes note: The use of this port is outside the scope of EN54 certification Environmental °C Operating Temperature -5°C to +40°C Relative Humidity 93% +/3% non-condensing IP Rating IP30 InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 28: Pse Specification

    0V (J4 pins 2 and 10) reference 7.3 EOLM-3 Specification EFBW2Zone-Flexi EFBW4Zone-Flexi EFBW8Zone-Flexi Power Specification Operating Voltage 18.75-30.7V DC Nominal Current 1.7mA 7.4 EOLM-1 Specification EFBW2Zone-Flexi EFBW4Zone-Flexi EFBW8Zone-Flexi Power Specification Operating Voltage 18.75-30.7V DC Nominal Current 1.4mA InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 29: Option Board Specification

    Current per Device Type Device Current (mA) 0.08 0.02 0.02 0.02 0.02 0.02 0.13 Quantity Current per Device Type Device Current (mA) 0.08 0.02 0.02 0.02 0.02 0.02 0.13 Quantity Current per Device Type InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 30: Zone Loading In Alarm Condition

    (4000 - (0.5 * (60 + ZA) ) ) / (51 + ZQ) Hours Total Zone Alarm Current (ZA) Standby Time Calculation (4000 - (0.5 * (60 + ZA) ) ) / (51 + ZQ) Hours InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
  • Page 31: Manufacturers Contact Details

    Vibration Resistance Vibration Resistance Durability of Operational Reliability, Pass Durability of Operational Reliability, Pass Electrical Stability Electrical Stability Durability of Operational Reliability, Pass Durability of Operational Reliability, Pass Humidity Resistance Humidity Resistance InstallatIon and operatIon manual 25-16732-A November 2019 www.eaton.com...
