  • Page 1 Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 SUPPORT Mail order: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 INFORMATION Web site: www.blackbox.com • E-mail: info@blackbox.com...

  • Page 2: Federal Communications Commission

    CODE OPERATED SWITCH II This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference when the equipment is operated in a commercial environment.

  • Page 3: Table Of Contents

    Chapter 1 Specifications ...4 2 Introduction ...5 3 Installation...6 3.1 Introduction ...6 3.2 Setting the DIP Switches ...6 3.3 Functions and Arrangements of the Switch Banks ...7 3.4 Bank Assignments ...8 3.5 Configuring Ports with the Individual Port Switch Banks...8 3.6 Setting Global Characteristics with the System Switch Banks ...8 3.6.1 Functions fo Switch Bank SWF ...8 3.6.2 Setting the Arming Character with SWG...10...

  • Page 4: Specifications

    CODE OPERATED SWITCH II 1. Specifications Interface — RS-232 asynchronous (each port individually selectable for DTE or DCE) Connectors — Switch: (5) DB25S female; Switch with Expansion Board: (9) DB25S female Pins Supported — 1-8, 20, 22 Speed — 110 to 19,200 bps (selectable by port) Memory —...

  • Page 5: Introduction

    The Code Operated Switch II (COS II) makes code-operated switching possible for diverse combinations of serial devices. As it switches, the COS II also reconciles differences in word size, speed, flow control, and parity for up to four devices. An Expansion Board, available separately, doubles the maximum number of devices, to eight.

  • Page 6: Installation

    CODE OPERATED SWITCH II 3.1. Introduction In addition to this manual, your Switch package should contain one standard switch unit and a wallmounted power supply. After you’ve unpacked the Switch, take a few minutes to look through this manual. You will need a screwdriver large enough to remove the case screws, and a small screwdriver or other edged tool for setting DIP switches.

  • Page 7: Functions And Arrangements Of The Switch Banks

    The board layout for the Four-Port Expansion Board is shown on this page (Fig. 2). If you have ordered one, check your Board to make sure it matches. NOTE: Every time you change the DIP switch settings, you must press the reset button located on the front panel of the switch, or unplug the power supply.

  • Page 8: Bank Assignments

    CODE OPERATED SWITCH II In addition, there are some system characteristics that are set with the eighth DIP switch of the individual port switch banks. Sections 3.6 and 3.7 explain these functions in depth. 3.4 Bank Assignments The individual port switch banks are assigned as follows: Bank Label Port...
  • Page 9 Automatic Timeout The COS II times the intervals between the reception of each character and the next. You may instruct it to return to an unlinked state after intervals of 2.5, 5, or 10 minutes, or you may disable this automatic timeout feature. SWF 5 and SWF 6 control this feature.

  • Page 10: Setting The Arming Character With Swg

    CODE OPERATED SWITCH II 3.6.2 S ETTING THE RMING HARACTER WITH Switch Bank SWG supplies a portion of the control-code sequence, the sequence that activates the Switch. The arming character, the ASCII code that alerts the COS-II to an upcoming switch action, is set with SWG. The settings are given in the chart below.
  • Page 11 ARMING CHARACTER SWITCH POSITIONS ASCII CTRL HEX DECIMAL ’ < > CHAPTER 3: Installation...
  • Page 12 CODE OPERATED SWITCH II ARMING CHARACTER SWITCH POSITIONS ASCII CTRL HEX DECIMAL...
  • Page 13 ARMING CHARACTER SWITCH POSITIONS ASCII CTRL HEX DECIMAL CHAPTER 3: Installation...
  • Page 14 CODE OPERATED SWITCH II ARMING CHARACTER SWITCH POSITIONS ASCII CTRL HEX DECIMAL...

  • Page 15: Setting Global Characteristics With The Individual Banks

    ARMING CHARACTER SWITCH POSITIONS ASCII CTRL HEX DECIMAL 3.7Setting Global Characteristics with the Individual Banks Several other system-wide options are specified not by the system switch banks, but rather by the eighth switch position of the individual port switch banks. Explanations and tables are given below.

  • Page 16: Configuring Ports For Dte Or Dce

    CODE OPERATED SWITCH II Set SWB 8 Pass breaks Ignore breaks Lead Pass-Through This function allows the COS II either to pass hardware-handshake leads to connected devices, or to block them. If they are blocked, the leads will still be used to regulate the 8K internal buffer of the Switch.

  • Page 17: Connecting And Powering-Up The Cos-Ii

    3.9. Connecting and Powering Up the COS-II Once you have configured the internal switches and jumpers, you can connect your devices and the wallmounted power jack to the COS-II. Before you begin, you might wish to check the settings of all the DIP switches again, to make sure you have set them correctly.

  • Page 18: Operation

    CODE OPERATED SWITCH II 4.1. Introduction The primary action of the Switch consists of detecting and responding to control-code sequences. As it switches to a particular port, the COS-II establishes a link between the master and the slave device. After the COS-II has switched, it can lock the link out, that is, it can ignore all requests by other ports until the link is broken.

  • Page 19: Indicators

    4.6. Indicators The front panel of the Switch contains 10 LEDs. The Power LED, at the extreme right, will glow steadily when power is on. The Lockout LED, a green LED at the extreme left, will light when the unit is in lockout. Each of the eight port LEDs, numbered 0 through 7, will respond to the action of the COS II.
  • Page 20 CODE OPERATED SWITCH II After you have hit a key, the screen will change to: Serial Port Test SERIAL PORT TEST (EXPANSION BOARD IS NOT INSTALLED) PORT# DATA DTR/CTS/RI MASTER FAILED PORT 0 FAILED FAILED PORT 1 FAILED FAILED PORT 2 FAILED FAILED PORT 3...

  • Page 21: Quick Reference Guide

    Quick Reference Guide Individual Port Switch Bank Settings Option Speed 110 bps 300 bps 600 bps 1200 bps 2400 bps 4800 bps 9600 bps 19200 bps Parity none even Word Size 7 bits per word 8 bits per word Flow Control Hardware (DTR/CTS) Software (X-ON/X-OFF) Settings for Switch Option F...
  • Page 22 CODE OPERATED SWITCH II System Switch Options Available through Position 8 Option SWA 8 Self-test Normal operation Pass breaks Ignore breaks Lead pass-through Normal operation Graphics Mode Pause In Master Data Slave Data Master or slave data Text Mode Switch SWB 8 SWC 8 SWD 8...
  • Page 23 ©Copyright 1999. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
