Summary of Contents for RAM 2011 Ram Truck 1500

Page 1 RAM TRUCK 2 0 1 1 1 5 0 0 / 2 5 0 0 / 3 5 0 0 O W N E R ’ S M A N U A L...
Page 2 With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and features and equipment that are either standard or op- the name Chrysler Canada Inc. used in substitution tional on this vehicle.
Page 3: Introduction
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 5: Table Of Contents
INTRODUCTION CONTENTS Introduction ......4 Van Conversions/Campers ....6 How To Use This Manual .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
Page 7 INTRODUCTION 5...
Page 8: Van Conversions/Campers
6 INTRODUCTION WARNINGS AND CAUTIONS Operating instructions for the special equipment in- This Owner’s Manual contains WARNINGS against op- stalled by the conversion/camper manufacturer should erating procedures that could result in a collision or also be supplied with your vehicle. If these instructions bodily injury.
Page 9: Vehicle Identification Number
INTRODUCTION 7 VEHICLE IDENTIFICATION NUMBER NOTE: It is illegal to remove or alter the VIN. The Vehicle Identification Number (VIN) is found on the VEHICLE MODIFICATIONS/ALTERATIONS left front corner of the instrument panel, visible through the windshield. This number also appears on the Auto- WARNING! mobile Information Disclosure Label affixed to a window on your vehicle, the vehicle registration and title.
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS ▫ General Information ....18 A Word About Your Keys ....12 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Remote Open Window Feature — ▫ Power Windows – If Equipped ... . 34 If Equipped ......23 ▫...
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Seat Belts And Pregnant Women ..52 Engine Break-In Recommendations ..80 ▫ Seat Belt Extender ..... 52 Safety Tips .
Page 14: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS Wireless Ignition Node (WIN) — If Equipped The Wireless Ignition Node (WIN) operates similar to an Key Fob with Remote Keyless Entry (RKE) — If ignition switch. It has four operating positions, three with Equipped detents and one that is spring-loaded.
Page 15: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob operates the ignition switch. Insert the square end of the key fob into the ignition switch located on the instrument panel and rotate to the desired posi- tion.
Page 16: Removing Key Fob From Ignition
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: • For vehicles not equipped with the Electronic Vehicle Information Center (EVIC), the power window switches, radio, power sunroof (if equipped), and power outlets will remain active for 10 minutes after the ignition switch is turned to the OFF position.
Page 17: Key-In-Ignition Reminder
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 Key-In-Ignition Reminder WARNING! Opening the driver’s door when the Key Fob is in the • Never leave children alone in a vehicle. Leaving ignition and the ignition switch position is OFF or ACC, sounds a signal to remind you to remove the Key Fob.
Page 18 16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system uses a Key Fob with a factory-mated Remote If the Vehicle Security Light turns on during normal Keyless Entry (RKE) transmitter and Wireless Ignition vehicle operation (vehicle running for longer than 10 sec- Node (WIN) to prevent unauthorized vehicle operation.
Page 19: Replacement Keys
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 Replacement Keys Duplication of Key Fobs may be performed at an autho- rized dealer, this procedure consists of programming a NOTE: Only Key Fobs that are programmed to the blank Key Fob to the vehicle electronics. A blank Key Fob vehicle electronics can be used to start and operate the is one that has never been programmed.
Page 20: General Information
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE General Information Security Light will flash. Use of the Sentry Key will The Sentry Key system complies with FCC rules Part 15 disable the alarm. and with RSS-210 of Industry Canada. Operation is Rearming Of The System subject to the following conditions: The Vehicle Security Alarm will rearm itself after the 15...
Page 21: To Disarm The System
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 NOTE: If the Vehicle Security Light stays on continu- Vehicle Security Alarm will arm regardless of whether ously during vehicle operation, have the system checked you are in the vehicle or not. If you remain in the vehicle by an authorized dealer.
Page 22: Remote Keyless Entry (Rke) - If Equipped
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • The illuminated entry system will not operate if the dimmer control is in the extreme left position. REMOTE KEYLESS ENTRY (RKE) — IF EQUIPPED The RKE system allows you to lock or unlock the doors and activate the Panic Alarm from distances up to approximately 66 ft (20 m) using a hand-held radio transmitter with integrated key.
Page 23 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 The turn signal lights will flash to acknowledge the than ten seconds. Then, press and hold the UNLOCK unlock signal. The illuminated entry system will also button while still holding the LOCK button. turn on.
Page 24: To Lock The Doors
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Flash Lamps With Remote Key Lock 3. Test the feature while outside of the vehicle by press- This feature will cause the turn signal lights to flash when ing the LOCK/UNLOCK buttons on the RKE transmitter the doors are locked or unlocked with the RKE transmit- with the ignition switch in the OFF position and the key ter.
Page 25: Remote Open Window Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 Sound Horn With Remote Key Lock 3. Test the feature while outside of the vehicle by press- This feature will cause the horn to chirp when the doors ing the LOCK button on the RKE transmitter with the are locked with the RKE transmitter.
Page 26: Using The Panic Alarm
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • You may need to be less than 35 ft (11 m) from the Using The Panic Alarm To turn the Panic Alarm feature ON or OFF, press and vehicle when using the RKE transmitter to turn off the hold the PANIC button on the RKE transmitter for at Panic Alarm due to the radio frequency noises emitted least one second and release.
Page 27: General Information
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 • This device must accept any interference received, 1. With the RKE transmitter buttons facing down, use a flat blade screwdriver to pry the two halves of the RKE including interference that may cause undesired transmitter apart.
Page 28: Remote Starting System - If Equipped
26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Ignition key removed from ignition switch REMOTE STARTING SYSTEM — IF EQUIPPED This system uses the Remote Keyless Entry • Battery at an acceptable charge level (RKE) transmitter to start the engine conve- •...
