Application Guidelines
Three phase electrical
characteristics
LRA (Locked Rotor Amp)
MCC (Maximum Continuous
Current)
16
AB243586442172en-001301
Electrical data, connections and wiring
Compressor model
SH090
SH105
SH120
SH140
SH161
SH184
SH180
SH240
SH295
SH380
SH090
SH105
SH120
SH140
SH161
SH184
SH180
SH240
SH295
SH380
SH485
SH090
SH105
SH120
SH140
SH161
SH184
SH090
SH105
SH120
SH140
SH161
SH184
SH180
SH240
SH295
SH380
SH485
SH090
SH105
SH120
SH140
SH161
SH184
SH180
SH240
SH295
SH380
SH485
* 380-415V/3ph/50Hz for SH295 and SH485
Locked Rotor Amp value is the higher average
current as measured on mechanically blocked
compressor tested under nominal voltage. The
LRA value can be used as rough estimation for
The MCC is the current at which the motor
protection trips under maximum load and
low voltage conditions. This MCC value is the
maximum at which the compressor can be
operated in transient conditions and out of
LRA MCC Max. operating current Winding resistance
A A
203 43
267 51
267 61
304 64
315 69
351 75
380 78
485 105
560 128
717 170
98 22
142 25
142 29
147 30
158 35
197 38.6
170 38
215 51
260 62
320 79
344 106
157 40
223 43
223 51
236 53
236 57
236 57
84 18
103 22
103 24
122 26
136 29
135 35
135 30
175 41
210 45
235 60
327 71
124 26
160 33
160 35
168 37
177 41
239 51
210 46
260 60
310 72
360 90
491 111
the starting current. However in most cases, the
real starting current will be lower. A soft starter
can be applied to reduce starting current.
the application envelope. Above this value, the
internal motor protection or external electronic
module will cut-out the compressor to protect
the motor.
A Ω
38 0.39
45 0.27
48 0.27
56 0.24
64 0.22
71 0.22
71 0.19
103 0.16
112 0.13
155 0.09
19 1.47
22 1.05
24 1.05
28 0.92
31 0.83
36 0.83
34 0.8
49 0.62
56 0.52
72 0.42
91 0.23
32 0.5
38 0.35
41 0.35
49 0.31
53 0.31
56 0.31
14 2.34
17 1.57
19 1.57
22 1.38
24 1.32
28 1.32
28 1.20
38 0.94
44 0.82
58 0.56
71 0.36
23 1.05
26 0.72
29 0.72
33 0.62
37 0.57
41 0.57
44 0.52
58 0.42
69 0.36
88 0.24
106 0.16
