4. Digital Inputs (counters)

DAEnetIP4 IP controller (the core of the current module) supports 8 digital inputs
every of which is combined with 16 bit cyclic counter. These inputs are extended with
Schmitt triggers in this module so they are able to handle voltages from 0 up-to 30V
DC. Moreover every digital input can control digital output (relay) and send traps up-
on falling and/or rising edge of the input signal. For more information please refer to
the DAEnetIP4's documentation here:
http://denkovi.com/Documents/DAEnetIP4/Current-Version/UserManual.pdf
Type
Digital inputs count
Nominal value of inputs
Max non desctructive voltage
Input switching limit values
Input impedance at state 1
Sensor compability
Input type
Isolation
Protection
Digital input pin # (DAEnetIP4 JP2)
Digital Input #1 (JP2.1)
Digital Input #2 (JP2.2)
Digital Input #3 (JP2.3)
Digital Input #4 (JP2.4)
Digital Input #5 (JP2.5)
Digital Input #6 (JP2.6)
Digital Input #7 (JP2.7)
Figure 5. Location of the digital inputs
Voltage
Current
From 0 to 1 Voltage
From 1 to 0 Voltage
2-wire
3-wire
Between supply and
inputs
Between inputs
Against reverse polarity
Table 4. Mapping to DAEnetIP4 JP2 digital inputs (counters) port
Digital Input # (peripheral board)
Din1
Din2
Din3
Din4
Din5
Din6
Din7
Table 3. Digital inputs electrical characteristics
VDC
mA
VDC
VDC
Current
mA
VDC
Current
mA
Peripheral board
8
12
5.2
30.0
>7.6
>3.2
<4.5
<1.8
2.2
Yes PNP
No
Resistive with Schmitt
trigger
No
No
Yes
Page 8
