RAM PROMASTER

20 2 1 OWNER' S M ANUAL

Summary of Contents for RAM PROMASTER 2021

Page 1 RAM PROMASTER 20 2 1 OWNER’ S M ANUAL...
Page 2 This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment that are no longer available or were not ordered on this vehicle.
Page 3 TABLE OF CONTENTS INTRODUCTION ..........................6 GETTING TO KNOW YOUR VEHICLE ................. 10 GETTING TO KNOW YOUR INSTRUMENT PANEL ............42 STARTING AND OPERATING ....................57 MULTIMEDIA ..........................88 SAFETY ............................149 IN CASE OF EMERGENCY .....................190 SERVICING AND MAINTENANCE ..................211 TECHNICAL SPECIFICATIONS ....................264 CUSTOMER ASSISTANCE ......................
Page 4 INTRODUCTION Turn Signals ..........27 SEATS ..............15 Lane Change Assist ........27 Manual Adjustments ........16 Symbols Key............7 Battery Saver ..........27 Heated Seats — If Equipped ....... 19 WARNINGS AND CAUTIONS ......... 7 INTERIOR LIGHTS ..........28 Fold Down Tray — If Equipped..... 20 VAN CONVERSIONS/CAMPERS ......
Page 5 GETTING TO KNOW YOUR STARTING AND OPERATING ParkSense Rear Park Assist Failure Indications............ 72 INSTRUMENT PANEL STARTING THE ENGINE ........57 Cleaning The ParkSense System....72 Automatic Transmission......57 INSTRUMENT CLUSTER........42 ParkSense Rear Park Assist System Normal Starting..........57 Instrument Cluster Descriptions....43 Usage Precautions ........
Page 6 FREEING A STUCK VEHICLE ......208 Safety Checks You Should Make Inside Player Operation ........146 TOWING A DISABLED VEHICLE......209 RAM TELEMATICS - IF EQUIPPED ....146 The Vehicle ..........187 Automatic Transmission......210 Periodic Safety Checks You Should Ram Telematics General Information ..147 ENHANCED ACCIDENT RESPONSE Make Outside The Vehicle ......188...
Page 7 SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION CNG And LP Fuel System Modifications..267 MMT In Gasoline........267 UNIFORM TIRE QUALITY GRADES ....259 SCHEDULED SERVICING ........211 Fuel System Cautions........267 Treadwear ..........259 Maintenance Plan........212 FLUID CAPACITIES..........268 Traction Grades .........259 ENGINE COMPARTMENT ........215 Temperature Grades .........259 ENGINE FLUIDS AND LUBRICANTS ....
Page 8 Dear Customer, Congratulations on the purchase of your new Ram. Be assured that it represents precision workmanship, distinctive styling, and high quality. This Owner’s Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle.
Page 9 Follow this reference for additional information camper manufacturer. on a particular feature. To obtain dimensional and technical specifications for your vehicle, refer to the Body Builder’s Guide at https://www.ramtrucks.com/ ram-commercial/body-builders-guide.html. FOOTNOTE Supplementary and relevant information VEHICLE MODIFICATIONS/ALTERATIONS pertaining to the topic.
Page 10 SYMBOL GLOSSARY Red Warning Lights Some car components have colored labels with symbols indicating Engine Temperature Warning Light precautions to be observed when using this component. It is important to Ú page 49 follow all warnings when operating your vehicle. See below for the definition of each symbol Ú...
Page 11 Yellow Warning Lights Yellow Indicator Lights Electronic Stability Control (ESC) OFF TOW/HAUL Indicator Light Warning Light Ú page 53 Ú page 52 Engine Check/Malfunction Indicator Green Indicator Lights Warning Light (MIL) Ú page 52 Turn Signal Indicator Lights Ú page 54 Anti-Lock Brake System (ABS) Warning Light Ú...
Page 12 GETTING TO KNOW YOUR VEHICLE KEYS 1 — Mechanical Key Release Button 2 — Driver/Passenger Unlock Button 3 — Lock Button Your vehicle uses a key start ignition system 4 — Cargo Lock/Unlock Button which supports Remote Keyless Entry (RKE). The key fob allows you to lock or unlock the To Lock/Unlock The Doors doors from distances up to approximately 66 ft...
Page 13 GETTING TO KNOW YOUR VEHICLE Replacing The Battery In The Key Fob WARNING! The recommended replacement battery is Always remove the key fobs from the  CR2032. vehicle and lock all doors when leaving the NOTE: vehicle unattended. Always remember to place the ignition in Customers are recommended to use a ...
Page 14 GETTING TO KNOW YOUR VEHICLE SENTRY KEY All of the keys provided with your new vehicle have been programmed to the vehicle The Sentry Key Immobilizer System prevents electronics. unauthorized vehicle operation by disabling the NOTE: engine. The system does not need to be armed A key which has not been programmed is also or activated.
Page 15 GETTING TO KNOW YOUR VEHICLE VEHICLE SECURITY SYSTEM — IF EQUIPPED The Vehicle Security system is designed to WARNING! (Continued) protect your vehicle. However, you can create The Vehicle Security system monitors the conditions where the system will give you a false Allowing children to be in a vehicle unat- ...
Page 16 GETTING TO KNOW YOUR VEHICLE DOORS WARNING! (Continued) OWER OCKS Never leave children alone in a vehicle, or  with access to an unlocked vehicle. The central lock/unlock button has an LED that Allowing children to be in a vehicle unat- indicates whether the doors are locked or tended is dangerous for a number of unlocked.
Page 17 GETTING TO KNOW YOUR VEHICLE SEATS NLOCK OORS This feature unlocks all front doors when one Seats are a part of the Occupant Restraint front door is opened. System of the vehicle. NOTE: WARNING! If the rear or side door is open, only the rear or It is dangerous to ride in a cargo area, side door is unlocked.
Page 18 GETTING TO KNOW YOUR VEHICLE Forward And Rearward Adjustment Height Adjustment ANUAL DJUSTMENTS The adjustment bar is at the front of the seat, Without Swivel Seat The driver and passenger seats can be adjusted near the floor. Pull the bar upward to move the forward/rearward and reclined.
Page 19 GETTING TO KNOW YOUR VEHICLE With Swivel Seat Recliner Adjustment normal upright position, lean forward and pull the lever outward. Release the lever once the Without Swivel Seat The height adjustment knobs are located on the seatback is in the upright position. center outboard side of the seat.
Page 20 GETTING TO KNOW YOUR VEHICLE Lumbar Support — If Equipped Damper Weight Adjustment Swivel Seat — If Equipped This feature allows you to increase or decrease The swivel seat lever is located at the lower front Use the weight adjustment knob, located on the the amount of lumbar support.
Page 21 GETTING TO KNOW YOUR VEHICLE — I If the driver or the passenger seats are not locked NOTE: EATED EATS QUIPPED in the facing forward position before the first Once a heat setting is selected, heat will be felt On some models, the front driver and vehicle movement, shifting out of park is not within two to five minutes.
Page 22 GETTING TO KNOW YOUR VEHICLE — I Turn the adjuster wheel to the right or left to QUIPPED adjust the height of the armrest up or down. If your vehicle is equipped with a bench seat, the seat is equipped with a fold-down tray that can be used as a document support surface.
Page 23 GETTING TO KNOW YOUR VEHICLE NOTE: WARNING! WARNING! (Continued) Do not reposition the head restraint 180 degrees to the incorrect position in an attempt to gain A loose head restraint thrown forward in a Head restraints should never be adjusted ...
Page 24 GETTING TO KNOW YOUR VEHICLE UCONNECT VOICE RECOGNITION “Repeat” to listen to the system prompts  again. NTRODUCING OICE ECOGNITION Notice the visual cues that inform you of your Start using Uconnect Voice Recognition with Voice Recognition system’s status. these helpful quick tips. It provides the key Voice TARTED Commands and tips you need to know to control your vehicle’s Voice Recognition (VR) system.
Page 25 GETTING TO KNOW YOUR VEHICLE MIRRORS Digital Rearview Mirror — If Equipped Push the menu button next to the on/off control to access the following mirror options: The Digital Rearview Mirror provides a high NSIDE EARVIEW IRROR definition, wide and unobstructed view of the Brightness ...
Page 26 GETTING TO KNOW YOUR VEHICLE — I If it becomes difficult to see clearly in the display, OWER IRRORS QUIPPED WARNING! the camera may need to be cleaned. If snow, ice, The power mirror controls are located on the mud, or any foreign substance builds up on the Vehicles and other objects seen in an outside driver’s side door trim panel.
Page 27 GETTING TO KNOW YOUR VEHICLE — The power folding mirrors are designed to be OWER OLDING UTSIDE IRRORS folded and unfolded using the power folding QUIPPED switch. If the mirrors are manually folded, the The power folding mirrors can be folded mirror head may appear loose.
Page 28 GETTING TO KNOW YOUR VEHICLE EXTERIOR LIGHTS turned on. To turn off the headlights, turn the WITCH end of the multifunction lever back to the O (off) With the low beams activated, pull the position. ULTIFUNCTION EVER multifunction lever toward the steering wheel to (DRL ) —...
Page 29 GETTING TO KNOW YOUR VEHICLE — I OLLOW EADLIGHT ELAY IGHTS QUIPPED HANGE SSIST When this feature is selected, the driver can The fog light switch is located on the center Lightly push the multifunction lever up or down, choose to have the headlights remain on for a stack of the instrument panel, just below the without moving beyond the detent, and the turn preset period of time after the engine is turned...
Page 30 GETTING TO KNOW YOUR VEHICLE INTERIOR LIGHTS Dome Lights CAUTION! The interior lights can be set to three different Before getting out of the vehicle be sure that OURTESY IGHTS positions (off/left position, center position, on/ the switch is in the center position or that the right position).
Page 31 GETTING TO KNOW YOUR VEHICLE Dimmer Controls The dimmer controls are located on the left side of the instrument panel below the instrument cluster display. Side Cargo Lamp Location Ceiling Cargo Lamp The Rear and Side Cargo Lamps can be set to The Ceiling Cargo Lamp can be set to three three different positions by pushing the lens to different positions (off/left position, center...
Page 32 GETTING TO KNOW YOUR VEHICLE WIPERS AND WASHERS Intermittent Wipers LLUMINATED NTRY Push the lever downward to the first detent and The courtesy lights will turn on when you use the INDSHIELD IPER PERATION rotate the center ring to use one of the four key fob to unlock the doors or open any door.
Page 33 GETTING TO KNOW YOUR VEHICLE CLIMATE CONTROLS A/C Button — If Equipped WARNING! Push the A/C button to engage the Air The Climate Control system allows you to Sudden loss of visibility through the Conditioning (A/C). The A/C indicator regulate the temperature, air flow, and direction windshield could lead to a collision.
Page 34 GETTING TO KNOW YOUR VEHICLE Recirculation Button Front Defrost Mode CAUTION! Press and release this button to Turn the mode control knob to the Failure to follow these cautions can cause change the system between Front Defrost position. Air comes from damage to the heating elements: recirculation mode and outside air the windshield and side window...
