USA (FCC) .......................................................... 47 CFR 15 Intentional Radiators: This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation. (15.19).
Changes or modifications not expressly approved by Fluke could void the user's authority to operate the equipment. (15.21)

Detailed Specifications

Normal-Sinus-Rhythm Waveform
ECG Reference ...................................................... The ECG amplitudes specified are for Lead II (calibration), from the baseline to the peak
Normal Sinus Rhythm ........................................... 12-lead configuration with independent outputs referenced to right leg (RL). Output to
High-Level Output ................................................. 0.5 V/mV ±5 % of the ECG amplitude setting available on a BNC connector.
Amplitude ............................................................... 0.05 mV to 0.5 mV (0.05 mV steps); 0.5 mV to 5.0 mV (0.25 mV steps). Other leads are
Lead I .................................................................. 70
Lead II ................................................................. 100
Lead III ................................................................ 30
Lead V1 ............................................................... 24
Lead V2 ............................................................... 48
Lead V3 ............................................................... 100
Lead V4 ............................................................... 120
Lead V5 ............................................................... 112
Lead V6 ............................................................... 80
of the R wave. All other leads are proportional.
10 Universal ECG Jacks, color-coded to AHA and IEC Standards.
proportional to Lead II (reference lead) in percentage per:
