- Page 1 Manual Greenhouse Nursery 0,51x0,91x1,68m 15-11-2021...
- Page 2 Assembly Instructions PRODUCT SIZE(LxWxH): 51X91X168CM PLEASE READ CAREFULLY BEFORE ASSEMBLY...
- Page 3 PART PART PART PART L01A M6X10 L01B L18A M4X6 L18B L01C D101 M6X12 L19A L01D D108 L19B L01E D109 L02A D117 L21A L02B H78-1 Ø4X12 L22A H78-2 Ø4X12D L23A J121L M4.2X10 L08A J121R L08B J119L L10A J119R L14A J120 PART POLYCARBONATE PANEL PC/Glass Milky Film...
- Page 4 PART Roof Vent Assembly L19A L19B Fix L19A to L19B using Z15, L23A then insert the panel Y10 into position. Fix L20 to L19A/L19B, using Z15. D108 Ø4X12D M4X6 L19A L19A L19B L19B Slide 2*S36 into the channel of L19B to fix A68, using M16.
- Page 5 Fix L23A & L31 to the window as below, using D108 and Z15. (L23A & L31 are factory fitted as a part already) D108 L23A&L31 L23A D108 D108 L23A D108...
- Page 6 PART L18B L18A L18B L18A L18A Ø4X12D Outside View Door Assembly L18B L18A L18A Fix L18A to L15&L18B using Z15,then put the panel Y11 L18B L18B into position. L18A L18A L18A L18A Fix another L18A to L15 & L18B, using Z15.
- Page 7 PART Shelves Assembly (3PCS) L22A Fix L21A (3PCS) to 2 * L22A as below, L21A using Z15. Ø4X12D L22A L21A L21A L21A L22A Insert panel Y7 into the channel of L22A. Attention: If glass is chosen, make sure the shelves should be put in a safe place to avoid damaging or falling off after assembly.
- Page 8 PART Main Frame Assembly L08A L08B L01B L02B L10A L01C L01A L02A L02B L01A L02A L01A L01B L01C M6X10 L08A L08B Fix the base and all the vertical elements using S35 & M14. L08A L10A L08B S35/M14 L08A S35/M14 L02A S35/M14 S35/M14 S35/M14...
- Page 9 PART Ø4X12D L22A L22A L01A&B L02A Put the panels into positions. Fix the shelves to L01A/L01B/L01C and L02A/L02B, using Z15.
- Page 10 PART L01D L01D L01E L01E D101 M6X10 Fix L06, L07, L01D & L01E with the vertical frame using plate D99 & D101 and S35 & M14. S35/M14 D101 S35/M14 L01E/D...
- Page 11 PART Door Secure L14A onto L14A L07 using Z19. L14A Ø4X12D Fix L13 to L07 and M4.2X10 L10A using Z15. H78-1 H78-2 L14A Door L18B Door DOOR Put the magnetic sticker H78 onto L18A and L13 at matching positions so that the door can close tightly.
- Page 12 PART Window J121L/R Ø4X12D Ø4X12 J121L J121R J119L/R J119L S35/M14 J119R Fix parts J119R/L & J120 J121R/L, using Z15. D109 D117 Fix plate D109 onto L07,using S35 & M14, then fix J120 onto D109,using Z03. M6X10 J120 D109 M4X6 inner view M6X12...
- Page 13 L23A Roof Vent L23A Roof Vent Slide 2 * S37 into the channel of L31 to fix it to L06 using M15. L23A L23A S35/M14 D117 Loosen the existing Z15, and fix D117 bracket to L13 & L01A using the same Z15 and S35 & M14.
- Page 14 Head office: Dancover A/S For more information Lyngevej 16A, Nørre Herlev please visit: 3400 Hillerød www.dancovershop.com Denmark...
