Operating Considerations

Operating Considerations
Table 1: P7500 Series TriMode Probes
Characteristic
Input Voltage
Temperature
Humidity
Pollution
Degree
CAUTION. To avoid ESD damage to the probe, always use an antistatic wrist strap (provided with your probe), and work at
a static-approved workstation when you handle the probe.
2
Description
Dynamic Range
Input Voltage Range
(DC + peak AC, Both ranges;
input referenced to ground)
Operating
Nonoperating
Operating
Nonoperating
Specification
P7513, P7516: ±0.750 V (5X),
±1.75 V (12.5X)
P7513, P7516: +4.0 V, –2.0 V
0 to +40 °C (+32 °F to +104 °F)
-20 °C to +71 °C (-4 °F to +160 °F)
Up to +40 °C (+104 °F) 20%-80% RH
+30 °C to +46 °C (+86 °F to +115 °F) 0-90% RH
2, Indoor use only
P7500 Series TriMode Probes Quick Start User Manual
P7520: ±0.625 V (5X),
±1.60 V (12.5X)
P7520: +3.7 V, –2.0 V