Page 29 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 Remote Start Abort Message On Electronic Vehicle will chirp twice (if programmed). Once the vehicle has Information Center (EVIC) — If Equipped started, the engine will run for 15 minutes. The following messages will display in the EVIC if the NOTE: vehicle fails to remote start or exits remote start prema- •...
Page 30 28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: To avoid unintentional shut downs, the system message “Turn To On” will flash in the EVIC until you will disable the one time press of the REMOTE START turn the ignition switch to the ON/RUN position. button for two seconds after receiving a valid Remote Remote Start Comfort Systems —...
Page 31: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 DOOR LOCKS WARNING! Manual Door Locks • For personal security and safety in the event of an Front and rear doors may be locked by moving the lock accident, lock the vehicle doors when you drive as knob down or unlocked by moving the lock knob up.
Page 32: Power Door Locks - If Equipped
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Power Door Locks — If Equipped power locks will not operate. This prevents you from A power door LOCK switch is on each front door trim accidentally locking your Key Fob in the vehicle. Remov- panel.
Page 33 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 • For vehicles not equipped with the EVIC, perform the 8. If a chime is not heard, program mode was canceled following procedure: before the feature could be disabled. If necessary, repeat the above procedure.
Page 34: Child-Protection Door Lock
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • For vehicles not equipped with the EVIC, perform the 7. Repeat the above steps to alternate the availability of following procedure: this feature. 1. Enter your vehicle and close all doors. 8.
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 Child-Protection Door Lock Location Child Lock Control To use the system, open each rear door, use a flat blade WARNING! screwdriver (or emergency key) and rotate the dial to engage and disengage the Child-Protection locks. When Avoid trapping anyone in a vehicle in a collision.
Page 36: Windows
34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE NOTE: WINDOWS • After setting the Child-Protection Door Lock system, Power Windows – If Equipped always test the door from the inside to make certain it is in the desired position. • For emergency exit with the system engaged, move the door lock switch to the UNLOCK position, roll down the window and open the door with the outside door handle.
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 The control on the left front door panel has UP-DOWN WARNING! switches that give you fingertip control of all power windows. There is a single opening and closing switch on Never leave children alone in a vehicle. Leaving the front passenger door for passenger window control unattended children in a vehicle is dangerous for a and on the rear doors of Quad Cab , Mega Cab and...
Page 38 36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To open the window part way, press to the first detent conditions may trigger the auto reverse function unex- and release it when you want the window to stop. pectedly during auto closure. If this happens, pull the switch lightly to the first detent and hold to close the Auto-Up Feature With Anti-Pinch Protection window manually.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 2. Push the window switch down firmly to the second detent to open the window completely and continue to hold the switch down for an additional two seconds after the window is fully open. Window LOCKOUT Switch —...
Page 40: Wind Buffeting
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • Supplemental Side Airbag Inflatable Curtains (SABIC) Wind Buffeting Wind buffeting can be described as the perception of — if equipped pressure on the ears or a helicopter-type sound in the • An energy-absorbing steering column and steering ears.
Page 41: Lap/Shoulder Belts
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 NOTE: The Advanced Front Airbags have a multistage and cause an accident that includes you. This can happen inflator design. This allows the airbag to have different far away from home or on your own street. rates of inflation based on the severity and type of Research has shown that seat belts save lives, and they collision.
Page 42 40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • Do not allow people to ride in any area of your • Wearing a seat belt incorrectly is dangerous. Seat vehicle that is not equipped with seats and seat belts are designed to go around the large bones of belts.
Page 43 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 2. The seat belt latch plate is above the back of the front 3. When the belt is long enough to fit, insert the latch seat, next to your arm in the rear seat. Grasp the latch plate into the buckle until you hear a “click.”...
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! WARNING! (Continued) • A belt that is worn under your arm is dangerous. • A belt buckled into the wrong buckle will not Your body could strike the inside surfaces of the protect you properly.
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 4. Position the lap belt across your thighs, below your WARNING! abdomen. To remove slack in the lap belt portion, pull up • A lap belt worn too high can increase the risk of on the shoulder belt.
Page 46 44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. Regular Cab Front Center Three Point Belt The belt will automatically retract to its stowed position. 1. The front center seat belt on the Regular Cab may be If necessary, slide the latch plate down the webbing to disconnected to open up utilization of the storage areas allow the belt to retract fully.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 WARNING! • If the black latch and black buckle are not prop- erly connected when the seat belt is used by an occupant, the seat belt will not be able to provide proper restraint and will increase the risk of injury in an accident.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Inserting Latch Plate In Use Position...
Page 49: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 Lap/Shoulder Belt Untwisting Procedure located on the upper belt guide to release the anchorage, Use the following procedure to untwist a twisted lap/ and then move it up or down to the position that fits you shoulder belt.
Page 50: Center Lap Belts
48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE you will prefer a higher position. When you release the WARNING! (Continued) anchorage, try to move it up or down to make sure that • A belt that is too loose or too high will apply crash it is locked in position.
Page 51: Seat Belts In Passenger Seating Positions
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 Driver Center Passenger WARNING! First Row • The belt and retractor assembly must be replaced Second Row if the seat belt assembly “Automatic Locking Re- Third Row tractor (ALR)” feature or any other seat belt func- •...
Page 52: Automatic Locking Retractor (Alr) Mode - If Equipped
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Automatic Locking Retractor (ALR) Mode – If How To Disengage The Automatic Locking Mode Equipped Unbuckle the combination lap/shoulder belt and allow it In this mode, the shoulder belt is automatically pre- to retract completely to disengage the Automatic Locking locked.
Page 53: Enhanced Seat Belt Use Reminder System (Beltalert )
60 seconds of the ignition switch being turned to the BeltAlert is a feature intended to remind the driver to ON/RUN or START position. Chrysler Group LLC does fasten their seatbelt. This feature is active whenever the not recommend deactivating the BeltAlert .
