- Page 1 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) SUPPORT FREE technical support 24 hours a day, 7 days a week: Call 877-877-2269 or fax 724-746-0746 INFORMATION Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
- Page 2 FIBER WALLMOUNT CABINET, 12-ADAPTER Specifications Construction: 16-gauge steel Size: 6.51"H x 14.02"W x 15.98"D (16.5 x 35.6 x 40.6 cm) Weight: 20.7 lb. (9.4 kg) What’s Included • (1) fiber enclosure cabinet (assembled) • (4) rectangular cable rings • (2) sets of semi-circle cable rings (installed) •...
- Page 3 FIBER WALLMOUNT CABINET, 12-ADAPTER Installation REPARINg THE NcLoSURE AND oUNTINg IT oN A 1. Place the Fiber Wallmount Cabinet near the incoming fiber and patch cord routing. 2. Mount the cabinet on a wall. Use the enclosure as a positioning template, then use fasteners that are appropriate for the wall construction.
- Page 4 9. Gently route the fiber slack into the management clips. TRADEMARKS USED IN THIS MANUAL Black Box and the Double Diamond logo are registered trademarks of BB Technologies, Inc. Kevlar is a registered trademark of E.I. du Pont de Nemours and Company.