Page 35 GETTING TO KNOW YOUR VEHICLE Temperature Control Mode Control NOTE: Bi-Level mode is designed under comfort condi- Temperature Control regulates the temperature Turn the mode control knob to change tions to provide cooler air out of the panel of the air forced through the climate system. the airflow distribution mode.
Page 36 GETTING TO KNOW YOUR VEHICLE — Rear Blower Control DDITIONAL LIMATE ONTROL PERATING Push this button to turn on the rear QUIPPED NOTE: climate controls. An indicator light will These switches, mounted on the instrument Refer to the chart at the end of this section for turn on when the rear climate control suggested control settings for various weather panel to the left of the steering column, activate...
Page 37 GETTING TO KNOW YOUR VEHICLE Vacation Storage Cabin Air Filter CONTROL WEATHER For information on maintaining the Climate The Climate Control system filters out dust and SETTINGS Control system when the vehicle is being stored pollen from the air. Contact an authorized Operate in for an extended period of time, see dealer to service your cabin air filter, and to...
Page 38 GETTING TO KNOW YOUR VEHICLE INTERIOR STORAGE AND EQUIPMENT Dash Storage The dash storage is located on the right side of TORAGE the instrument panel. Glove Compartments The glove compartment is located on the passenger side of the instrument panel and features both an upper and lower storage area.
Page 39 GETTING TO KNOW YOUR VEHICLE USB/AUX C — I USB Charging Port ONTROL QUIPPED The USB connector port can be used for The USB Port and Auxiliary Jack is located on charging purposes only. Use the connection the instrument panel left of the radio (driver’s cable to connect an external USB device to the lower right).
Page 40 12 Volt For further information on using the auxiliary started (with accessories still plugged in), outlet. switches, please refer to the Ram Body Builders the vehicle must be driven a sufficient Guide by accessing www.rambodybuilder.com Do not touch with wet hands.
Page 41 GETTING TO KNOW YOUR VEHICLE WINDOWS To open the window part way, lift the window WARNING! switch to the detent for less than half a second OWER INDOWS Never leave children alone in a vehicle, or and release it to stop the window. ...
Page 42 GETTING TO KNOW YOUR VEHICLE HOOD 2. Move to the outside of the vehicle, reach UFFETING into the opening beneath the center of the Wind buffeting can be described as the hood and push the safety latch lever to the PENING perception of pressure on the ears or a right to release it, before raising the hood.
Page 43 GETTING TO KNOW YOUR VEHICLE CARGO AREA FEATURES LOSING The cargo area may be equipped with different WARNING! options such as optional side panels, rear seats Be sure the hood is fully latched before and an optional floor. driving your vehicle. If the hood is not fully latched, it could open when the vehicle is in motion and block your vision.
Page 44 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER Instrument Cluster...
Page 45 GETTING TO KNOW YOUR INSTRUMENT PANEL before the repair/service, so that you can be 3. Tachometer NSTRUMENT LUSTER ESCRIPTIONS sure that it is properly reset, or that the door This gauge measures engine revolutions  1. Speedometer jamb sticker is accurate if the odometer must per minute (RPM x 1000).
Page 46 GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER DISPLAY OCATION ONTROLS CAUTION! The instrument cluster display features a driver Your vehicle will be equipped with an Driving with a hot engine cooling system could interactive display that is located in the instrument cluster display, which offers useful damage your vehicle.
Page 47 GETTING TO KNOW YOUR INSTRUMENT PANEL If equipped with a Uconnect system, some MODE Button: Unless reset, this message will continue to  customer programmable features will display in display each time you turn the ignition switch to Push and hold the MODE button for a time the radio Ú...
Page 48 GETTING TO KNOW YOUR INSTRUMENT PANEL Selecting An Option Of The Main Menu Without ISPLAY ETUP 4. Push and release the up or down Submenu arrow button (by single pushes) to select the The menu comprises a series of functions new setting for this submenu option.
Page 49 GETTING TO KNOW YOUR INSTRUMENT PANEL NOTE: ERSONAL ETTINGS UTTON The range depends on several factors: driving USTOMER ROGRAMMABLE The TRIP button, located on the right steering style, type of route (freeway, residential, moun- EATURES column stalk, can be used to display and to tain roads, etc.), conditions of use of the vehicle reset the previously described values.
Page 50 GETTING TO KNOW YOUR INSTRUMENT PANEL WARNING LIGHTS AND MESSAGES Start Of Trip Procedure Air Bag Warning Light This light will turn on for four to eight With the ignition on, push and hold the TRIP The warning/indicator lights will illuminate in the seconds as a bulb check when the button for over two seconds to reset trip instrument panel together with a dedicated...
Page 51 GETTING TO KNOW YOUR INSTRUMENT PANEL Door Open Warning Light on when the ignition is placed in the ON/RUN or Brake Warning Light MAR/ON/RUN position and remain on briefly as This indicator will illuminate when one This warning light monitors various a bulb check.
Page 52 GETTING TO KNOW YOUR INSTRUMENT PANEL Brake Warning Light, which will turn on when Operation of the Brake Warning Light can be Vehicle Security Warning Light — If the brake fluid level in the master cylinder has checked by turning the ignition switch from the Equipped dropped below a specified level.
Page 53 GETTING TO KNOW YOUR INSTRUMENT PANEL Tire Pressure Monitoring System Warning Each tire, including the spare (if provided), Your vehicle has also been equipped with a should be checked monthly when cold and TPMS malfunction indicator to indicate when Light inflated to the inflation pressure recommended the system is not operating properly.
Page 54 GETTING TO KNOW YOUR INSTRUMENT PANEL system. If this light remains on after several Engine Check/Malfunction Indicator CAUTION! ignition cycles, and the vehicle has been driven Warning Light The TPMS has been optimized for the original several miles (kilometers) at speeds greater The Engine Check/Malfunction equipment tires and wheels.
Page 55 GETTING TO KNOW YOUR INSTRUMENT PANEL If the ABS light remains on or turns on while ELLOW NDICATOR IGHTS WARNING! driving, then the Anti-Lock portion of the brake Forward Collision Warning Off Indicator A malfunctioning catalytic converter, as system is not functioning and service is Light —...
Page 56 GETTING TO KNOW YOUR INSTRUMENT PANEL Park/Headlight On Indicator Light REEN NDICATOR IGHTS NDICATOR IGHTS This indicator light will illuminate Turn Signal Indicator Light High Beam Indicator Light when the park lights or headlights are The turn signal arrows will flash This indicator light will illuminate to turned on Ú...
Page 57 GETTING TO KNOW YOUR INSTRUMENT PANEL ONBOARD DIAGNOSTIC SYSTEM — OBD II need to access this information to assist with CAUTION! the diagnosis and service of your vehicle and Your vehicle is equipped with a sophisticated Prolonged driving with the MIL on could emissions system.
Page 58 GETTING TO KNOW YOUR INSTRUMENT PANEL EMISSIONS INSPECTION AND Your vehicle has a simple ignition actuated test, The MIL will not flash at all and will  which you can use prior to going to the test remain fully illuminated until you place MAINTENANCE PROGRAMS station.
Page 59 STARTING AND OPERATING STARTING THE ENGINE UTOMATIC RANSMISSION NGINE AILS TART The gear selector must be in the PARK or If the engine fails to start after you have Before starting your vehicle, adjust your seat, NEUTRAL position before you can start the followed the “Normal Starting”...
Page 60 STARTING AND OPERATING The engine block heater must be plugged in at The engine oil installed in the engine at the WARNING! (Continued) least one hour to have an adequate warming factory is a high-quality energy conserving type effect on the engine. lubricant.
Page 61 STARTING AND OPERATING PARKING BRAKE When the parking brake is applied with the WARNING! (Continued) ignition switch in the MAR (ACC/ON/RUN) Before leaving the vehicle, make sure that the position, the Brake Warning Light in the Be sure the parking brake is fully disen- ...
Page 62 STARTING AND OPERATING AUTOMATIC TRANSMISSION GNITION NTERLOCK WARNING! (Continued) This vehicle is equipped with a Key Ignition Park You must press and hold the brake pedal while When leaving the vehicle, always remove  Interlock which requires the transmission to be shifting out of PARK.
Page 63 STARTING AND OPERATING NOTE: The transmission gear selector provides PARK, Swivel seats that are unlocked can also prevent REVERSE, NEUTRAL, DRIVE, and Electronic the transmission gear selector from being Range Select (ERS) shift positions. Manual downshifts can be made using the ERS shift moved out of the PARK position.
Page 64 STARTING AND OPERATING Gear Ranges When exiting the vehicle, always: WARNING! (Continued) Do not press the accelerator pedal when Apply the parking brake.  It is dangerous to shift out of PARK or  shifting out of PARK or NEUTRAL. Shift the transmission into PARK.
Page 65 STARTING AND OPERATING The following indicators should be used to REVERSE (R) WARNING! (Continued) ensure that you have engaged the transmission This range is for moving the vehicle backward. into the PARK position: When exiting the vehicle, always remove  Shift into REVERSE only after the vehicle has the ignition key from the vehicle and lock come to a complete stop.
Page 66 STARTING AND OPERATING DRIVE (D) During extremely cold temperatures (-16°F 3. Turn the ignition OFF. [-27°C] or below), operation may briefly be This range should be used for most city and 4. Wait approximately 10 seconds. limited to THIRD gear only. Normal operation highway driving.
Page 67 STARTING AND OPERATING Electronic Range Select (ERS) Operation You can switch between DRIVE and ERS mode To exit ERS mode, simply return the gear at any vehicle speed. When the gear selector is selector to the DRIVE position. The Electronic Range Select (ERS) shift control in the DRIVE position, the transmission will allows the driver to limit the highest available WARNING!
Page 68 STARTING AND OPERATING Overdrive Operation The “TOW/HAUL Indicator Light” will illuminate when cold. This is normal. Using the Elec- tronic Range Select (ERS) shift control, when in the instrument cluster to indicate that TOW/ The automatic transmission includes an HAUL mode has been activated. Pushing the the transmission is sufficiently warm, will electronically controlled Overdrive (SIXTH gear).
Page 69 STARTING AND OPERATING CRUISE CONTROL — IF EQUIPPED NOTE: and/or the system is not functioning as anticipated. Coordinate inspection efforts Increased noise levels at the end of the  When engaged, the Cruise Control takes over through an authorized dealer. steering wheel travel are considered normal accelerator operations at speeds greater than and do not indicate that there is a problem...
Page 70 STARTING AND OPERATING If the lever is continually held up or down, the CTIVATE ESIRED PEED  set speed will continue to adjust until the Rotate the center ring upward on the Cruise Turn the Cruise Control on. When the vehicle lever is released, then the new set speed will Control lever to turn the system on.