Page 54: Seat Belts And Pregnant Women
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 1. With all doors closed and the ignition switch in any NOTE: Although BeltAlert has been deactivated, the position except ON/RUN or START, buckle the driver’s Seat Belt Reminder Light will continue to illuminate seat belt.
Page 55: Supplemental Restraint System (Srs) - Airbags
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 53 extender should be used only if the existing belt is not instrument panel, above the glove compartment. The long enough. When it is not required, remove the ex- words SRS AIRBAG are embossed on the airbag covers. tender and store it.
Page 56: Airbag System Components
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Airbags have a multistage inflator NOTE: • Airbag covers may not be obvious in the interior trim; design. This allows the airbag to have different rates of inflation based on the severity and type of collision. but they will open during airbag deployment.
Page 57: Advanced Front Airbag Features
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 • Supplemental Side Airbag Inflatable Curtains (SABIC) WARNING! • Front and Side Impact Sensors • No objects should be placed over or near the • Front Seat Belt Pretensioners, Seat Belt Buckle Switch, airbag on the instrument panel, because any such and Seat Track Position Sensors objects could cause harm if the vehicle is in a...
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WARNING! (Continued) • Do not mount any accessories to the knee bolster such as alarm lights, stereos, citizen band radios, etc. Supplemental Side Airbag Inflatable Curtain (SABIC) — If Equipped SABIC airbags may offer side-impact protection to front and rear seat outboard occupants in addition to that provided by the body structure.
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 The system includes side impact sensors adjacent to both WARNING! (Continued) front and rear seat occupants that are calibrated to deploy • If your vehicle is equipped with SABIC airbags, the side airbags during impacts that require airbag do not have any accessory items installed which occupant protection.
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Here are some simple steps you can take to minimize the ride properly buckled up in the rear seat. Never allow risk of harm from a deploying airbag: children to slide the shoulder belt behind them or under their arm.
Page 61: Airbag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 Do not lean against the door or window. If your vehicle WARNING! (Continued) has side airbags, and deployment occurs, the side airbags • Being too close to the steering wheel or instrument will inflate forcefully into the space between you and the panel during Advanced Front Airbag deployment door.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Based on the impact sensors signals, a central electronic The side airbags will not deploy in all side collisions. Side ORC deploys the Advanced Front Airbags, SABIC air- airbag deployment will depend on the severity and type bags —...
Page 63 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 The ORC contains a backup power supply system that WARNING! may deploy the airbags even if the battery loses power or it becomes disconnected prior to deployment. Ignoring the Airbag Warning Light in your instru- ment panel could mean you won’t have the airbags to Also, the ORC turns on the Airbag Warning protect you in a collision.
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE based on the collision type and severity. The steering A quantity of non-toxic gas is generated to inflate the side wheel hub trim cover and the upper right side of the curtain airbag. The inflating side curtain airbag pushes instrument panel separate and fold out of the way as the the outside edge of the headliner out of the way and airbags inflate to their full size.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Enhanced Accident Response System NOTE: Front and/or side airbags will not deploy in all In the event of an impact causing airbag deployment, if collisions. This does not mean something is wrong with the communication network remains intact, and the the airbag system.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE airbag inflation. These airborne particles may irritate Maintaining Your Airbag System the skin, eyes, nose, or throat. If you have skin or eye WARNING! irritation, rinse the area with cool water. For nose or throat irritation, move to fresh air.
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 with airbag system electrical components. While the WARNING! (Continued) airbag system is designed to be maintenance free, if any • Do not attempt to modify any part of your airbag of the following occurs, have an authorized dealer ser- system.
Page 68: Event Data Recorder (Edr)
66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE • How far (if at all) the driver was depressing the located on the inside of the fuse block cover for the proper airbag fuses. See your authorized dealer if the accelerator and/or brake pedal; and, fuse is good.
Page 69: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 such as law enforcement, that have the special equip- WARNING! ment, can read the information if they have access to the vehicle or the EDR. In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle.
Page 70 68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Small Children LATCH child restraint anchorage system. Refer to the “LATCH – Child Seat Anchorage System (Lower An- • Safety experts recommend that children ride chors and Tether for Children)”. rearward-facing in the vehicle until they are at least one year old and weigh at least 20 lbs (9 kg).
Page 71 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 child restraint anchorage system. Refer to “LATCH- WARNING! Child Seat Anchorage System (Lower Anchors and • Improper installation can lead to failure of an Tether for Children)”. infant or child restraint. It could come loose in a •...
Page 72 Safety seatback should use the lap/shoulder belt in a rear seat. Standards. Chrysler Group LLC also recommends that • Make sure that the child is upright in the seat. you make sure that you can install the child restraint in the vehicle where you will use it before you buy it.
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 • In the rear seat, you may have trouble tightening the WARNING! lap/shoulder belt on the child restraint because the • Improper installation can lead to failure of an buckle or latch plate is too close to the belt path opening on the restraint.
Page 74 72 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Lower Anchors and Tether for CHildren (LATCH) Each vehicle is equipped with the child restraint anchor- age system called LATCH, which stands for Lower Anchors and Tether for CHildren. The LATCH system provides for the installation of the child restraint without using the vehicle seat belt, instead securing the child restraint using lower anchorages and upper tether straps...
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 Child restraint systems having attachments designed to NOTE: • When using the LATCH attaching system to install a connect to the lower anchorages are now available. Child restraints having tether straps and hooks for connection child restraint, please ensure that all seat belts not to the seat back tether anchorage have been available for being used for occupant restraints are stowed and out...
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing The Child Restraint System We urge you to carefully follow the directions of the manufacturer when installing your child restraint. Many, WARNING! but not all, restraint systems will be equipped with separate straps on each side, with each having a hook or Do not install child restraint systems equipped with connector, and a means for adjusting the tension in the...
