Dancover GH152015 Manual

Orangery
Hide thumbs

Advertisement

Quick Links

Download this manual
Manual
for
Orangery
3,2x2,83x2,75m
28-11-2019

Advertisement

loading
Need help?

Need help?

Do you have a question about the GH152015 and is the answer not in the manual?

Questions and answers

Related Manuals for Dancover GH152015

Summary of Contents for Dancover GH152015

  • Page 1 Manual Orangery 3,2x2,83x2,75m 28-11-2019...
  • Page 2 Assembly Instructions PRODUCT SIZE(LxWxH):320x283x275cm PLEASE READ CAREFULLY BEFORE ASSEMBLY...
  • Page 3 CONTENTS...
  • Page 4 Assembly and Maintenance Advice 1. For safety purposes, we strongly recommend that this product is assembled by at least two people. 2. Some components have sharp metal edges. Please be careful when handling metal components. Please wear gloves, shoes and safety goggles during assembly. 3.
  • Page 5 Functions and Features: 1. Compared with traditional greenhouses, this exciting new product features many significant improvements. The hollow box profile aluminium framing is much stronger than other greenhouses and it can withstand much greater pressure. Wind resistance up to 12th typhoon (40M/S or 120KM/H). Weight Support 80KGS/M2, Snow load capability over 40CM.
  • Page 6 3. Base anchor brackets are included as standard with expanding bolts to ensure a secure fixing into concrete or paving. Alternatively, you can use the brackets to fix into a timber base with wood screws. Expansion Steel bar/Lawn land screw/Concrete ground 4.
  • Page 7 GH152010 PART L08A L01A M6X12 PART L02A L02K L03A L23A L23B L23C L23D M6X12...
  • Page 8 GH152010 PA RT PA RT W indowx2pcs Door L02B PA RT PA RT L02C L19A L02D L16A L19B L02E L16B L04A L11F L18A L24A L11G L18C L24B L18D L11H L24C S 01 L11J L24D M6X12 Ø4X10 S 04 L25A M8X150 PA RT L25B S 02...
  • Page 9 GH152010 PART PC/Glass...
  • Page 10 PART L11F L11G L19A L19B Windowx2pcs Ø4X10 Ø4X16D L19A L19A L11G L19B L11F L11F L11G...
  • Page 11 L19A L19A L19B L19A L19B L19A Push down the button on After connector J has been fitted, connector J before inserting it use the hole in the profile to tighten into the end of the frame profile. the connector in place.
  • Page 12 L11G L11F L11F L11G First the glazing panel Y10 should be loosely retained by the bar capping profiles L11F and L11G. Next tap the bar capping gently into position with a rubber mallet.
  • Page 13 Fix the W06 vent handles using Z03 screws.
  • Page 14 Fill the gap with silicone sealant on 4 sides to avoid any leaking.
  • Page 15 PART PART PART Door L16A L16B M8X35 L18A L18C Ø4X50 L18D L11H L11J...
  • Page 16 Put L16A into L17 and L18D and put L16B into L18A and L18C, then assemble the door frames using connector J, as shown in the sketches below. L18A&B&D L16A L18D L16A L16A&B S02x2pcs L18D L16A L16B L18A L16A Push down the button on connector J before inserting it L18C into the end of the frame profile.
  • Page 17 L11H L11J L11H L11H L11J L11H First the glazing panels should be loosely retained by the bar capping profiles L11H and L11J. Next tap the bar capping gently into position with a rubber mallet,...
  • Page 18 Slide 2xS02 into L18D, positioned 100mm away from each edge. Secure S02 using M02 bolts, then rotate the wheels to ensure free movement. 100mm 100mm 29mm 29mm After Assembly * This is the method of adjusting the door height.
  • Page 19 Expansion bolt in concrete It is essential the dimensions a = b = c are the same to ensure the base is square. Steel pegs in soil Support at the corners only is inadequate.
  • Page 20 PART Expansion bolts assembly M8X60 106.3 3123.5mm 2705mm This size is the inner specification of the product,...
