3.2.3 Parameter / User menu

The user menu is a customized menu where you can put together an individual selection of
parameters.
Inserting a parameter
Press the <Ins> key. Enter the desired parameter number in the editing window. Press the
<RETURN> key. The new parameter will be inserted.
If the new parameter is not inserted, this may be because
– the parameter number you have entered does not exist
– the parameter number you have entered is already included in the user menu
– the maximum number of entries (max. 100 entries) has been reached.
Deleting a parameter
Press the <Del> key. If the user menu contains only one parameter, then it is not possible to delete
this parameter.
Printing the parameters included in the user menu:
Press <F4>.
IMPORTANT:
When you set the default user menu:
The existing user menu configuration will be overwritten.

3.2.4 Parameter / Signature

You can store any 16 characters in the unit. This ensures unique identification of the parameter set
or the unit. This character string is shown in the MX_SHELL status line and printed in the header of
the hardcopy printout.

3.2.5 Parameter / Manual reset

This menu has the same effect as P840 "Manual reset" = YES.
You may also reset the inverter with the <r> key.