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 then allow the belt to retract into the retractor. For WARNING! additional information on ALR, refer to “Automatic Locking Mode”. Improper installation of a child restraint to the LATCH anchorages can lead to failure of an infant or To install a child restraint, first, pull enough of the seat child restraint.
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE each behind the front center and right seats. Quad Cab , Tether Anchorage Points at the Right and Center Mega Cab and Crew Cab models have three anchor- Front Seat (Regular Cab - All Seats) ages, one behind each of the rear seats.
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 Multiple Child Restraint Installation Sequence (Quad Cab /Crew Cab/Mega Cab - Rear Seats) Mega Cab 1. Place a child restraint on each outboard rear seat and adjust the tether strap so that it will reach under the head restraint to the tether anchor directly behind the seat and then to the anchor directly behind the center rear seat.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Quad Cab /Crew Cab 1. The tether straps loops are located between the rear glass and the rear seat. There is a tether strap loop located behind each seating position. You can gain access to the center seating position tether strap loop by raising the head restraint and reaching between the rear glass and rear seat.
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 2. Place a child restraint on each outboard rear seat and adjust the tether strap so that it will reach under the head restraint, through the outboard tether strap loop, then route it to the tether strap loop located directly behind the center rear seat.
Page 82: Engine Break-In Recommendations
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transporting Pets The engine oil installed in the engine at the factory is a Airbags deploying in the front seat could harm your pet. high-quality energy conserving type lubricant. Oil An unrestrained pet will be thrown about and possibly changes should be consistent with anticipated climate injured, or injure a passenger during panic braking or in conditions under which vehicle operations will occur.
Page 83: Safety Tips
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 SAFETY TIPS Exhaust Gas Transporting Passengers WARNING! NEVER TRANSPORT PASSENGERS IN THE CARGO AREA. Exhaust gases can injure or kill. They contain carbon monoxide (CO), which is colorless and odorless. WARNING! Breathing it can make you unconscious and can eventually poison you.
Page 84: Safety Checks You Should Make Inside The Vehicle
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you are required to drive with the trunk/liftgate open, Safety Checks You Should Make Inside The make sure that all windows are closed and the climate Vehicle control BLOWER switch is set at high speed. DO NOT Seat Belts use the recirculation mode.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 Defroster WARNING! Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to Pedals that cannot move freely can cause loss of feel the air directed against the windshield. See your vehicle control and increase the risk of serious per- authorized dealer for service if your defroster is sonal injury.
Page 86: Periodic Safety Checks You Should Make Outside The Vehicle
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside WARNING! (Continued) The Vehicle • Check mounting of mats on a regular basis. Al- Tires ways properly reinstall and secure floor mats that Examine tires for excessive tread wear and uneven wear have been removed for cleaning.
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks. Also, if gasoline fumes are detected or if fuel, power steering fluid, or brake fluid leaks are suspected, the cause should be located and corrected immediately.
Page 89: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Driver’s Automatic Dimming Mirror — Mirrors ......93 If Equipped .
Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Power Lumbar — If Equipped ... 104 ▫ Self-Limiting Control ....120 ▫...
Page 91 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 ▫ Daytime Running Lights (DRL) — ▫ To Set A Desired Speed ....137 If Equipped ......128 ▫...
Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Parksense System Usage Precautions ..145 ▫ Reprogramming A Single HomeLink Button ......157 Parkview Rear Back Up Camera —...
Page 93 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 ▫ Sunshade Operation ....161 ▫ Rear Cupholder — Crew Cab ... 170 ▫...
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Rear Window Defroster ....179 ▫ Bed Rail Tie-Down System ....194 ▫...
Page 95: Mirrors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 MIRRORS The mirror should be adjusted with the lever set in the day position (lever flipped toward the windshield). The Inside Day/Night Mirror mirror should be adjusted to center on the view through Headlight glare can be reduced by moving the small the rear window.
Page 96: Outside Mirrors
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Outside Mirrors To receive maximum benefit, adjust the outside mirror(s) to center on the adjacent lane of traffic with a slight overlap of the view obtained on the inside mirror. WARNING! Vehicles and other objects seen in a passenger side convex mirror will look smaller and farther away than they really are.
Page 97: Outside Mirrors Folding Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 Outside Mirrors Folding Feature CAUTION! All exterior mirrors are designed to be able to be manu- ally folded both forward and rearward to prevent dam- It is recommended to fold the mirrors into the full age.
Page 98: Power Mirrors - If Equipped
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Mirrors — If Equipped The power mirror controls consist of mirror select but- The controls for the power mirrors are located on the tons and a four-way mirror control switch. driver’s door trim panel. Power Mirror Controls Power Mirror Controls 1 —...
Page 99: Power Folding Outside Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 To adjust a mirror, press the mirror select button for the Power Folding Outside Mirrors — If Equipped mirror that you want to adjust. Using the mirror control If equipped with power folding mirrors, they can be switch, press on any of the four arrows for the direction electrically folded rearward and unfolded into the drive that you want the mirror to move.
Page 100: Heated Mirrors - If Equipped
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The switch for the power folding mirrors is located NOTE: Ten or more switch activations within one between the power mirror switches L (left) and R (right). minute will disable the fold/unfold feature to protect the Press the switch once and the mirrors will fold in, motors from overheating.
Page 101: Illuminated Vanity Mirror - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 99 Illuminated Vanity Mirror — If Equipped “Slide-On-Rod” Features Of Sun Visor — If Illuminated vanity mirrors are located on each sun visor. Equipped To use the mirror, rotate the sun visor down and swing The sun visor “Slide-On-Rod”...
Page 102: Trailer Towing Mirrors - If Equipped
100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To use the “Slide-On-Rod” feature, rotate the sun visor Trailer Towing Mirrors — If Equipped downward and unclip it. Pull the sun visor along the These mirrors are designed with an adjustable mirror “Slide-On-Rod”...