Page 71 STARTING AND OPERATING PARKSENSE REAR PARK ASSIST — IF CCELERATE ASSING ESUME PEED EQUIPPED While the Cruise Control system is set, press the To resume a previously set speed, push the RES accelerator to pass as you would normally. button and release. Resume can be used at any The ParkSense Rear Park Assist system When the pedal is released, the vehicle will speed above 20 mph (32 km/h) up to the...
Page 72 STARTING AND OPERATING ENSE SSIST ENSE SSIST ENSORS LERTS The four ParkSense Rear Park Assist sensors, If an obstacle is behind the vehicle when located in the rear fascia/bumper, monitor the REVERSE gear is engaged, an audible alert is area behind the vehicle that is within the activated.
Page 73 STARTING AND OPERATING Audible And Visual Signals Supplied By The ParkSense Rear Park Assist System SIGNAL MEANING INDICATION Audible Signal (dashboard loudspeaker) • Sound pulses emitted at a rate that increases as the distance decreases. An obstacle is present within the Obstacle Distance sensors' field of view •...
Page 74 STARTING AND OPERATING erly. The Rear Park Assist system might not ENSE SSIST LEANING ENSE YSTEM detect an obstacle behind the fascia/ AILURE NDICATIONS Clean the Rear Park Assist sensors with water, bumper, or it could provide a false indication car wash soap and a soft cloth.
Page 75 STARTING AND OPERATING to “Check Entire Surroundings” across the top WARNING! (Continued) CAUTION! (Continued) of the screen. After five seconds this note will disappear. The ParkView Rear Back Up Camera Before using ParkSense, it is strongly The vehicle must be driven slowly when ...
Page 76 STARTING AND OPERATING When displayed, static grid lines will illustrate the width of the vehicle and will show separate zones that will help indicate the distance to the rear of the vehicle. The following table shows the approximate distances for each zone: Zone Distance To The Rear Of The Vehicle 0 - 1 ft (0 - 30 cm)
Page 77 STARTING AND OPERATING REFUELING THE VEHICLE WARNING! CAUTION! (Continued) The gas cap is located behind the fuel filler door Never have any smoking materials lit in or A poorly fitting fuel filler cap may cause the   on the left side of the vehicle. If the gas cap is near the vehicle when the fuel door is open “Malfunction Indicator Light (MIL)”...
Page 78 STARTING AND OPERATING OOSE ILLER ESSAGE EHICLE ERTIFICATION ABEL ROSS EHICLE EIGHT ATING (GVWR) If the vehicle diagnostic system determines that Your vehicle has a Vehicle Certification Label the fuel filler cap is loose, improperly installed, affixed to the driver’s side B-pillar or the rear of The GVWR is the total allowable weight of your or damaged, a “Check fuel cap”...
Page 79 STARTING AND OPERATING VERLOADING OADING The tire size on the Vehicle Certification Label The load carrying components (axle, springs, To load your vehicle properly, first figure out its represents the actual tire size on your vehicle. tires, wheels, etc.) of your vehicle will provide empty weight, axle-by-axle and side-by-side.
Page 80 STARTING AND OPERATING TRAILER TOWING Gross Combination Weight Rating (GCWR) WARNING! The GCWR is the total allowable weight of your In this section you will find safety tips and It is important that you do not exceed the vehicle and trailer when weighed in information on limits to the type of towing you maximum front or rear GAWR.
Page 81 STARTING AND OPERATING Trailer Sway Control (TSC) Weight-Distributing Hitch WARNING! The TSC can be a mechanical telescoping link A weight-distributing system works by applying An improperly adjusted Weight Distributing  that can be installed between the hitch receiver leverage through spring (load) bars. They are Hitch system may reduce handling, and the trailer tongue that typically provides typically used for heavier loads to distribute...
Page 82 STARTING AND OPERATING RAILER ITCH LASSIFICATION The following chart provides the industry standard for the maximum trailer weight a given trailer hitch class can tow and should be used to assist you in selecting the correct trailer hitch for your intended towing condition. Trailer Hitch Classification Definitions Class Max.
Page 83 STARTING AND OPERATING the Tire And Loading Information placard for the RAILER OWING EIGHTS AXIMUM CAUTION! maximum combined weight of occupants and RAILER EIGHT ATINGS Always load a trailer with 60% of the weight in cargo for your vehicle Ú page 245. NOTE: the front of the trailer.
Page 84 STARTING AND OPERATING Towing Requirements — Tires WARNING! WARNING! (Continued) Do not attempt to tow a trailer while using a  Make certain that the load is secured in the Vehicles with trailers should not be parked   compact spare tire. trailer and will not shift during travel.
Page 85 STARTING AND OPERATING An electronically actuated trailer brake NOTE:  CAUTION! controller is required when towing a trailer Disconnect trailer wiring connector from the  with electronically actuated brakes. When If the trailer weighs more than 1,000 lbs vehicle before launching a boat (or any other towing a trailer equipped with a hydraulic (453 kg) loaded, it should have its own device plugged into vehicle’s electrical...
Page 86 STARTING AND OPERATING Tow/Haul Mode OWING To reduce potential for automatic transmission Before towing, practice turning, stopping, and overheating, activate TOW/HAUL mode when backing up the trailer in an area located away driving in hilly areas, or select a lower gear from heavy traffic.
Page 87 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME) OWING EHICLE EHIND NOTHER EHICLE Towing Condition Wheels OFF the Ground Automatic Transmission Flat Tow NONE NOT ALLOWED Front Dolly Tow Rear NOT ALLOWED On Trailer NOTE: When towing your vehicle, always follow applicable state and provincial laws. Contact state and provincial Highway Safety offices for additional details. 3.
Page 88 STARTING AND OPERATING DRIVING TIPS Traction RIVING HROUGH ATER When driving on wet or slushy roads, it is Driving through water more than a few inches/ RIVING LIPPERY URFACES possible for a wedge of water to build-up centimeters deep will require extra caution to between the tire and road surface.
Page 89 STARTING AND OPERATING Shallow Standing Water CAUTION! CAUTION! (Continued) Although your vehicle is capable of driving Always check the depth of the standing Driving through standing water may cause   through shallow standing water, consider water before driving through it. Never drive damage to your vehicle’s drivetrain compo- the following Cautions and Warnings before through standing water that is deeper than...
Page 90 MULTIMEDIA UCONNECT SYSTEMS Your vehicle may be equipped with certain WARNING! security features to reduce the risk of For detailed information about your unauthorized and unlawful access to vehicle It is not possible to know or to predict all of ...
Page 91 MULTIMEDIA UCONNECT SETTINGS NOTE: Your Uconnect system may also have Screen Off and Mute buttons on the faceplate. FCA US LLC or your dealer may contact you  The Uconnect system uses a combination of Push the Screen Off button on the faceplate to directly regarding software updates.
Page 92 MULTIMEDIA 3/3 NAV S Push the Settings button on the faceplate to When making a selection, press the Menu CONNECT ETTINGS display the menu setting screen. In this mode, button on the touchscreen to enter the desired the Uconnect system allows you to access menu.
Page 93 MULTIMEDIA Display When the Display button is pressed on the touchscreen, the system will display the options related to screen brightness and language displayed on the touchscreen. The available settings are: Setting Name Description This setting will allow you to set the brightness manually or have the system set it automatically. The “Auto” Display Mode setting has the system automatically adjust the display brightness.
Page 94 MULTIMEDIA Units When the Units button is pressed on the touchscreen, the system displays the different measurement options. The selected unit of measurement will display in the instrument cluster display and navigation system (if equipped). The available settings are: Setting Name Description This setting will change the unit of measurement on the display to US.
Page 95 MULTIMEDIA Safety/Assistance When the Safety/Assistance button is pressed, the system displays the options related to the vehicle’s safety settings. These options will differ depending on the features equipped on the vehicle. The settings may display in list form or within subfolders on the screen. To access a subfolder, select the desired folder;...
Page 96 MULTIMEDIA Lights When the Lights button is pressed on the touchscreen, the system displays the options related to the vehicle’s exterior and interior lights. NOTE: When the “Daytime Running Lights” feature is selected, the daytime running lights can be turned on or off. This feature is only allowed by law in the country of the vehicle purchased.
Page 97 MULTIMEDIA Audio When the Audio button is pressed on the touchscreen, the system displays options related to the vehicle’s sound system. These settings can change the audio location within the vehicle, adjust the bass or treble levels, and auto-play music from an audio device or smartphone. Setting Name Description Equalizer...
Page 98 MULTIMEDIA SiriusXM® Setup When the SiriusXM® Setup button is pressed on the touchscreen, the system displays options related to SiriusXM® Satellite Radio. These settings can be used to skip specific radio channels and restart favorite songs from the beginning. NOTE: A subscription to SiriusXM®...
Page 99 MULTIMEDIA Restore Settings When the Restore Settings button is pressed on the touchscreen, the system displays the option related to resetting the Uconnect system back to its default settings. These setting can clear personal data and reset selected settings from other menus. Setting Name Description Restore Settings to Default...
Page 100 MULTIMEDIA UCONNECT INTRODUCTION NOTE: 1 — Settings Button Uconnect screen images are for illustration 2 — Back Button purposes only and may not reflect exact soft- DENTIFYING ADIO 3 — Enter/Browse & Tune/Scroll Knob ware for your vehicle. 4 — More Button 5 —...
Page 101 MULTIMEDIA Feature Description Settings Press the Settings button to access the Uconnect Settings. Back Press the Back button to return to a previous page. Push the Enter/Browse button to accept a highlighted selection on Enter/Browse & Tune/Scroll Knob the screen. Rotate the Tune/Scroll rotary knob to scroll through a list or tune a radio station.
Page 102 MULTIMEDIA Please read and follow these safety Keep drinks, rain and other sources of mois- AFETY ENERAL NFORMATION  ture away from your system. Besides damage precautions. Failure to do so may result in injury Safety Guidelines or property damage. to your system, moisture can cause electric shocks as with any electronic device.
Page 103 MULTIMEDIA UCONNECT MODES The radio is equipped with the following modes: Seek Functions Seek Up And Seek Down  ADIO Press and release the Seek Up or Seek Down  Operating Radio Mode button on the touchscreen to tune the radio SiriusXM®...
Page 104 MULTIMEDIA Direct Tune Info SiriusXM® Satellite Radio Mode Press the Info button to display the current track information. Press the X button to cancel this feature. Setting The Presets The Presets are available for all Radio Modes, and are activated by pressing any of the four Preset buttons, located at the top of the screen.
Page 105 MULTIMEDIA SiriusXM® services require subscriptions sold This functionality is only available for radios Acquiring SiriusXM® Subscription separately after the trial included with the new equipped with a Satellite receiver. In order to To activate the SiriusXM® Satellite Radio vehicle purchase. If you decide to continue your receive satellite radio, the vehicle needs to be subscription, US visit www.UconnectPhone.com outside with a clear view to the sky.
Page 106 MULTIMEDIA When in Satellite mode: Replay The SXM button on the touchscreen is high- The replay function provides a means to store  lighted. and replay up to 22 minutes of music audio and 48 minutes of talk radio. Once the channel is The SiriusXM®...
