4
Specifications
Size:
114mm x 67mm x 20mm
Power:
9V – 30V
Current:
4G/4G unit @12V
4G/4G unit @24V
Alarm inputs:
16 General purpose inputs 1-16. (-0.5V – 30V)
Alarm threshold: High >2V, and Low <1.3V
Outputs:
3 x Relay NO C NC (Comms, Func, Fire)
RS232 port:
remote panel access (UDL) and signalling to some intruder panel types
RS485 port:
remote panel access (UDL) and signalling to some intruder panel types
Configuration:
Using on board configuration buttons, web portal or App
Processor:
STM32
Wireless modules: ELS61
Average
Normal Operation
110mA
50mA
Average Max loading
(inc relays and dial capture operated)
190mA
110mA