Page 103: Uconnect™ Phone - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 NOTE: Fold the trailer towing mirrors rearward prior to Uconnect™ Phone — IF EQUIPPED entering an automated car wash. Uconnect™ Phone is a hands-free system that allows you to use voice commands to dial a phone number stored in A small blindspot mirror is located next to main mirror your mobile phone.
Page 104: Seats
102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SEATS There are two power seat switches that are used to Seats are a part of the Occupant Restraint System of the control the movement of the seat cushion and the seat- vehicle. back.
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 Adjusting The Sear Forward Or Rearward Reclining The Seatback The seat can be adjusted both forward and rearward. The angle of the seatback can be adjusted forward or Push the seat switch forward or rearward, the seat will rearward.
Page 106: Power Lumbar - If Equipped
104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Lumbar — If Equipped WARNING! (Continued) Vehicles equipped with power driver or passenger seats • Do not ride with the seatback reclined so that the may be also be equipped with power lumbar. The power shoulder belt is no longer resting against your lumbar switch is located on the outboard side of the chest.
Page 107: Heated Seats - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Heated Seats — If Equipped WARNING! (Continued) On some models, the front and rear seats may be • Do not place anything on the seat that insulates equipped with heaters in both the seat cushions and against heat, such as a blanket or cushion.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE You can choose from HIGH, LOW or OFF heat settings. The heated seats switch from HIGH to LOW and from Amber indicator lights in each switch indicate the level of LOW to OFF automatically, based on time and tempera- heat in use.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 Rear Heated Seats NOTE: • Once a heat setting is selected, heat will be felt within On some models, the two outboard seats are equipped with heated seats. The heated seat switches for these two to five minutes.
Page 110: Ventilated Seats - If Equipped
108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Ventilated Seats — If Equipped Press the switch once to choose HIGH, On some models, both the driver and passenger seats are press it a second time to choose LOW. ventilated. Located in the seat cushion and seatback are Pressing the switch a third time will small fans that draw the air from the passenger compart- turn the ventilated seat OFF.
Page 111: Manual Seat Adjuster - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 Manual Seat Adjuster — If Equipped While sitting in the seat, pull up on the handle and slide Both front seats are adjustable forward or rearward. The the seat forward or backward. Release the bar once you manual seat adjustment handle is located under the seat have reached the desired position.
Page 112: Manual Reclining Seats - If Equipped
110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Manual Reclining Seats — If Equipped To adjust the seatback, lift upward on the handle, lean The recliner handle is used to adjust the seatback position back on the seatback and when you reach the desired and is located on the outside of the seat cushion.
Page 113: 40-20-40 Front Bench Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 Mega Cab Rear Seat Features WARNING! Reclining Rear Seats — If Equipped • Do not stand or lean in front of the seat while The recliner handle is located on the outside of the seat actuating the handle.
Page 114 112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! Do not ride with the seatback reclined so that the shoulder belt is no longer resting against your chest. In a collision you could slide under the seat belt, which could result in serious injury or death. Folding Rear Seat (Table Mode) —...
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 WARNING! • It is dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. •...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To fold either rear seat flat: 2. Fold the seatback down and push the seat forward. 1. Lift the handle, located on the outboard side of either of the rear seats. Rear Passenger Fold Flat Seats Handle...
Page 117: Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 3. Lift the seatback, to return the seat to the upright Head Restraints position. Be sure the seat is locked in place. Head restraints are designed to reduce the risk of injury by restricting head movement in the event of a rear WARNING! impact.
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Head Restraints Rear Head Restraints To raise the head restraint, pull upward on the head The two outboard seat are equipped with adjustable head restraint. To lower the head restraint, press the adjust- restraints.
Page 119: Driver Memory Seat - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 NOTE: • The rear center head restraint (Crew Cab and Quad Cab) has only one adjustment position that is used to aid in the routing of a tether. Refer to “Occupant Restraints” in “Things to Know Before Starting Your Vehicle”...
Page 120: Setting Memory Positions And Linking Rke Transmitter T O Memory
118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Keyless Entry (RKE) transmitters can also be pro- 2. Adjust the driver’s seat, recliner, and both sideview grammed to recall the same positions when the UN- mirrors to the desired positions. LOCK button is pressed. NOTE: Not all motors may be moved at one time.
Page 121: Memory Position Recall
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 119 performed within 10 seconds if you desire to also use a To recall the memory settings for driver one, press RKE transmitter to recall memory positions. MEMORY button number 1 on the driver’s seat or the UNLOCK button on the RKE transmitter linked to 8.
Page 122: To Disable A Rke Transmitter Linked To Memory
120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: A chime sound may be heard if setting memory vehicles equipped with the Electronic vehicle Informa- was inhibited for any reason. tion Center (EVIC), refer to “Electronic Vehicle Informa- tion Center (EVIC)/Customer-Programmable Features” To Disable A RKE Transmitter Linked To Memory in “Understanding Your Instrument Panel”...
Page 123: Driver Easy Exit And Easy Entry Control
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Driver Easy Exit And Easy Entry Control TO OPEN AND CLOSE THE HOOD This additional feature provides automatic driver’s seat To open the hood, two latches must be released. positioning which will enhance driver mobility into and 1.
Page 124 122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Reach into the opening beneath the center of the hood CAUTION! and push the safety latch lever from right to left to release it, before raising the hood. To prevent possible damage, do not slam the hood to close it.
Page 125: Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 LIGHTS Your vehicle is equipped with plastic headlight and fog The headlight switch is located on the left side of the light (if equipped) lenses that are lighter and less suscep- instrument panel, next to the steering wheel. The head- tible to stone breakage than glass lights.
Page 126: Headlights
124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Headlights To turn on the headlights, rotate the headlight switch clockwise. When the headlight switch is on the parking lights, taillights, license plate light and instrument panel lights are also turned on. To turn off the headlights, rotate the headlight switch back to the O (Off) position.
