ProSim™ 8
Getting Started Manual
ECG Artifact
Type ........................................................................ 50 Hz, 60 Hz, muscular, baseline wander, respiration
Size ......................................................................... 25 %, 50 %, 100 % of the normal sinus R-Wave for each lead
Lead Select ............................................................ All, RA, LL, LA, V1, V2, V3, V4, V5, V6
Fetal / Maternal-ECG
Fetal Heart Rate (Fixed) ........................................ 60 BPM to 240 BPM in 1 BPM steps
Fetal Heart Rate (IUP) ........................................... 140 BPM at beginning, then varies with pressure
Intrauterine-Pressure Waveforms ....................... Early deceleration, late deceleration, and acceleration
Wave Duration ....................................................... 90 seconds, bell-shaped pressure curve, from 0 mmHg to 90 mmHg and returning to
IUP Period .............................................................. 2 minutes, 3 minutes, or 5 minutes; and manual
Default Settings ..................................................... FHR 140 BPM, early deceleration wave, manual

Invasive Blood Pressure

Channels ................................................................ 2, each independently settable with identical parameters and are individually electrically
Input/output Impedance ....................................... 300 Ω ±10 %
Exciter Input Range .............................................. 2.0 V to 16.0 V peak
Exciter-Input Frequency Range ........................... DC to 5000 Hz
Transducer Sensitivity ......................................... 5 μV/V/mmHg (default) or 40 μV/V/mmHg
Pressure Accuracy ............................................... ±(1 % of setting + 1 mmHg) Accuracy guaranteed for DC excitation only
Static Pressure ...................................................... -10 mmHg to +300 mmHg in 1 mmHg steps
Pressure Units ....................................................... mmHg or Kpa
18
0 mmHg
isolated from all other signals
