Dancover GH158011 Manual

Commercial greenhouse tunnel 10x15x3,7m

Advertisement

Quick Links

Manual
for
Commercial greenhouse tunnel
10x15x3,7m
29-12-2021

Advertisement

loading
Need help?

Need help?

Do you have a question about the GH158011 and is the answer not in the manual?

Questions and answers

Summary of Contents for Dancover GH158011

  • Page 1 Manual Commercial greenhouse tunnel 10x15x3,7m 29-12-2021...
  • Page 2 Assembly Instructions...
  • Page 3 Dear customer / dear garden friend, we congratulate you on purchasing a greenhouse. You have chosen a high quality and stable greenhouse. Please read the assembly instructions first. Follow this step by step! Storage / keeping Store protected - Please store all components in a dry place and protected from direct sunlight! Parts list / packing list Before you start to assemble the greenhouse, please use this description (material list) to...
  • Page 4 The construction of the greenhouse must be carried out by at least two people! Work with safe, handcrafted tools. Always work with gloves (risk of injury, risk of cuts) This symbol describes the manual work, e.g. the assembly of components You need the following tools to set up: •...
  • Page 5 Frame List of material: Width: 10,00m Lenght 16,50m Note: The number of items in this material list corresponds to a greenhouse length of 16.50 m. If the greenhouse length is longer/shorter, the individual items will be adjusted accordingly! See also delivery note! Qty.
  • Page 6 Foundation of your greenhouse The stable and robust construction of the greenhouses allows them to be installed directly on a level, pre-compacted surface. The fastening is carried out with an earth anchor system and the film has to be buried. Frame-assembling: 1.0 Angle the base 1.1 Tension cords alongside...
  • Page 7 2.0 Anchor / longitudinal tube 150 cm 10,00 m 10,03 m Set the anchor along the cord - for distance see 2.2 a. Push the longitudinal tubes through the eyelets of the anchor 2007 b. Connect the longitudinal pipes to the pipe sections. 9241 Note: The longitudinal tubes are 6m long, the start and end pieces are 9433...
  • Page 8 Arch assembling 3.1.1 Assemble left / right arch - using connector 54 9081 Place spacer between archs and connector 9412 Fix the arch left / right to connector with screw 4.8x19 14006 NOTE: nut must point inward 14101 3.1.2 Place strut and screw 9220 NOTE: nut must point inward 14007...
  • Page 9 Set up arch / frame 4.1.1 Set up pre-assembled frames in field 2 4.1.2 Push the pipe clamp left / right onto the frame 19004 NOTE: The clamp leg must point inwards 4.1.3 Screw the frame to the longitudinal tube 14008 NOTE: - The nut must point inwards 4.1.4...
  • Page 10 Longitudinal pipes NOTE - As soon as a frame is set up - mount the longitudinal tube 4.4.1 Mount the center tube 9431 14005 4.4.2 Mount the longitudinal pipe on the left 9431 14005 4.4.3 Mount the longitudinal tubes on the right 9431 14005 S-hook...
  • Page 11 Gable List of material Note: For a material list, see also the delivery note Qty. Part-No. Designation 2,00 9041 Gable 1000 with top part 3,04 13021 Twin wall plate, 4 x 3,5m x 2,1m / 4 x 2,5m x 1,05m 2,00 13022 H- Profile, 4 x 2,5m 2,00...
  • Page 12 Gable assembly Gable element 1.1.1 Assemble gable element left / right using connector 54 9041 NOTE: nut must point down 9412 1.1.2 Mount connector, center 9434 Place spacer between pipe bend and connector 9470 NOTE: nut must point down 14009 1.1.3 Mount connector, right 9434 NOTE: nut must point down...
  • Page 13 Screen 1.2.1 Screw the screen to the pre-fabricated bracket 9206 14101 Upper part of the gable 1.3.1 Mount the pre-assembled upper part of the gable 14101 NOTE: Use existing screw holes for positioning...
  • Page 14 Running rail 1.4.1 Mount the running rail 20002 Note: distance between running rail and post must be 15mm 1.4.2 Mount the retaining plate on the right, door post 9426 14101 1.4.3 Mount the retaining plate to the right, arch 9424 14101 1.4.4 Mount the retaining plate, center 9422...
  • Page 15 Guide shoes 1.5.1 Mount guide shoe holder left / right 9429 14101 1.5.2 Mount the left / right guide shoe 9443 14101...
  • Page 16 Ventilation flap 1.6.1 Position ventilation flap - align evenly between the profiles 9202 4,8x19 1.6.2 Fasten the ventilation flap with clamps 9445 1.6.3 Position and fix the clamps on the left 14101 1.6.4 Position and fix the half clamps on the right 14101...
  • Page 17 Rod for stand 1.7.1 Mount the „rod for place“ (linkage) 5212 14101 1.7.2 Attach the „rod for stand” (linkage) 9216 19020...
  • Page 18 Door 1.8.1 Screw the trolleys into the holes provided 20003 1.8.2 Hang the door on the track 9092 1.8.3 Place the door stop at the end of the track 20004 1.8.4 Mount the door handle 15004...
  • Page 19 Close the gable 1.9.1 Place twin-wall sheets and screw them together 13021 NOTE: Screws with sealing washer 14102 NOTE: Screw spacing approx. 30cm NOTE: Adapt the twin-wall sheet to the arch contour using a cutter knife H-Schiene 1.9.2 Connect the joint edge of the twin-wall sheet with the H-profile 13022 1.9.3 Foam adhesive tape - tape off the sharp edge of the twin-wall sheet as 20014...
  • Page 20 2.0 Film Roll out the foil on the ground Fasten the chain with the hooks on arches 1 + 2 on the lower chord. Pull the film over the sheet / frame Fasten the chain with the hooks on arches 1 + 2 on the lower chord. Tension the film - chain tensioner 9512 If necessary, dig in the excess film...
  • Page 21: Contact Information

    Contact information Austria Belgium Croatia Denmark Estonia Finland France Germany Ireland Italy Latvia Lithuania Nederland Norway Poland Portugal Spain Sweden Switzerland For more information please visit: www.dancovershop.com...