Page 107 MULTIMEDIA Press the Pause/Play button on the touchscreen to pause the playing of live or Play/Pause rewound content at any time. Play can be resumed again by pressing the Pause/Play button on the touchscreen. Press the Rewind button on the touchscreen to rewind the content in steps of five seconds.
Page 108 MULTIMEDIA Favorites Browse In SXM Press the All button on the Browse Screen. Press the Favorites button on the touchscreen to activate the favorites menu, which will time When pressing the All button, the following categories become available: out within 20 seconds in absence of user interaction.
Page 109 MULTIMEDIA Remove Favorites Add/Delete — If Equipped Audio Settings Press the Audio button within the settings main Press the Remove Favorites tab at the top of the Press the Add/Delete button on the touchscreen menu to activate the Audio Settings screen. screen.
Page 110 MULTIMEDIA Audio Setting Description Press the Balance/Fade button on the touchscreen to balance audio between the front speakers or fade the audio between the rear and front Balance/Fade speakers. Press the Front, Rear, Left or Right buttons or press and drag the red Speaker icon to adjust the Balance/Fade.
Page 111 MULTIMEDIA Radio Voice Commands Audio Source Selection EDIA Use your voice to quickly get to the AM, FM, or Once in Media Mode, press the Source button Operating Media Mode SiriusXM® Satellite Radio stations you would and the desired mode button. USB, AUX and like to hear.
Page 112 MULTIMEDIA Seek Up/Seek Down Repeat NOTE: The system supports only FAT32 or ExFAT Press the Repeat button on the touchscreen to Seek Up /Seek Down formatted USB devices. The system does not repeat the song selection. To cancel repeat, Press and release the Right Arrow button on support devices with a capacity higher than press the Repeat button on the touchscreen a...
Page 113 MULTIMEDIA Bluetooth® Mode Controlling The Auxiliary Device Push the VR button . After the beep, say one of the following commands and follow the Before proceeding, the Bluetooth® device must The control of the Auxiliary device (e.g., prompts to switch your media source or choose be paired with the Uconnect Phone to selecting playlists, play, fast forward, etc.) an artist.
Page 114 MULTIMEDIA Screen Activated Features Canada — visit UconnectPhone.com or call HONE  Dialing via Keypad using touchscreen. 800-465-2001 (English)  Overview 800-387-9983 (French) Viewing and Calling contacts from Phone- Uconnect Phone is a voice-activated,  books displayed on the touchscreen. hands-free, in-vehicle communications system.
Page 115 MULTIMEDIA Ensure you phone is turned on with Phone Operation For each feature explanation in this section,  Bluetooth® active and has been paired to the only the compound command form of the Operation voice command is given. You can also break vehicle's Uconnect Phone.
Page 116 MULTIMEDIA The system handles multiple inputs in the same Cancel Command phrase or sentence such as “make a phone At any prompt, after the beep, you can say call” and “to Kelly Smith”. For multiple inputs in “Cancel” and you will be returned to the main the same phrase or sentence, the system menu.
Page 117 MULTIMEDIA NOTE: 5. If “No” is selected, and you still would like to 9. When the pairing process has successfully pair a mobile phone, press the Pairing or completed, the system will prompt you to If there are no phones currently connected ...
Page 118 MULTIMEDIA You can also use the following VR command to NOTE: Connecting To A Particular Mobile Phone Or bring up the Paired Phone screen from any If there is no device currently connected with Audio Device After Pairing screen on the radio: the system, a pop-up will appear.
Page 119 MULTIMEDIA Disconnecting or Deleting A Phone Or Audio 3. Press the Settings button located to the Phonebook Download (Automatic Phonebook Device right of the device name for a different Transfer From Mobile Phone) — If Equipped phone or audio device than the currently If supported by your phone, Uconnect Phone connected device or press the preferred has the ability to download contact names and...
Page 120 MULTIMEDIA Depending on the maximum number of 2. After loading the mobile phonebook, select Phone Call Features  entries downloaded, there may be a short Contacts from the Phone main screen, and The following features can be accessed through delay before the latest downloaded names then select the appropriate number.
Page 121 MULTIMEDIA Call Controls Key Pad Number Entry Answer Or Ignore An Incoming Call — No Call Currently In Progress The touchscreen allows you to control the 1. Press the Phone button. following call features: When you receive a call on your mobile phone, 2.
Page 122 MULTIMEDIA Answer Or Ignore An Incoming Call — Call Do Not Disturb can automatically reply with a Place/Retrieve A Call From Hold Currently In Progress text message, a call, or both when declining an During an active call, press the Hold or Call On incoming call and send it to voicemail.
Page 123 MULTIMEDIA You can also push the Phone button to toggle Call Continuation Things You Should Know About Uconnect between the active and held phone call. Phone Call continuation is the progression of a phone call on the Uconnect Phone after the vehicle Join Calls Voice Command ignition has been switched to OFF.
Page 124 MULTIMEDIA Audio Performance Phone Voice Commands WARNING! Audio quality is maximized under: Making and answering hands-free phone calls ALWAYS drive safely with your hands on the is easy with Uconnect. When the Phonebook Low-To-Medium Blower Setting  wheel. You have full responsibility and button is illuminated on your touchscreen, your assume all risks related to the use of the Low-To-Medium Vehicle Speed...
Page 125 MULTIMEDIA Voice Text Reply — If Equipped Did You Know: Your mobile phone must have PRE-DEFINED VOICE TEXT REPLY the full implementation of the Message Access Uconnect can announce incoming text RESPONSES Profile (MAP) to take advantage of this feature. messages.
Page 126 MULTIMEDIA NAVIGATION MODE — IF EQUIPPED To enable Siri, push and hold, then release the Using Search Uconnect Voice Recognition (VR) button on the — I Press the Search button in the Main menu steering wheel. After you hear a double beep, PERATING AVIGATION to start searching.
Page 127 MULTIMEDIA Feature Description Back Button Press the Back button to return to the previous screen. Enter your search term in the search input box. As you type, matching addresses and Points of Interests Search Box (POI) are shown. Press this button to change the type of search to any of the following: Whole Map: Select this option to search your current map with no limit to the search radius.
Page 128 MULTIMEDIA Feature Description View Button Press this button to return to the map view or guidance view. Show/Hide Keyboard Button Press this button to show or hide the keyboard. List/Map Button Select this button to switch between showing the results in a list or showing the results on the map. Keyboard Layout Button Press this button to change your keyboard layout to another language.
Page 129 MULTIMEDIA Planning A Route — Searching For A City Center 2. Select the Points Of Interest tab. NOTE: The city center location is shown on the map. When planning a route to a city center, you can search for a town, city, or postal code. 4.
Page 130 MULTIMEDIA Planning A Route — Searching For A POI 3. To see more information about the POI, Planning A Route — Searching By Entering select the POI on the map and then select Coordinates You can search for a POI type, such as a the Pop-up Menu button.
Page 131 MULTIMEDIA Planning A Route Using My Places Finding A Parking Lot Finding A Gas Station 1. Press the Main Menu button. 1. Select the Main Menu button. 1. Press the Parking button from the Main Menu. 2. Select “My Places”. 2.
Page 132 MULTIMEDIA Changing Your Route Making Changes To Your Route After planning a route, the route and destination can be changed. There are various ways to change the route without the need to completely replan the entire journey. To change the current route, press the Current Route button in the main menu.
Page 133 MULTIMEDIA Route Option Description Press the button to avoid an unexpected obstacle that is blocking the road on the route. A new route will be found that avoids blocked roads. You may be shown a maximum of two alternatives depending on the road network between you and your destination.
Page 134 MULTIMEDIA Route Option Description Select the button to avoid some types of route features that are on your currently planned Avoid Toll Roads And More route. These include ferries, toll roads and unpaved roads. Press the button to see a list of turn-by-turn instructions for the planned route. The instructions include the following information: Current location ...
Page 135 MULTIMEDIA Route Option Description Press the button to change the type of route used to plan the route. The route will be recalculated using the new route type selected. You can select the following types of routes: Fastest Route  Change Route Type Shortest Route ...
Page 136 MULTIMEDIA Voice Command — If Equipped Using Voice Control 2. When you hear a beep, say a command of your choice. For example, you can say About Voice command WARNING! “Navigate home”. Instead of pressing the touchscreen to control ALWAYS drive safely with your hands on the NOTE: your navigation system, you can use your voice wheel.
Page 137 MULTIMEDIA Guidance View NOTE: When you have planned a route and the 3D The guidance view is used to guide you along guidance view is shown, select the switch view the route to your destination. As soon as you button to change to the map view and use the start driving, your navigation system will interactive features.
Page 138 MULTIMEDIA Feature Description Switch View Button Select the Switch View button to change between the map view and the guidance view. Press this button to view the following information: The direction of your next turn  Instruction Panel The distance to your next turn ...
Page 139 MULTIMEDIA Advanced Lane Guidance Map View The map view is shown when you have no NOTE: planned route. You can use map view the same Lane guidance is not available for all intersec- way as you might look at a traditional paper tions or in all countries.
Page 140 MULTIMEDIA Feature Description Press the Back button to return to an overview of the route. If no route is planned, Back Button pressing this button moves the map to put your current location at the center. Symbols are used on the map to show the destination and saved places Ú page 142. Map symbols include: Your destination ...
Page 141 MULTIMEDIA Voices Read Street Names Out Loud (if equipped): Appearance  Use this setting to control whether street To change how your navigation screen looks, About Voices names are read out loud as part of navigation select “Appearance” in the settings menu. From instructions.
Page 142 MULTIMEDIA Arrival Information Show Previews Of Highway Exits Voices Setting In the settings menu, select “Arrival Select this setting to control the full screen Select this setting to change how instructions Information” to change the following settings: preview when you approach highway exits. are read out loud Ú...
Page 143 MULTIMEDIA Fastest Route Sounds And Warnings NOTE:  This feature increases safety by minimizing Select this setting to change the following You can choose whether you would like the driver distraction. When driver safety is on, a sounds and warnings: navigation system to choose the fastest message tells you when the lock is enabled.
Page 144 MULTIMEDIA Points Of Interest Using Search NOTE: Your navigation system will calculate a route, 1. Select “Search” on the Main Menu to begin About Points Of Interest and guidance to your destination will begin. a search. The search screen will open, Guidance view will begin as soon as you start Points Of Interest (POI) are useful places on the displaying the keyboard.
Page 145 MULTIMEDIA Using My Places Adding A Location To My Places Adding A Location From The Map You can use My Places as a way of navigating to Adding From My Places 1. In Map View, move the map and zoom in a place without having to enter the address.
Page 146 MULTIMEDIA Adding A Location Using Search 3. To select a location for home, do one of the Deleting A Location From My Places following: 1. In the Main Menu, press “Search”. 1. In the main menu, select “My Places”. Zoom in on the map at the location ...