Page 127: Headlight Delay
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 NOTE: The engine must be running before the head- Parking Lights And Panel Lights lights will turn on in the Automatic Mode. To turn on the parking lights and instrument panel lights, rotate the headlight switch clockwise to the Headlight Delay parking light symbol.
Page 128: Interior Lights
126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE turn off when the switch is pushed a second time, when the headlight switch is rotated to the off position, or the high beam is selected. Interior Lights Courtesy and dome lights are turned on when the front doors are opened, when the dimmer control (rotating wheel on the bottom of the switch) is rotated to the far right detent position, or if equipped, when the UNLOCK...
Page 129: Cargo Light
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 supplement the brightness of the odometer, trip odom- Cargo Light eter, radio and overhead console by rotating the control The cargo lights are turned on by pressing on the cargo to the right until you hear a click. This feature is termed button.
Page 130: Lights-On Reminder
128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Lights-On Reminder Daytime Running Lights (DRL) — If Equipped If the headlights, parking lights, or cargo lights are left on The headlights on your vehicle will illuminate when the after the ignition is turned OFF, a chime will sound when engine is started and the transmission is in any gear the driver’s door is opened.
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 Turn Signals NOTE: If either light remains on and does not flash, or Move the multifunction lever up or down and the arrows there is a very fast flash rate, check for a defective outside on each side of the instrument cluster flash to show light bulb.
Page 132: Windshield Wipers And Washers
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE High/Low Beam Switch WINDSHIELD WIPERS AND WASHERS Push the multifunction lever toward the instrument Windshield Wipers panel to switch the headlights to high beam. Pulling the The wipers and washers are operated by a switch in the multifunction back toward the steering wheel will turn multifunction lever.
Page 133: Windshield Washers
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 Intermittent Wiper System depressed while in the delay range, the wiper will The intermittent feature of this system was designed for operate for several seconds after the washer knob is use when weather conditions make a single wiping cycle, released.
Page 134: Mist Feature
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pull the lever toward the steering wheel to unlock the WARNING! steering column. With one hand firmly on the steering wheel, move the steering column up or down, as desired. Sudden loss of visibility through the windshield Release the lever to lock the steering column firmly in could lead to a collision.
Page 135: Heated Steering Wheel - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 The heated steering wheel switch is located on the switch WARNING! bank below the climate controls. Do not adjust the steering column while driving. Press the switch to turn on the heated Adjusting the steering column while driving or driv- steering wheel.
Page 136: Driver Adjustable Pedals - If Equipped
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE from the driver to provide improved position with the WARNING! steering wheel. • Persons who are unable to feel pain to the skin The adjustable pedal switch is located to the left side of because of advanced age, chronic illness, diabetes, the steering column.
Page 137: Adjustment
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Adjustment CAUTION! 1. Position the driver’s seat so that you are at least 10 in Do not place any article under the adjustable pedals (25.4 cm) away from the airbag, located in the center of or impede its ability to move as it may cause damage the steering wheel.
Page 138: Electronic Speed Control - If Equipped
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ELECTRONIC SPEED CONTROL — IF EQUIPPED NOTE: In order to ensure proper operation, the Elec- When engaged, Electronic Speed Control takes over the tronic Speed Control System has been designed to shut accelerator operation at speeds greater than 25 mph down if multiple Speed Control functions are operated at (40 km/h).
Page 139: To Set A Desired Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 speed memory. Pushing the ON/OFF button to the OFF WARNING! position or turning OFF the ignition erases the set speed memory. Leaving the Electronic Speed Control system on when not in use is dangerous. You could accidently To Resume Speed set the system or cause it to go faster than you want.
Page 140: To Accelerate For Passing
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To decrease speed while the Electronic Speed Control is Your vehicle may experience a downshift (automatic set, push down and hold the SET DECEL lever. If the transmissions only) while climbing uphill or descending lever is continually held in the SET DECEL position, the downhill.
Page 141: Parksense Rear Park Assist - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 PARKSENSE REAR PARK ASSIST — IF ParkSense Sensors EQUIPPED The four ParkSense sensors, located in the rear fascia/ The ParkSense Rear Park Assist system provides visual bumper, monitor the area behind the vehicle that is and audible indications of the distance between the rear within the sensors’...
Page 142: Parksense Display
140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The ParkSense Warning Display is located in the Instru- ParkSense Display ment cluster’s EVIC display. It provides both visual and When the vehicle is in REVERSE, the warning display audible warnings to indicate the distance between the will turn ON indicating the system status.
Page 143 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 The system will indicate a detected obstacle by showing three solid arcs and will produce a one-half second tone. As the vehicle moves closer to the object the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 144 142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Fast Tone Continuous Tone...
Page 145: Enabling And Disabling Parksense
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 The vehicle is close to the obstacle when the EVIC display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert operation when the system is detecting an obstacle: WARNING ALERTS Rear Distance Greater than...
Page 146: Service The Parksense Rear Park Assist System
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When the ParkSense switch is pressed to display located above in the Instrument Cluster’s EVIC disable the system, the instrument cluster will provides both visual and audible warnings to indicate display the “PARK ASSIST OFF” message for the range of the object.
Page 147: Cleaning The Parksense System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 • Jackhammers, large trucks, and other vibrations could If “CLEAN PARK ASSIST SENSORS” appears in the Electronic Vehicle Information Center (EVIC) and the affect the performance of ParkSense . rear fascia/bumper is clean and clear of snow, ice, mud, •...
Page 148 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE obstacle behind the fascia/bumper, or it could provide CAUTION! a false indication that an obstacle is behind the fascia/ • ParkSense is only a parking aid and it is unable bumper. to recognize every obstacle, including small ob- •...
Page 149 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 WARNING! WARNING! (Continued) • Before using the ParkSense Rear Park Assist • Drivers must be careful when backing up even System, it is strongly recommended that the ball when using the ParkSense Rear Park Assist Sys- mount and hitch ball assembly is disconnected tem.