  • Page 21 PART L08A L08A L08A L08A L08A L08A L08A First lay out the aluminium profiles, connectors and anchor brackets approximately in place. Make sure you pay close attention to the direction of the pins L08A L08A L08A Assemly all the L08A and L10 with connecter A. Insert connector A into L08A and L10, tight the bolts with the special spanner (provided) when the connector A is in the right position.
  • Page 22 PART L01A L01A L01A L01A L01A L01A L01A Make sure you pay close attention to the direction of the pins L01A L01A L08A L08A L08A Assembly L01A with connector A,insert connector A into L01A, tight the bolt with the special spanner when the it's in the right position.
  • Page 23 PART M6X12 Make sure you pay close attention to the direction of the pins S02X3pcs L01A L01A Slide S01 (3PCS) into the Assembly L07 and L01A with connector B, insert connector B channel of L07 for later use, into L01A and L07, tight the bolt with the special spanner the one which is Parallel to L10.
  • Page 24 PART L23A L23B L23B L23A L08A L23A L23B L01A Please pay attention to the direction L23B L23B L08A Tap the bar capping L23B into L10, L08A and L07, and L23A into L01A gently with a rubber mallet.
  • Page 25 PART L23C L23C L23C L23C L23C L08A L23C L23C 50mm 50mm Tap the bar capping L23C into L10 and L08A gently with a rubber mallet. Make sure you leave 50mm between the two L23C in the middle,for later assembly of L02A. Do the same on the other sides.
  • Page 26 PART L02A L02A L02A L02A L23A L02A L02A L02A L23A L02A L02A L23C L23C L02A Put connector K into the slot of L07, L10 Slide in Tight it up and L08A, turn its direction until it goes into the hole on L02A. Tight the bolt in the connector K with the spanner.
  • Page 27 PART L23D L23D L23D L01A L02A L01A L23D L01A L01A L23D L02A 50mm 50mm 50mm 50mm Tap the bar capping L23D into L01A and L02A gently with a rubber mallet. Make sure you leave 50mm between the two L23D in the middle,for later assembly of L02K. Do the same on the other sides.
  • Page 28 PART L23A L23D L23A L23D L01A L01A L01A L02A L01A L02A L23D L23B L23D 50mm 50mm L23D L23D Tap the bar capping L23A and L23D into L01A and L02A gently with a rubber mallet. Make sure you leave 50mm between the two L23D in the middle,for later assembly of L02K. Do the same on the other sides.
  • Page 29 PART L02K L02K L02K L02K L23D L02K L23D Slide in Tight it up Put connector K into the slot of L02A and L01A, turn its direction until it goes into the hole on L02K. Tight the bolt in the connector K with the spanner. Pay attention to the direction on the spanner.
  • Page 30 PART L23C L23C L02K L23C Tap the bar capping L23C into L02K gently with a rubber mallet.
  • Page 31 PART L03A L03A L03A M6X12 L03A S01&W11 L03A L03A Assembly L03A with connector B, insert connector B into L03A, tight the bolt with the special spanner when the it's in the right position. Don't forget to assembly the anchor bracket J02 at the same time.
  • Page 32 PART L03A L03A M6X12 Do the same for the left L03A.
  • Page 33 PART Auto Cap Assembly GM80003 GM80003 Put automatic opener GM80003 through the central hole on W01 (fig. 1). Use plug W04 to pass over the hole on GM80003 (fig. 2), bend and secure it (fig 3).
  • Page 34 PART L24A L24B L03A Roof frame on the window vent side assembly L24B 578mm L24B L24B L03A L03A L24A L24A Tap the bar capping L24A into L03A and L24B into L07 gently with a rubber mallet. Make sure you leave 50mm between the two L24B in the middle,for later assembly of L02D. Do the same on the other side which you want to assemble the window vent (2 standard window vents for one set).
  • Page 35 PART L02C L02C L25A 50mm L02E L02D L25A L25A L25B L02E L02E L25B L25A 578mm L25A L25B L02D L25B L25B L02D L25A L25B Roof frame on the window vent side M6X12 assembly L02E Tap the bar capping L25A and L25B into L02E gently with a rubber mallet. Make sure you leave 50mm between the two L25A in the middle,for later assembly of L02C, and leave 578mm between the two L25B in the middle, for later assembly of L02D.