Page 147 MULTIMEDIA Important Safety Notices And Warnings Safety Settings The use of this material is subject to the terms of a license agreement. Any unauthorized We recommend using the safety settings to Global Positioning System copying or disclosure of this material will lead to make your driving as safe as possible.
Page 148 PERATION Pushing the top of the right-hand switch will The remote sound system controls are located Ram Telematics is designed to help improve “Scan” up for the next listenable station, and on the surface of the steering wheel. safety, efficiency, and productivity. It gives you...
Page 149 MULTIMEDIA Go to activate.verizonconnect.com/ram/ RF Exposure ELEMATICS ENERAL  #login. If you are an existing Verizon Connect NFORMATION This equipment complies with FCC and IC customer, enter your company’s log-in radiation exposure limits set forth for an Modification Statement credentials. New customers will need to uncontrolled environment.
Page 150 MULTIMEDIA RADIO OPERATION AND MOBILE PHONES The internal wireless radio operates within EGULATORY AFETY guidelines found in radio frequency safety NFORMATION Under certain conditions, the mobile phone standards and recommendations, which reflect being on in your vehicle can cause erratic or USA/CANADA the consensus of the scientific community.
Page 151 SAFETY SAFETY FEATURES WARNING! WARNING! (Continued) (ABS) The ABS contains sophisticated electronic RAKE YSTEM The ABS cannot prevent collisions,   equipment that may be susceptible to inter- including those resulting from excessive The ABS is designed to aid the driver in ference caused by improperly installed or speed in turns, following another vehicle maintaining vehicle control under adverse...
Page 152 SAFETY (EBC) Do not reduce brake pedal pressure unless applied, creating a steering effect that mitigates LECTRONIC RAKE ONTROL braking is no longer desired. Once the brake the cross wind influence. During system YSTEM pedal is released, the BAS is deactivated. intervention, the driver should perceive the Your vehicle is equipped with an advanced natural stable handling feel of the vehicle.
Page 153 SAFETY ESC uses sensors in the vehicle to determine ESC Operating Modes WARNING! (Continued) the vehicle path intended by the driver and compares it to the actual path of the vehicle. Vehicle modifications, or failure to properly  When the actual path does not match the maintain your vehicle, may change the intended path, ESC applies the brake of the handling characteristics of your vehicle,...
Page 154 SAFETY ESC Partial Off ESC Activation/Malfunction Indicator Light WARNING! And ESC OFF Indicator Light This mode is entered by momentarily pushing When in “Partial Off” mode, the TCS func-  the ESC OFF button. The ESC Activation/Malfunction tionality of ESC, (except for the limited slip Indicator Light in the instrument When in the “Partial Off”...
Page 155 SAFETY The ESC OFF Indicator Light indicates Hill Start Assist (HSA) HSA Activation Criteria that the Electronic Stability Control The HSA system is designed to assist the driver The following criteria must be met in order for (ESC) is in a reduced mode. when starting a vehicle from a stop on a hill.
Page 156 SAFETY Towing With HSA Traction Control System (TCS) WARNING! HSA will also provide assistance to mitigate roll TCS monitors the amount of wheel spin of each The TCS cannot prevent the natural laws of  back while towing a trailer. of the driven wheels.
Page 157 SAFETY AUXILIARY DRIVING SYSTEMS NOTE: The BSM detection zone covers approximately TSC cannot stop all trailers from swaying. one lane width on both sides of the vehicle 12 ft (BSM) — I Always use caution when towing a trailer and LIND ONITORING (3.8 m).
Page 158 SAFETY The vehicle’s taillights, where the radar sensors If the blockage message is still present after Entering From The Side are located, must remain free of snow, ice, and cycling the ignition and driving in traffic, check Vehicles that move into your adjacent lanes dirt/road contamination so that the BSM again for a blockage.
Page 159 SAFETY Entering From The Rear The BSM system will not alert you of objects that are traveling in the opposite direction of the Vehicles that come up from behind your vehicle vehicle in adjacent lanes Ú page 274. on either side and enter the rear detection zone with a relative speed of less than 30 mph (48 km/h).
Page 160 SAFETY Rear Cross Path (RCP) When RCP is on and the vehicle is in REVERSE Blind Spot Modes (R), the driver is alerted using both the visual RCP is intended to aid the driver when backing Blind Spot has three selectable modes of and audible alarms, including reducing the out of parking spaces where their vision of operation that are available in the Uconnect...
Page 161 SAFETY NOTE: The warnings and limited braking are intended the intervention of automatic braking, the trans- Whenever an audible alert is requested by the to provide the driver with enough time to react, mission may remain in last gear stored — there- BSM system, the radio is also muted.
Page 162 SAFETY NOTE: the driver is not braking adequately in the WARNING! event of a potential frontal collision, but The minimum speed for FCW activation is  Forward Collision Warning (FCW) is not maintains the audible and visual warnings. 3 mph (5 km/h). intended to avoid a collision on its own, nor When FCW status is set to “Warning and ...
Page 163 SAFETY More cautious drivers that do not mind FCW Limited Warning RESSURE ONITORING YSTEM  frequent warnings may prefer this (TPMS) If the instrument cluster displays “FCW Limited setting. Functionality” or “FCW Limited Functionality The Tire Pressure Monitoring System (TPMS) Clean Front Windshield”...
Page 164 SAFETY The TPMS will warn the driver of a low tire NOTE: CAUTION! pressure if the tire pressure falls below the When filling warm tires, the tire pressure may low-pressure warning limit for any reason, need to be increased up to an additional 4 psi The TPMS has been optimized for the orig- ...
Page 165 SAFETY NOTE: Base System Tire Pressure Monitoring Low Pressure Warnings This is the TPMS warning indicator The TPMS is not intended to replace normal  located in the instrument cluster. The Tire Pressure Monitoring System Warning tire care and maintenance or to provide Light will illuminate in the instrument cluster, an warning of a tire failure or condition.
Page 166 SAFETY OCCUPANT RESTRAINT SYSTEMS Check TPMS Warnings NOTE: Your vehicle is equipped with a regular size The Tire Pressure Monitoring System Warning Some of the most important safety features in spare wheel. Light will flash on and off for 75 seconds and your vehicle are the restraint systems: remain on solid when a system fault is detected, 1.
Page 167 SAFETY Here are some simple steps you can take to 6. All occupants should always wear their lap WARNING! (Continued) minimize the risk of harm from a deploying air and shoulder belts properly. bag: Never install a rear-facing child restraint in ...
Page 168 SAFETY Enhanced Seat Belt Use Reminder System front seat passenger is unbuckled (if equipped flat (if equipped). It is recommended that pets be with outboard front passenger seat BeltAlert) restrained in the rear seat (if equipped) in pet (BeltAlert) (the outboard front passenger seat BeltAlert is harnesses or pet carriers that are secured by seat Driver and Passenger BeltAlert —...
Page 169 SAFETY WARNING! WARNING! WARNING! (Continued) Relying on the air bags alone could lead to A lap belt worn too high can increase the Be sure everyone in your vehicle is in a seat    more severe injuries in a collision. The air risk of injury in a collision.
Page 170 SAFETY Lap/Shoulder Belt Operating Instructions WARNING! (Continued) 1. Enter the vehicle and close the door. Sit A seat belt that is worn under your arm is  back and adjust the seat. dangerous. Your body could strike the inside surfaces of the vehicle in a collision, 2.
Page 171 SAFETY Lap/Shoulder Belt Untwisting Procedure Adjustable Upper Shoulder Belt Anchorage Use the following procedure to untwist a twisted In the driver and outboard front passenger lap/shoulder belt. seats, the top of the shoulder belt can be adjusted upward or downward to position the 1.
Page 172 SAFETY As a guide, if you are shorter than average, you To verify the shoulder belt anchorage is latched, Seat Belts And Pregnant Women will prefer the shoulder belt anchorage in a pull downward on the shoulder belt anchorage lower position, and if you are taller than until it is locked into position.
Page 173 SAFETY Seat Belt Pretensioner Switchable Automatic Locking Retractor (ALR) The front seat belt system is equipped with pretensioning devices that are designed to The seat belt in the passenger seating position remove slack from the seat belt in the event of is equipped with a Switchable Automatic a collision.
Page 174 SAFETY In Automatic Locking Mode, the shoulder belt is How To Engage The Automatic Locking Mode WARNING! (Continued) automatically pre-locked. The seat belt will still 1. Buckle the combination lap and shoulder retract to remove any slack in the shoulder belt. Failure to replace the seat belt assembly ...
Page 175 SAFETY Air Bag System Components The ORC contains a backup power supply The Air Bag Warning Light remains on after  system that may deploy the air bag system even the four to eight-second interval. Occupant Restraint Controller (ORC)  if the battery loses power or it becomes The Air Bag Warning Light comes on intermit- ...
Page 176 SAFETY Front Air Bags information from the front impact sensors (if WARNING! equipped) or other system components. This vehicle has front air bags and lap/shoulder Being too close to the steering wheel or  belts for both the driver and front passenger. WARNING! instrument panel during front air bag The front air bags are a supplement to the seat...
Page 177 SAFETY Front Air Bag Operation The steering wheel hub trim cover and the upper passenger side of the instrument panel Front Air Bags are designed to provide separate and fold out of the way as the air bags additional protection by supplementing the seat inflate to their full size.
Page 178 SAFETY Supplemental Side Air Bag Inflatable Curtains edge of the headliner out of the way and covers Side Impacts (SABICs) the window. The SABICs inflate with enough The Side Air Bags are designed to activate in force to injure occupants if they are not belted This vehicle is equipped with Supplemental certain side impacts.
Page 179 SAFETY Side Air Bags are a supplement to the seat belt Rollover Events WARNING! restraint system. Side Air Bags deploy in less Side Air Bags and seat belt pretensioners are time than it takes to blink your eyes. Side Air Bags need room to inflate. Do not ...
Page 180 SAFETY Air Bag System Components If A Deployment Occurs eye irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air. The front air bags are designed to deflate NOTE: If the irritation continues, see your doctor. If immediately after deployment.
Page 181 SAFETY Fuel Cut Off Switch damage to the vehicle electrical devices (e.g. WARNING! headlights) after an accident, reset the Fuel Cut Your vehicle is equipped with a Fuel Cut Off Off Switch by following the procedure described If, after an accident, you smell fuel or see switch.
Page 182 SAFETY Event Data Recorder (EDR) NOTE: WARNING! (Continued) EDR data are recorded by your vehicle only if a This vehicle is equipped with an event data non-trivial crash situation occurs; no data are It is dangerous to try to repair any part of ...
Page 183 SAFETY There are different sizes and types of restraints NOTE: HILD ESTRAINTS for children from newborn size to the child Everyone in your vehicle needs to be buckled up For additional information, refer to http://  almost large enough for an adult safety belt. www.nhtsa.gov/parents-and-caregivers or at all times, including babies and children.
