Application Guidelines
SH380 code 3
725.8
667
277.4
301.5
172.2
370.8
304.8
60°
12
AB243586442172en-001301
Dimensions
Ø333.2
Ø318.1
76.6
345.4
279.4
183
60°
202
195
8°
202.3
308.8
356
Rigid spacer
29.5 mm
524.8
92.5
4 holes Ø19.43
477
273
HM 8 bolt
Lock washer
Nut
Flat washer
Rigid spacer
Nut
All dimensions in mm
Flexible grommet
HM 8 bolt
Lock washer
Flat washer
Steel mounting sleeve
Rubber grommet
Nut
Discharge: 1"1/8
Suction
1"5/8
Compressor
base plate
27.5 mm