Page 150: Parkview Rear Back Up Camera - If Equipped
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE PARKVIEW REAR BACK UP CAMERA — IF When displayed, static grid lines will illustrate the width EQUIPPED of the vehicle while a dashed center-line will indicate the Your vehicle may be equipped with the ParkView Rear center of the vehicle to assist with aligning to a hitch/ Back Up Camera that allows you to see an on-screen receiver.
Page 151: Turning Parkview On Or Off - With Navigation/Multimedia Radio
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 WARNING! CAUTION! (Continued) • To avoid vehicle damage, the vehicle must be Drivers must be careful when backing up even when driven slowly when using ParkView to be able to using the ParkView Rear Back Up Camera. Always stop in time when an obstacle is seen.
Page 152: Turning Parkview On Or Off - Without Navigation/Multimedia Radio
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Power Sunroof Switch — If Equipped 4. Enable or disable the rear camera feature by selecting “enable rear camera in reverse” soft key and pressing the • Power Sliding Rear Window Switch — If Equipped “save”...
Page 153: Courtesy/Reading Lights
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 Courtesy/Reading Lights Both lights in the overhead console and rear passenger compartment will illuminate as courtesy lights when a door is opened, when the dimmer control is rotated to the courtesy light position (full right position), or when the UNLOCK button is pressed on the Remote Keyless Entry (RKE) transmitter, if equipped.
Page 154: Garage Door Opener - If Equipped
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE GARAGE DOOR OPENER — IF EQUIPPED HomeLink replaces up to three remote controls (hand- held transmitters) that operate devices such as garage door openers, motorized gates, lighting or home security systems. The HomeLink unit operates off your vehicle’s battery.
Page 155 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 WARNING! • Your motorized door or gate will open and close while you are training the Universal Transceiver. Do not train the transceiver if people, pets or other objects are in the path of the door or gate. Only use this transceiver with a garage door opener that has a “stop and reverse”...
Page 156: Programming Homelink
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Place the handheld transmitter 1 to 3 in (3 to 8 cm) Programming HomeLink from the HomeLink buttons while keeping the EVIC Before You Begin display in view. If you have not trained any of the HomeLink buttons, erase all channels before you begin training.
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 NOTE: Some gate operators and garage door openers This can usually be found where the hanging antenna may require you to replace Step 3 with procedures noted wire is attached to the garage door opener motor (it is in the “Gate Operator/Canadian Programming”...
Page 158: Gate Operator/Canadian Programming
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 1. Firmly press and release the LEARN or TRAINING Gate Operator/Canadian Programming button. The name and color of the button may vary by Canadian radio-frequency laws require transmitter sig- manufacturer. nals to “time-out” (or quit) after several seconds of transmission –...
Page 159: Using Homelink
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 successfully accepted the frequency signal. The EVIC 2. Press and hold the desired HomeLink button for display will change from “CHANNEL # TRAINING” to 20 seconds until the EVIC display states “CHANNEL # “CHANNEL # TRAINED.”...
Page 160: Troubleshooting Tips
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Troubleshooting Tips General Information If you are having trouble programming HomeLink , here This device complies with FCC rules Part 15 and Industry are some of the most common solutions: Canada RSS-210. Operation is subject to the following two conditions: •...
Page 161: Power Sunroof - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 POWER SUNROOF — IF EQUIPPED NOTE: The Power Accessory Delay feature will allow The power sunroof switch is located on the overhead the power sunroof to operate for approximately ten console between the courtesy/reading lights. minutes after the ignition is turned OFF or until a front door is opened.
Page 162: Open Sunroof - Express Mode
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE movement and the sunroof will remain in a partially WARNING! (Continued) opened condition until the switch is pushed and held • Do not allow small children to operate the sun- rearward again. roof. Never allow your fingers, other body parts, or Closing Sunroof —...
Page 163: Pinch Protect Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 Pinch Protect Feature will remain active for 45 seconds after the ignition switch This feature will detect an obstruction in the opening of is turned to the LOCK position. Opening either front the sunroof during Express Close operation. If an ob- door will cancel this feature.
Page 164: Wind Buffeting
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Wind Buffeting ELECTRICAL POWER OUTLETS Wind buffeting can be described as the perception of The auxiliary 12 Volt (13 Amp) power outlets can provide pressure on the ears or a helicopter-type sound in the power for in-cab accessories designed for use with the ears.
Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 • Inside the top storage tray — with floor mounted CAUTION! shifter. • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded the fuse protecting the system will need to be replaced.
Page 166 164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Inside the upper lid of the center storage compartment — if equipped. Power Outlet — Rear Center Console The key symbol indicates that this outlet can supply power when the key is in the ON/RUN or ACC posi- Power Outlet —...
Page 167 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 WARNING! To avoid serious injury or death: • Only devices designed for use in this type of outlet should be inserted into any 12 Volt outlet. • Do not touch with wet hands. •...
Page 168: Cigar Lighter And Ash Receiver - If Equipped
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CIGAR LIGHTER AND ASH RECEIVER — IF CAUTION! EQUIPPED • Many accessories that can be plugged in draw A removable ash receiver and cigar lighter are available. For vehicles with a bench seat the cupholder tray can be power from the vehicle’s battery, even when not in used to hold the ash receiver.
Page 169: Power Inverter - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 For vehicles equipped with an optional floor shifter. POWER INVERTER — IF EQUIPPED A 115 Volt (150 Watts Maximum) outlet is located on the center stack of the instrument panel, to the right of the radio.
Page 170 168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: • When the power inverter switch is pressed, there will be a delay of approximately one second before the power inverter status indicator turns on. The status indicator of the AC power inverter indicates whether the inverter is producing AC power.
Page 171: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 CUPHOLDERS Front Instrument Panel Cupholders — Floor Mounted Shifter Front Instrument Panel Cupholders — (40–20–40 For vehicles equipped with bucket seats and a floor Seats) mounted shifter there are two cupholders located in the The cupholders are located in the pull-out tray at the bottom floor console.