Page 184 SAFETY Summary Of Recommendations For Restraining Children In Vehicles Child Size, Height, Weight Or Age Recommended Type Of Child Restraint Children who are two years old or younger and Either an Infant Carrier or a Convertible Child Infants and Toddlers who have not reached the height or weight limits Restraint, facing rearward in a rear seat of the of their child restraint...
Page 185 SAFETY Infant And Child Restraints Older Children And Child Restraints WARNING! Safety experts recommend that children ride Children who are two years old or who have Never place a rear-facing child restraint in  rear-facing in the vehicle until they are two years outgrown their rear-facing convertible child seat front of an air bag.
Page 186 SAFETY Children Too Large For Booster Seats the seat belt buckle is latched. A child’s squirming WARNING! or slouching can move the belt out of position. If Children who are large enough to wear the Improper installation can lead to failure of the shoulder belt contacts the face or neck, move ...
Page 187 SAFETY the passenger seat should be moved to the full WARNING! (Continued) rearward position and the child must be in a proper restraint system based on its age, size Follow the child restraint manufacturer’s  and weight. Follow the instructions below to directions exactly when installing an infant secure the child restraint using the seat belt.
Page 188 SAFETY SAFETY TIPS Installing A Child Restraint With A 4. Pull on the webbing to make the lap portion tight against the child seat. Switchable Automatic Locking Retractor RANSPORTING ASSENGERS (ALR) 5. To lock the seat belt, pull down on the Child restraint systems are designed to be NEVER TRANSPORT PASSENGERS IN THE shoulder part of the belt until you have...
Page 189 SAFETY Air Bag Warning Light fasteners so it cannot slip out of position and RANSPORTING interfere with the accelerator, brake or clutch The Air Bag Warning Light will turn on for four Air Bags deploying in the front seat could harm pedals or impair safe operation of your vehicle to eight seconds as a bulb check when the your pet.
Page 190 SAFETY ERIODIC AFETY HECKS HOULD WARNING! (Continued) WARNING! (Continued) UTSIDE EHICLE ONLY install floor mats designed to fit your NEVER place any objects under the floor   vehicle. NEVER install a floor mat that mat (e.g., towels, keys, etc.). These objects Tires cannot be properly attached and secured to could change the position of the floor mat...
Page 191 SAFETY Fluid Leaks ARBON ONOXIDE ARNINGS WARNING! (Continued) Check area under the vehicle after overnight If it is necessary to sit in a parked vehicle WARNING!  parking for fuel, coolant, oil, or other fluid leaks. with the engine running, adjust your Also, if gasoline fumes are detected or if fuel or Carbon monoxide (CO) in exhaust gases is heating or cooling controls to force outside...
Page 192 IN CASE OF EMERGENCY HAZARD WARNING FLASHERS JACKING AND TIRE CHANGING Push the switch to turn on the Hazard Warning Flashers. When the switch is activated, all The Hazard Warning Flashers switch is located directional turn signals will flash on and off to WARNING! on the instrument panel below the climate warn oncoming traffic of an emergency.
Page 193 IN CASE OF EMERGENCY 6. Block both the front and rear of the wheel REPARATIONS ACKING OCATION diagonally opposite the jacking position. For The jack and jack tools are stored under the 1. Park the vehicle on a firm, level surface. example, if the driver’s front wheel is being front passenger seat in a box, or next to or Avoid ice or slippery areas.
Page 194 IN CASE OF EMERGENCY To release the jack kit from its storage location, To open the jack kit container, you must push turn the lock knob a quarter turn the container’s release to separate the top and counterclockwise to the unlock position. bottom.
Page 195 IN CASE OF EMERGENCY NOTE: PARE EMOVAL The winch mechanism is designed for use with 1. Remove the spare tire before attempting to the winch extension tube only. Use of an air jack up the vehicle. Attach the lug bolt wrench or other power tools is not recom- adapter to the winch extension and insert mended and can damage the winch.
Page 196 IN CASE OF EMERGENCY WARNING! (Continued) Never start or run the engine with the  vehicle on a jack. Do not let anyone sit in the vehicle when it  is on a jack. Do not get under the vehicle when it is on a ...
Page 197 IN CASE OF EMERGENCY 1. Loosen (but do not remove) the wheel lug NOTE: bolts by turning them counterclockwise The rear jacking location is located in front of one turn while the wheel is still on the the rear tire and in front of the leaf spring mount.
Page 198 IN CASE OF EMERGENCY WARNING! WARNING! Being under a jacked-up vehicle is Raising the vehicle higher than necessary can dangerous. The vehicle could slip off the jack make the vehicle less stable. It could slip off and fall on you. You could be crushed. Never the jack and hurt someone near it.
Page 199 IN CASE OF EMERGENCY 10. Install the winch extension and rotate the HEEL OVERS WARNING! wrench handle clockwise until the winch To avoid the risk of forcing the vehicle off the mechanism operator hears “3 clicks” from CAUTION! the device to indicate the wheel is properly jack, do not tighten the wheel nuts fully until Use a back-and-forth motion to remove the the vehicle has been lowered.
Page 200 IN CASE OF EMERGENCY Using The Mode Select Knob And Hoses Using The Deflation Button ERVICE TORAGE  Your Tire Service Kit is equipped with the Push the Deflation Button (9) to The Tire Service Kit is located under the following symbols to indicate the air or sealant reduce the air pressure in the tire if passenger seat or the driver side door.
Page 201 IN CASE OF EMERGENCY When the Tire Service Kit sealant is in a liquid  WARNING! WARNING! (Continued) form, clean water and a damp cloth will remove the material from the vehicle or tire Do not attempt to seal a tire on the side of A loose Tire Service Kit thrown forward in a ...
Page 202 IN CASE OF EMERGENCY (B) Setting Up To Use Tire Service Kit: (C) Injecting Tire Service Kit Sealant Into EALING ERVICE The Deflated Tire: 1. Push in the Mode Select Knob (2) and turn (A) Whenever You Stop To Use Tire Service Always start the engine before turning ON the ...
Page 203 IN CASE OF EMERGENCY Check that the Mode Select Knob (2) is in will decrease quickly from approximately If the tire inflates to the recommended pressure the Sealant Mode position and not Air 70 psi (4.8 Bar) to the actual tire pressure or is at least 26 psi (1.8 Bar) pressure within Mode.
Page 204 IN CASE OF EMERGENCY (D) Drive Vehicle: 3. Uncoil the Air Pump Hose (5) (black in color) 4. Have the tire inspected and repaired or and screw the fitting at the end of hose onto replaced at the earliest opportunity at an Immediately after injecting sealant and inflating the valve stem.
Page 205 IN CASE OF EMERGENCY 5. Position the new Sealant Bottle (4) in the NOTE: The Remote Negative (-) Post is located on the housing so that the Sealant Hose (3) aligns When using a portable battery booster pack, core support closest to the front of the vehicle. with the hose slot in the front of the follow the manufacturer’s operating instruc- tions and precautions.
Page 206 IN CASE OF EMERGENCY Connecting The Jumper Cables WARNING! WARNING! (Continued) Do not allow vehicles to touch each other as Batteries contain sulfuric acid that can  burn your skin or eyes and generate this could establish a ground connection and hydrogen gas which is flammable and personal injury could result.
Page 207 IN CASE OF EMERGENCY 2. Connect the opposite end of the positive (+) 5. Start the engine in the vehicle that has the 5. Close the cover of the Front Power Distri- jumper cable to the positive (+) post of the booster battery.
Page 208 IN CASE OF EMERGENCY IF YOUR ENGINE OVERHEATS If your Air Conditioner (A/C) is on, turn it off. ATTERY OCATION  The A/C system adds heat to the engine There are two remote jump starting posts under If the vehicle is overheating, it will need to be cooling system and turning the A/C off can the hood which is the recommended jump start serviced by an authorized dealer.
Page 209 IN CASE OF EMERGENCY GEAR SELECTOR OVERRIDE 5. Insert the screwdriver or similar tool into the WARNING! access port, and push and hold the override If a malfunction occurs and the gear selector You or others can be badly burned by hot release lever forward.
Page 210 IN CASE OF EMERGENCY FREEING A STUCK VEHICLE NOTE: CAUTION! Push the “ESC OFF” switch, to place the If your vehicle becomes stuck in mud, sand, or Electronic Stability Control System (ESC) in When “rocking” a stuck vehicle by shifting ...
Page 211 IN CASE OF EMERGENCY TOWING A DISABLED VEHICLE This section describes procedures for towing a disabled vehicle using a commercial towing service. Towing Condition Wheels OFF The Ground ALL Models Flat Tow NONE If transmission is operable: • Transmission in NEUTRAL •...
Page 212 IN CASE OF EMERGENCY ENHANCED ACCIDENT RESPONSE SYSTEM UTOMATIC RANSMISSION CAUTION! (EARS) The FCA US LLC recommends towing your Towing faster than 25 mph (40 km/h) or  vehicle with all four wheels OFF the ground farther than 15 miles (24 km) with front This vehicle is equipped with an Enhanced using a flatbed.
Page 213 SERVICING AND MAINTENANCE SCHEDULED SERVICING An authorized dealer will reset the oil change Severe Duty All Models indicator message after completing the Vehicles that are operated in a dusty and off-road Your vehicle is equipped with an automatic oil scheduled oil change. If a scheduled oil change environment, or predominately at idle or very low change indicator system.
Page 214 SERVICING AND MAINTENANCE AINTENANCE Refer to the maintenance plan for the required maintenance intervals. More frequent maintenance may be needed in severe conditions, such as dusty areas and very short trip driving. In some extreme conditions, additional maintenance not specified in the maintenance schedule may be required. At Every Oil Change Interval As Indicated By Oil Change Indicator System: Change oil and filter.
Page 215 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV/Universal joints. Inspect front suspension, tie rod ends, boot seals, and replace if necessary. Inspect the brake pads, replace as necessary. Additional Maintenance Replace the engine air filter.
Page 216 SERVICING AND MAINTENANCE Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Flush and replace the engine coolant at 10 years or 150,000 miles (240,000 km) whichever comes first. Change the automatic transmission fluid and filter. Inspect and replace the PCV valve if necessary.
Page 217 SERVICING AND MAINTENANCE ENGINE COMPARTMENT 3.6L E NGINE 1 — Washer Fluid Reservoir Cap 5 — Power Distribution Center (Fuses) 2 — Engine Oil Fill 6 — Coolant Reservoir Cap 3 — Engine Oil Dipstick 7 — Power Steering Reservoir Cap 4 —...
Page 218 SERVICING AND MAINTENANCE There are four possible dipstick types: HECKING EVEL CAUTION! (Continued) Crosshatched zone.  If the engine oil is being topped up, wait for WARNING!  Crosshatched zone marked SAFE. the engine to cool down before loosening  Never smoke while working in the engine ...
Page 219 SERVICING AND MAINTENANCE DDING ASHER LUID AINTENANCE ATTERY CAUTION! The fluid reservoir is located in the engine Your vehicle is equipped with a It is essential when replacing the cables on  compartment and should be checked at regular maintenance-free battery. You will never have the battery that the positive cable is intervals.
