Dancover GH16050 Manual

Lean-to greenhouse 1,1x2x2,1m
Hide thumbs

Advertisement

Quick Links

Download this manual
Manual
for
Lean-to Greenhouse
1,1x2x2,1m
27-04-2020

Advertisement

loading
Need help?

Need help?

Do you have a question about the GH16050 and is the answer not in the manual?

Questions and answers

Related Manuals for Dancover GH16050

Summary of Contents for Dancover GH16050

  • Page 1 Manual Lean-to Greenhouse 1,1x2x2,1m 27-04-2020...
  • Page 2 - ASSEMBLING THE ROOF STRUCTURE (fig. A). Components A - Mount the ridges of the roof. To mount the front and Description rear ridge, use the 3-way joint Pos.01 while to mount the Pos. Cod. Q.ty central ridges use the 4-way joint Pos.02, fit the 95 cm 1685 3-way joint long tubulars (Pos.04a) into the slanted slots of the joints.
  • Page 3 - MOUNT THE VERTICAL TUBES (fig. D). A - Insert the tubulars Pos. 05 and 03 into the roof. fig. D...

  • Page 4: On The Ground

    - ASSEMBLY OF THE COLUMNS ON THE GROUND (fig. B). A - Position the greenhouse in the point where you intend to mount it, having first flattened the ground or in the case of grassy ground after having performed a very low grass cut. Make sure that the size at the base of the pipes is the same as for the roof.

  • Page 5: On The Floor

    - ASSEMBLY OF THE DOWELS ON THE FLOOR (fig. C). A - Position the greenhouse in the point where you intend to mount it (fig. C). Make sure that the size at the base of the pipes is the same as for the roof. B - Contour the tubes with a marker or other tracer means (fig.C1) to outline the position where to fix the bases Pos.10;...
  • Page 6 - COMPLETE THE ASSEMBLY OF THE STRUCTURE (fig. E). A - Mount the roof over the vertical tubulars Pos.05 so as to obtain the complete structure. B - After assembly, check the external dimensions with those of the drawing. It is important that the dimensions correspond to ensure correct assembly of the sheet. fig.
  • Page 7 - MOUNTING THE SHEET (fig. F). A - Open the sheet zips and then drag the sheet Pos.06 on the structure starting from one side of the greenhouse as shown in the figure. fig. F...
  • Page 8 - ASSEMBLY OF THE COVER (fig. G). A - Once the cap has been inserted, close the zips and arrange the sheet carefully. B - Use the stakes Pos.07 to fix the sheet on the ground. C - Cover the protruding part of the sheet with the soil making sure it is well stretched. (C) Cover with soil the abundant sheet (B) Close the zips...
  • Page 9 - ASSEMBLY OF THE SHADING NET (fig. H). To keep the cultivated products longer, the greenhouse has been equipped with a shading net that must be fixed under the roof of the greenhouse with the appropriate plastic clips also supplied. A - Insert the shading net Pos.08 between the greenhouse sheet and the roof tubulars and fix it to the eaves tubular with the clips Pos.09.
  • Page 10 Contact information Head office: Dancover A/S For more information Nordre Strandvej 119 G please visit: 3150 Hellebæk www.dancovershop.com Denmark National contact Denmark: 70 26 76 20 Spain: 911 436 828 denmark@dancover.com espana@dancover.com UK: 020 8099 7570 Italy: 02 479 21 198 uk@dancover.com...
