Summary of Contents for Marzocchi Bomber 58
- Page 1 TUNING GUIDE...
- Page 2 20% sag (Plush) DUST WIPER 203 mm (8in) 30 mm (1.2in) 41 mm (1.6in) Your fork has a 4 digit ID code on the back of the lower leg. Use this number at www.Marzocchi.com to find out more information about your fork.
- Page 3 120-130 54-59 130-140 59-64 140-150 64-68 150-160 68-73 160-170 73-77 170-180 77-82 180-190 82-86 190-200 86-91 200-210 91-95 210-220 95-100 220-230 100-104 230-240 104-109 240-250 109-113 Do not exceed maximum air pressure: BOMBER 58 maximum air pressure is 120 psi.
- Page 4 (counter-clockwise) to the number of clicks shown in the table below. REBOUND Rebound controls the rate of speed at which the fork Rider Weight (lbs) Rider Weight (kgs) BOMBER 58 extends after compressing. 120-130 54-59 130-140 59-64...
- Page 5 GRIP COMPRESSION ADJUSTER Use this diagram as a starting point for your compression adjuster. Turn your compression adjuster to the closed position (full clockwise) until it stop. Then back it out (counter-clockwise) to the number of clicks shown below. Low-speed compression adjustment is useful to control fork performance during rider weight shifts, G-outs, and other...
- Page 6 Torque the two pinch bolts on the rider’s right dropout to 2.15 Nm (19 in-lb). WARNING: Failure to secure the axle properly can cause the wheel to become detached from the bicycle, resulting in SERIOUS INJURY OR DEATH. SEE ADDITIONAL INFORMATION AND VIDEOS: MARZOCCHI.COM...
- Page 7 ADDITIONAL TUNING OPTIONS CLIP-ON VOLUME SPACERS Changing volume spacers in the BOMBER 58 fork is an easy internal adjustment that allows you to change the amount of mid stroke and bottom out resistance. If you have set your sag correctly and are using full travel (bottoming out) too easily, then you could install one or more spacers to increase bottom out resistance.
- Page 8 NOTES...
- Page 10 ©MARZOCCHI. 2017 // 1.800.369.7469 915 Disc Drive, Scotts Valley, CA 95066 USA 605-00-174 REV A...