Page 220 SERVICING AND MAINTENANCE VEHICLE MAINTENANCE Synthetic Engine Oils NGINE You may use synthetic engine oils provided the An authorized dealer has the qualified service Engine Oil Selection recommended oil quality requirements are met, personnel, special tools, and equipment to For best performance and maximum protection and the recommended maintenance intervals perform all service operations in an expert under all types of operating conditions, FCA only...
Page 221 SERVICING AND MAINTENANCE NGINE ILTER WARNING! WARNING! The engine oil filter should be replaced with a The air induction system (air cleaner, hoses, Use only refrigerants and compressor lubri-  new filter at every engine oil change. cants approved by the manufacturer for etc.) can provide a measure of protection in the Engine Oil Filter Selection case of engine backfire.
Page 222 SERVICING AND MAINTENANCE Refrigerant Recovery And Recycling The cabin air filter is located in the fresh air inlet in the engine compartment. Perform the R-134a Air Conditioning Refrigerant is a following procedure to replace the filter: hydrofluorocarbon (HFC) that is an ozone-saving product.
Page 223 SERVICING AND MAINTENANCE UBRICATION INDSHIELD IPER LADES XHAUST YSTEM Locks and all body pivot points, including such Clean the rubber edges of the wiper blades and The best protection against carbon monoxide items as seat tracks, door hinge pivot points the windshield periodically with a sponge or soft entry into the vehicle body is a properly and rollers, liftgate, tailgate, decklid, sliding...
Page 224 SERVICING AND MAINTENANCE In unusual situations involving grossly WARNING! CAUTION! (Continued) malfunctioning engine operation, a scorching Exhaust gases can injure or kill. They odor may suggest severe and abnormal catalyst Damage to the catalytic converter can   contain carbon monoxide (CO), which is result if your vehicle is not kept in proper overheating.
Page 225 SERVICING AND MAINTENANCE Coolant Checks Selection Of Coolant OOLING YSTEM Check the engine coolant (antifreeze) For further information Ú page 268. WARNING! protection every 12 months (before the onset of NOTE: freezing weather, where applicable). If the You or others can be badly burned by hot ...
Page 226 SERVICING AND MAINTENANCE This vehicle has not been designed for use Please review these recommendations for Some vehicles require special tools to add   with propylene glycol-based engine coolant. coolant properly. Failure to fill these systems using OAT engine coolant that meets the Use of propylene glycol-based engine coolant requirements of FCA Material Standard properly could lead to severe internal engine...
Page 227 SERVICING AND MAINTENANCE Coolant Level the coolant expansion bottle must also be WARNING! protected against freezing. The coolant expansion bottle provides a quick Do not open hot engine cooling system.  visual method for determining that the coolant If frequent engine coolant additions are ...
Page 228 SERVICING AND MAINTENANCE However, an unexpected drop in fluid level may RAKE YSTEM WARNING! (Continued) be caused by a leak and a system check should In order to ensure brake system performance, be conducted Ú page 268. Overfilling the brake fluid reservoir can ...
Page 229 SERVICING AND MAINTENANCE transmission fluid at the correct level using the exception to this policy is the use of special dyes immediately to have the transmission fluid level recommended fluid. No chemical flushes should for diagnosing fluid leaks in six-speed checked.
Page 230 SERVICING AND MAINTENANCE FUSES CAUTION! General Information If it is necessary to wash the engine compartment, take care not to directly hit the WARNING! fuse box, and the windshield wiper motors with water. When replacing a blown fuse, always use ...
Page 231 SERVICING AND MAINTENANCE Underhood Fuses The ID number of the electrical component corresponding to each fuse can be found on the The Front Power Distribution Center is located back of the cover. on the driver’s side of the engine compartment. To access the fuses, remove the cover.
Page 232 SERVICING AND MAINTENANCE Cavity Maxi Fuse Mini Fuse Description – 15 Amp Blue Horn – 20 Amp Yellow Power Outlet – 7.5 Amp Brown USB Charger KL15 Shifter Transmission Module (STM) (3.6), KL15 Starter Relay – 7.5 Amp Brown Coil (3.6 Gasoline Engine) –...
Page 233 SERVICING AND MAINTENANCE Front PDC Additional Fuses The additional fuse box is located inside the front PDC Box. Front Power Distribution Center Additional Fuses Cavity Mini Fuse Description 20 Amp Yellow Vacuum Pump (3.6 Gasoline Engine) 30 Amp Green Transmission Power RELE (3.6 Gasoline Engine) 5 Amp Beige Shifter Transmission Module (STM) (3.6 Gasoline Engine)
Page 234 SERVICING AND MAINTENANCE Interior Fuses The interior fuse panel is part of the Body Control Module (BCM) and is located on the driver's side under the instrument panel. Fuse Panel Fuse Panel Cavity Locations Cavity Mini Fuse Description 5 Amp Beige INT/A 7.5 Amp Brown Clearance Lights...
Page 235 SERVICING AND MAINTENANCE Cavity Mini Fuse Description 15 Amp Blue Central Locking 5 Amp Beige INT (BSM – SAS – BRAKE NC) / DASM 20 Amp Yellow Bi-Directional Washer Pump 20 Amp Yellow Driver Power Window 20 Amp Yellow Passenger Power Window 5 Amp Beige INT (PAM –...
Page 236 SERVICING AND MAINTENANCE Right Central Pillar Fuses The right central pillar fuse panel is located on the interior side at the base of the passenger side B-pillar. Fuse Panel Location Fuse Panel Cavity Mini Fuse Description 7.5 Amp Brown Seat Heater 20 Amp Yellow Rear Left Windows Heater 20 Amp Yellow...
Page 237 SERVICING AND MAINTENANCE BULB REPLACEMENT Replacement Bulbs Interior Bulbs Bulb Name Bulb Number Dome Lamp Courtesy Lamp FF500 Cargo Lamp Exterior Bulbs Bulb Name Bulb Number Front Low and High Beam Headlamp H7SLL Front Park/Turn Signal Lamps 7444NA Daytime Running Lamps (If Equipped) 7440 Front Side Marker Lamps Rear Tail/Stop Lamps...
Page 238 SERVICING AND MAINTENANCE Exterior Bulbs Bulb Name Bulb Number Front Fog Lamps License Plate Lamps Front Roof Lamps WY5W Rear Roof Lamps NOTE: Numbers refer to commercial bulb types that can be purchased from an authorized dealer. If a bulb needs to be replaced, visit an authorized dealer. Replacing Exterior Bulbs 5.
Page 239 SERVICING AND MAINTENANCE Front Turn Signal/Parking Lamps 10. Install the two lower retaining screws on 7. Replace lamp as required and lock in place. headlamp housing. See below steps to replace: 8. Reinstall plastic cap. 11. Carefully reinstall the lower headlamp filler 1.
Page 240 SERVICING AND MAINTENANCE 4. Connect the wire and rotate bulb/socket Replacing Interior Bulbs clockwise into lamp locking it in place. Cargo Lamp 5. Reinstall the plastic cap and close the cover See below steps to replace: on the wheel liner. 1.
Page 241 SERVICING AND MAINTENANCE 3. Remove and replace the bulbs as needed. Cargo Lamp Bulb Location Dome Lamp Assembly Location 1 — Spring Tension Relief Access 3. Remove and install the replacement bulb. Dome Lamp Light Bulbs 2 — Dome Lamp Assembly 4.
Page 242 SERVICING AND MAINTENANCE TIRES LT (Light Truck) — Metric tire sizing is based 1 — US DOT Safety Standards Code (TIN)  on US design standards. The size designation 2 — Size Designation for LT-Metric tires is the same as for P-Metric AFETY NFORMATION 3 —...
Page 243 SERVICING AND MAINTENANCE Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on US design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on US design standards, or T or S = Temporary spare tire or 31 = Overall diameter in inches (in)
Page 244 SERVICING AND MAINTENANCE EXAMPLE: Service Description: 95 = Load Index A numerical code associated with the maximum load a tire can carry  H = Speed Symbol A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions ...
Page 245 SERVICING AND MAINTENANCE Tire Identification Number (TIN) The TIN may be found on one or both sides of the tire; however, the date code may only be on one side. Tires with white sidewalls will have the full TIN, including the date code, located on the white sidewall side of the tire. Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle.
Page 246 SERVICING AND MAINTENANCE Tire Terminology And Definitions Term Definition B-pillar The vehicle B-pillar is the structural member of the body located behind the front door. Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a Cold Tire Inflation Pressure minimum of three hours.
Page 247 SERVICING AND MAINTENANCE Tire Loading And Tire Pressure This placard tells you important information about the: NOTE: 1. Number of people that can be carried in The proper cold tire inflation pressure is listed the vehicle. on the driver’s side B-Pillar or the rear edge of the driver's side door.
Page 248 SERVICING AND MAINTENANCE NOTE: (3) Subtract the combined weight of the Metric Example For Load Limit Under a maximum loaded vehicle condition, driver and passengers from XXX kg or For example, if “XXX” amount equals 635 kg gross axle weight ratings (GAWRs) for the front XXX lbs.
Page 249 SERVICING AND MAINTENANCE...
Page 250 SERVICING AND MAINTENANCE Safety Both underinflation and overinflation affect the WARNING! stability of the vehicle and can produce a feeling WARNING! Overloading of your tires is dangerous. of sluggish response or over responsiveness in Overloading can cause tire failure, affect the steering.
Page 251 SERVICING AND MAINTENANCE Tire Inflation Pressures three hours. The cold tire inflation pressure Tire Pressures For High Speed Operation must not exceed the maximum inflation The proper cold tire inflation pressure is listed The manufacturer advocates driving at safe pressure molded into the tire sidewall. on the driver's side B-pillar or rear edge of the speeds and within posted speed limits.
Page 252 SERVICING AND MAINTENANCE Radial Ply Tires Index and Speed Symbol). Replace the tire Tire Spinning pressure sensor as well as it is not designed to When stuck in mud, sand, snow, or ice WARNING! be reused. conditions, do not spin your vehicle's wheels Combining radial ply tires with other types of above 30 mph (48 km/h) or for longer than Run Flat Tires —...
Page 253 SERVICING AND MAINTENANCE Tread Wear Indicators Life Of Tire NOTE: Wheel Valve Stem must be replaced as well Tread wear indicators are in the original The service life of a tire is dependent upon when installing new tires due to wear and tear equipment tires to help you in determining varying factors including, but not limited to: in existing tires.
Page 254 SERVICING AND MAINTENANCE It is recommended to replace the two front tires failure to do so may adversely affect the safety WARNING! (Continued) or two rear tires as a pair. Replacing just one tire and handling of your vehicle. can seriously affect your vehicle’s handling. If Never use a tire with a smaller load index or ...
