Probe Power-On
When the probe is powered on, all LEDs briefly
flash as the self-test routine runs, and then the
following LEDs remain lit:
5X Attenuation
A – B TriMode (Differential)
This indicates that the probe is in normal
operating mode.
NOTE.
The host instrument sets all probe
settings to the last known state for the
probe/channel combination. If none of the
Range LEDs are lit, the instrument may have
detected an error condition. Disconnect and
reconnect the probe to clear the error.