  • Page 36 PART L03A L02D L02D Put connector K into the slot of L07 turn its direction until it goes into L24B L24B the hole on L02D. Tight the bolt in the connector K with the spanner. Pay attention to the direction on the spanner. Slide in Tight it up L03A...
  • Page 37 PART L25C L25D L25E L02C L02E L25C L02D L02D L25E L25D L25D Tap the bar capping L25C into L02C, L25D insto L02D and L25E into L02E gently with a rubber mallet. Do the same on the side which you want to assemble the window vent.
  • Page 38 PART L24C L24C 50mm L24C L24C Tap the bar capping L24C into L07 gently with a rubber mallet. Make sure you leave 50mm between the two L24C in the middle,for later assembly of L02B. Do the same on the other sides.
  • Page 39 PART L02B M6X12 L02B L02B L02B W11&S01 L24C L24C Slide in Tight it up Put connector K into the slot of L07 turn its direction until it goes into the hole on L02B. Tight the bolt in the connector K with the spanner. Pay attention to the direction on the spanner.
  • Page 40 PART L24D L24D L02B L24D Tap the bar capping L24D into L02B gently with a rubber mallet. Do the same on the other sides.
  • Page 41 PART M8X150 GM80003 GM80003 GM80003 After secure S04 onto W02, turn the Put screw S04 into spring W09 (2PCS), auto opener GM80003 clockwise so that and then pass through the two holes on W01, it pushes up W02, leave some gaps between secure them onto the two holes on cap W02.
  • Page 42 PART Panel Assembly L11B L11B L12C L11B L12C L12D L12D L11B L12C L12D Install the panels and aluminum bar capping in order as shown above, tap these bar capping into the channels of each position properly with a rubber hammer. Do the same on the other side.
  • Page 43 Fill the silicone sealant on the places shown above to avoid any water leaking. Do the same on the other side.
  • Page 44 PART L11B L11B L11B L12B L12B L12B L11B L11B Install the panels and aluminum bar capping in order as shown above, tap these bar capping into the channels of each position properly with a rubber hammer. Do the same on the other sides.
  • Page 45 Fill the silicone sealant on the places shown above to avoid any water leaking. Do the same on the other sides.
  • Page 46 PART Window x2pcs Ø4X10 M6X12 Slide the window vent along the groove in the L22 and fix it in the correct position using Z03 screws. L19A Window *Ensure the manual vent is closed as shown. Use a screw S01 to pass over Part Z,and then put part Z (2pcs) into the slot of L07 turn its direction until it can fix W08.
  • Page 47 PART PART L11A L11D L12A L12K L11A L11A L12K L12K L12A L11D L11D Install the panels Y6 and aluminum bar capping in order as shown above, tap these bar capping into the channels of each position properly with a rubber hammer.
  • Page 48 PART PART L11A L11E L12A L12K L11A L12K L12A L11E Install the panels Y6 and aluminum bar capping in order as shown above, tap these bar capping into the channels of each position properly with a rubber hammer.
  • Page 49 PART L18D Rotate D, the roller wheels, to adjust the height of the door Door so it does not bind or rub on the bottom track.
  • Page 50 PART L04A Ø4X14D L04A L04A GM80003 L04A Turn the auto opener GM80003 counter clockwise, adjust the space between W02 and L03A to ideal position.
  • Page 51 PART Ø4X14 L03A Drill a hole in L01A and L01B, Fill some silicone sealant Fill some silicone sealant approximately 3.2mm diameter around the downpipe bends around J02 and J06 to avoid and 700mm up from the bottom. to avoid water leaking. water leaking.
  • Page 52 PART L01A L08A&L10 L03A L01A...
  • Page 53 Contact information Head office: Dancover A/S For more information Nordre Strandvej 119 G please visit: 3150 Hellebæk www.dancovershop.com Denmark National contact Denmark: 70 26 76 20 Spain: 911 436 828 denmark@dancover.com espana@dancover.com UK: 020 8099 7570 Italy: 02 479 21 198 uk@dancover.com...