Page 255 SERVICING AND MAINTENANCE — I Snow Tires vehicle. If your vehicle has this option, refer to PARE IRES QUIPPED an authorized tire dealer for the recommended Some areas of the country require the use of NOTE: tire rotation pattern. snow tires during the Winter. Snow tires can be For vehicles equipped with Tire Service Kit instead identified by a “mountain/snowflake”...
Page 256 SERVICING AND MAINTENANCE Do not install a wheel cover or attempt to mount Collapsible Spare Tire — If Equipped Do not install a wheel cover or attempt to mount a conventional tire on the compact spare wheel, a conventional tire on the collapsible spare The collapsible spare is for temporary since the wheel is designed specifically for the wheel, since the wheel is designed specifically...
Page 257 SERVICING AND MAINTENANCE Full Size Spare — If Equipped Limited Use Spare — If Equipped HEEL HEEL The full size spare is for temporary emergency The limited use spare tire is for temporary All wheels and wheel trim, especially aluminum use only.
Page 258 SERVICING AND MAINTENANCE Dark Vapor Chrome, Black Satin Chrome, or CAUTION! CAUTION! Low Gloss Clear Coat Wheels Avoid products or automatic car washes that Do not use scouring pads, steel wool, a bristle CAUTION! use acidic solutions or strong alkaline brush, metal polishes or oven cleaner.
Page 259 SERVICING AND MAINTENANCE RACTION EVICES Use of traction devices require sufficient tire-to-body clearance. Due to limited clearance the following traction devices are recommended. Follow these recommendations to guard against damage. Snow traction device must be of proper size for the tire, as recommended by the traction device manufacturer. ...
Page 260 SERVICING AND MAINTENANCE Refer to the Maintenance Plan for the proper CAUTION! CAUTION! (Continued) maintenance intervals Ú page 212. The To avoid damage to your vehicle or tires, reasons for any rapid or unusual wear should be Observe the traction device manufacturer’s ...
Page 261 SERVICING AND MAINTENANCE DEPARTMENT OF TRANSPORTATION the norm due to variations in driving habits, its ability to dissipate heat, when tested service practices, and differences in road under controlled conditions on a UNIFORM TIRE QUALITY GRADES characteristics and climate. specified indoor laboratory test wheel. The following tire grading categories Sustained high temperature can cause RACTION...
Page 262 SERVICING AND MAINTENANCE STORING THE VEHICLE Outside parking, which exposes your vehicle to NDERBODY AINTENANCE airborne contaminants, road surfaces on which If you are storing your vehicle for more than Cleaning Headlights the vehicle is operated, extreme hot or cold 3 weeks, we recommend that you take the weather, and other extreme conditions will have Your vehicle is equipped with plastic headlights...
Page 263 SERVICING AND MAINTENANCE If a lot of driving is done on gravel roads, RESERVING ODYWORK  CAUTION! (Continued) consider mud or stone shields behind each Washing wheel. Use of power washers exceeding 1,200 psi  (8,274 kPa) can result in damage or Wash your vehicle regularly.
Page 264 SERVICING AND MAINTENANCE Stain Repel Fabric Cleaning Procedure — If Seat Belt Maintenance LASTIC OATED ARTS Equipped Do not bleach, dye or clean the belts with Use Mopar Total Clean to clean vinyl upholstery. chemical solvents or abrasive cleaners. This will Stain Repel seats may be cleaned in the weaken the fabric.
Page 265 SERVICING AND MAINTENANCE EATHER URFACES LEANING NSTRUMENT ANEL CAUTION! UPHOLDERS Mopar Total Clean is specifically recommended Do not use Alcohol and Alcohol-based and/or for leather upholstery. Ketone based cleaning products to clean Removal Your leather upholstery can be best preserved leather upholstery, as damage to the Pull the flexible liner from the cupholder drawer by regular cleaning with a damp soft cloth.
Page 266 TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION NUMBER BRAKE SYSTEM WHEEL AND TIRE TORQUE SPECIFICATIONS The Vehicle Identification Number (VIN) is found Your vehicle is equipped with dual hydraulic Proper lug nut/bolt torque is very important to on the left front corner of the instrument panel, brake systems.
Page 267 TECHNICAL SPECIFICATIONS FUEL REQUIREMENTS Inspect the wheel mounting surface prior to mounting the tire and remove any corrosion or While operating on gasoline with the required loose particles. octane number, hearing a light knocking sound from the engine is not a cause for concern. However, if the engine is heard making a heavy knocking sound, see a dealer immediately.
Page 268 TECHNICAL SPECIFICATIONS Visit www.toptiergas.com for a list of TOP TIER Problems that result from using gasoline EFORMULATED ASOLINE Detergent Gasoline Retailers. containing more than 15% ethanol (E-15) or Many areas of the country require the use of gasoline containing methanol are not the Indiscriminate use of fuel system cleaning cleaner burning gasoline referred to as responsibility of the manufacturer and may void...
Page 269 TECHNICAL SPECIFICATIONS CNG A LP F gasoline pump; therefore, you should ask your YSTEM CAUTION! (Continued) gasoline retailer whether the gasoline contains ODIFICATIONS MMT. MMT is prohibited in Federal and The use of fuel additives, which are now  Modifications that allow the engine to run on California reformulated gasoline.
Page 270 TECHNICAL SPECIFICATIONS FLUID CAPACITIES Metric Fuel (Approximate) 24 Gallons 90 Liters Engine Oil With Filter 3.6L Engine 6 Quarts 5.6 Liters Cooling System 3.6L Engine 10.5 Quarts 10 Liters ENGINE FLUIDS AND LUBRICANTS Component Fluid, Lubricant, or Genuine Part We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile (240,000 km) Formula Engine Coolant OAT (Organic Additive Technology) meeting the requirements of FCA Material Standard MS.90032.
Page 271 TECHNICAL SPECIFICATIONS CAUTION! CAUTION! (Continued) Mixing of engine coolant (antifreeze) other Do not use water alone or alcohol-based   than specified Organic Additive Technology engine coolant (antifreeze) products. Do (OAT) engine coolant (antifreeze), may not use additional rust inhibitors or antirust result in engine damage and may decrease products, as they may not be compatible corrosion protection.
Page 272 TECHNICAL SPECIFICATIONS CHASSIS FLUIDS AND LUBRICANTS Component Fluid, Lubricant, Or Genuine Part Use Only ATF+4 Automatic Transmission Fluid. Failure to use ATF+4 fluid Automatic Transmission may affect the function or performance of your transmission. We recommend Mopar ATF+4 Fluid. We recommend you use Mopar DOT 4. DOT 4 brake fluid must be Brake Master Cylinder changed every two years regardless of mileage.
Page 273 CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING SERVICE the facilities, factory-trained technicians, EASONABLE EQUESTS special tools, and the latest information to FOR YOUR VEHICLE If you list a number of items and you must have ensure the vehicle is fixed correctly and in a your vehicle by the end of the day, discuss the timely manner.
Page 274 CUSTOMER ASSISTANCE FCA US LLC C warranty. If you purchased a Mopar Vehicle USTOMER ENTER USTOMER SSISTANCE Protection Plan, you will receive Plan Provisions (TDD/ EARING PEECH MPAIRED P.O. Box 21–8004 and an Owner Identification Card in the mail TTY) Auburn Hills, MI 48321–8004 within three weeks of the vehicle delivery date.
Page 275 CUSTOMER ASSISTANCE REPORTING SAFETY DEFECTS To contact NHTSA, you may call the WARNING! Vehicle Safety Hotline toll free at 50 U Engine exhaust (internal combustion engines NITED TATES 1-888-327-4236 (TTY: only), some of its constituents, and certain , D.C. ASHINGTON 1-800-424-9153);...
Page 276 CUSTOMER ASSISTANCE PUBLICATION ORDER FORMS To access your Owner's Information online, visit Cet appareil est conforme au RSS - 310 d www.mopar.com/om 'Industrie Canada. Le fonctionnement est To order the following manuals, you may use soumis à la condition que cet appareil ne To order a hard copy of your Owner's either the website or the phone numbers listed provoque pas d'interférences nuisibles et...
Page 277 INDEX Alarm ....224 ........13 ........... 48 Adding Engine Coolant (Antifreeze) Security Alarm Battery ........217 .........48 Adding Washing Fluid Alarm System Charging System Light ..........266 ..........13 ....11 Additives, Fuel Security Alarm Keyless Key Fob Replacement ......121 ............ 187 Advance Phone Connectivity Alterations/Modifications Belts, Seat ............174...
Page 278 ..........31 ......55 Climate Control Diagnostic System, Onboard ..........73 ............31 ........29 Camera, Rear Manual Dimmer Control Switch ..........268 .............34 Capacities, Fluid Rear Dimmer Switch ........57 .............26 Caps, Filler Cold Weather Operation Headlight ............. 75 ........253 Fuel Compact Spare Tire Dipsticks ..........215 ..........
Page 279 Emergency, In Case Of Ethanol ............266 Four-Way Hazard Flasher ......190 Freeing Vehicle When Stuck ......208 Exhaust Gas Cautions ........189 Freeing A Stuck Vehicle ......... 208 Jacking ............190 Exhaust System ........189 Fuel ............... 265 Jump Starting ..........203 Exterior Lights .........26 Additives...
Page 280 ........12 Immobilizer (Sentry Key) ........23 ..........27 Hazard Inside Rearview Mirror Lane Change Assist ........42 ........166 Driving Through Flowing, Rising, Or Instrument Cluster Lap/Shoulder Belts ......86 ............44 ............188 Shallow Standing Water Display Latches ......190 ....262 ............40 Hazard Warning Flashers Instrument Panel Lens Cleaning Hood...
Page 281 Security Alarm ..........50 Modifications/Alterations Synthetic ........... 218 Service ............235 Vehicle ............7 Viscosity ............ 268 Tire Pressure Monitoring (TPMS) ....161 Monitor, Tire Pressure System ...... 161 Onboard Diagnostic System ......55 Traction Control .........152 Mopar Parts ..........273 Operating Precautions ........55 Turn Signals ........
Page 282 ........189 ........271 Safety, Exhaust Gas Service Assistance ..........250 ..........102 ..........272 Radial Ply Tires Satellite Radio Service Contract ....224 ........ 211 ........... 274 Radiator Cap (Coolant Pressure Cap) Schedule, Maintenance Service Manuals ..........165 Radio Frequency Seat Belts Settings ........148 ......
Page 283 Storing Your Vehicle ........260 Safety ..........240 Transmission Supplemental Restraint System – Air Bag ..174 Sizes ............241 Automatic .......... 60 Sway Control, Trailer ........154 Snow Tires ..........253 Fluid ............270 Synthetic Engine Oil ........218 Spare Tires ........253 Maintenance ..........
Page 284 ..........261 Making A Phone Or Audio Device A Uconnect Settings Washing Vehicle ..........117 .....89 Favorite Customer Programmable Features Water ......259 ...........86 Making A Second Call While Current Uniform Tire Quality Grades Driving Through .........120 ........265 ......255 Call Is In Progress Unleaded Gasoline Wheel And Wheel Tire Care...
