3 Menu Functions

3.2.6 Parameter / Manual operation

ATTENTION:
The documentation for manual operation refers to MOVIDRIVE
has become easier to activate and exit manual operation.
Functions
Activate manual operation
Processing terminals or con-
trol functions
Terminal function / Control-
ler inhibit (DI00)
Exiting manual operation
Inverter behaviour after exit-
ing manual operation
Any present IPOS programs will continue running in manual operation, and the IPOS program will
respond to changes made in manual operation.
Recommendation:
Stop running IPOS programs to avoid undesirable reactions in manual operation.
12
Older versions
Terminal/Controller inhibit (DI00) = 0
All programmed terminals will be evalu-
ated, i.e. the inverter requires the corre-
sponding enable data to respond to the
manual operation setpoint.
Always set this input to 1 (= 24 V) to move drive.
The inverter is stopped at ramps t
t /t and remains in status „controller
21 22
inhibit". A return to „normal" operation is
accomplished by toggling terminal DI00
= 0, DI00 = 1.
The inverter responds to setpoints and terminal signals as programmed and might start
operating immediately.
®
software version .15 and later. It
Version .15 or later
The inverter only has to be in inhibit status, i.e.
no power supply to standstill and output stage.
No terminal functions are evaluated, except
limit switch functions (LS CW/CCW).
/t / Exit manual operation only in inhibit status.
11 12
01133AEN