Page 172: Rear Cupholder - Quad Cab
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Cupholder — Quad Cab Rear Cupholder — Crew Cab Quad Cab vehicles may be equipped with a rear cup- Crew Cab vehicles are equipped with rear cupholders holder that consists of two cup wells for rear passenger located in the center armrest.
Page 173: Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 STORAGE To open the upper glove box push upward on the handle release. The glove box door will automatically open. Glove Box Storage The glove box is located on the passenger side of the instrument panel and features both an upper and lower storage area.
Page 174: Door Storage
172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To open the lower glove box, pull on the handle to release Door Storage the latch and lower the door. Front Door Storage — If Equipped Storage areas and bottle holders (drivers side only) are located in the door trim panels.
Page 175: Center Storage Compartment - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 Rear Door Storage — Crew Cab Center Storage Compartment — If Equipped Storage compartments are located in both the driver and The center storage compartment is located between the passenger door trim panels. driver and passenger seats.
Page 176 174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Pull on the upper handle on the front of the armrest to WARNING! raise the cover. The upper storage area contains a 12 Volt • This armrest is not a seat. Anyone seated on the power outlet that can be used to power small electrical devices, refer to “Electrical Power Outlets”...
Page 177 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 With the upper lid closed, pull on the lower handle to WARNING! open the lower storage bin. Do not operate this vehicle with a console compart- ment lid in the open position. Cellular phones, music players, and other handheld electronic devices should be stowed while driving.
Page 178: Second Row In-Floor Storage Bin - If Equipped
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Second Row In-Floor Storage Bin — If Equipped To open in-floor storage bin, lift upward on the handle of In-floor storage bins are located in front of the second the latch and open the lid. row seats and can be used for extra storage.
Page 179: Seatback Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 Seatback Storage Located in the back of both the driver and passenger front seats are pockets that can be used for storage. Storage Bin Storage and Seats (Crew Cab) The Crew Cab models provide additional storage under the rear seats.
Page 180: Plastic Grocery Bag Retainers (Regular Cab Models)
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Plastic Grocery Bag Retainers (Regular Cab Models) Retainer hooks which will hold plastic grocery bag handles are built into the back panel of the cab, behind the rear seat. Crew Cab Storage CAUTION! Always lift the storage compartment lids by using the handle.
Page 181: Rear Window Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 REAR WINDOW FEATURES CAUTION! Rear Window Defroster Failure to follow these cautions can cause damage to The rear window defroster button is located on the the heating elements: climate control panel. Press this button to turn on •...
Page 182: Power Sliding Rear Window - If Equipped
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Power Sliding Rear Window — If Equipped Manual Sliding Rear Window — If Equipped The switch for the power sliding rear window is located A locking device in the center of the window helps to on the overhead console.
Page 183 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 Unfolding the Load Floor 1. Lift the 60/40 seat cushion(s) to the upward position. Load Floor In Open Position 3. Reverse the procedure to store the load floor. Positioning the Load Floor for Storage Access Under Unfolding The Load Floor the Seat 2.
Page 184 182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. Unsnap the securing snap located at either side of the load floor. 3. Lift the load floor up to access storage under the load floor. WARNING! Do not drive with the load floor in the up position. When stopping fast or in an accident, the load floor could move to the down position causing serious injury.
Page 185: Rambox - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 RAMBOX — IF EQUIPPED RamBox Integrated Box Side Storage Bins The RamBox system is an integrated pickup box storage Cargo storage bins are located on both sides of the pickup and cargo management system consisting of three fea- box.
Page 186 184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! Failure to follow the following items could cause damage to the vehicle: • Assure that all cargo inside the storage bins is properly secured. • Do not exceed cargo weight rating of 150 lb (68 kg) per bin.
Page 187 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 CAUTION! Leaving the lid open for extended periods of time could cause the vehicle battery to discharge. If the lid is required to stay open for extended periods of time, it is recommended that the bin lights be turned off manually using the on/off switch.
Page 188: Rambox Safety Warning
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE RamBox Safety Warning CAUTION! (Continued) Carefully follow these warnings to help prevent personal • Loads applied to the top of the bin lid should be injury or damage to your vehicle: minimized to prevent damage to the lid and latching/hinging mechanisms.
Page 189: Bed Extender - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 RamBox Storage Bin Cover Emergency Release NOTE: In the event of an individual being locked inside Lever — If Equipped the storage bin, the storage bin cover can be opened from As a security measure, a Storage Bin Cover Emergency inside of the bin by pulling on the glow-in-the-dark lever Release is built into the storage bin cover latching mecha- attached to the storage bin cover latching mechanism.
Page 190 188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To install the bed extender into the storage position, 2. With the side gates open, position the extender fully perform the following: forward in the bed against the front panel. 1. Make sure the center handle is unlocked using the vehicle key and rotate the center handle vertically to release the extender side gates.
Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 Cargo Tie Down Loop Side Gates Closed 4. Rotate the center handle horizontally to secure the side 5. Lock the center handle using the vehicle key to secure gates in the closed position. the panel into place and assist against theft.
Page 192 190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Divider Position The divider position is intended for managing your cargo and assisting in keeping cargo from moving around the bed. There are 11 divider slots along the bed inner panels which allow for various positions to assist in managing your cargo.
Page 193 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 Aligning Gate To Slots Side Gates Closed 3. Rotate the side gates closed so that the outboard ends 5. Lock the center handle to secure the panel into place are secured into the intended slots of the bed. and assist against theft.
Page 194 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE additional cargo room is needed. The extender position 2. Make sure the center handle is unlocked and rotate the utilizes a locating pin and rotating handle located on both center handle vertically in order to release the extender sides of the truck bed near the tailgate.
Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 4. Rotate the handles to the horizontal position to secure WARNING! into place. To reduce the risk of potential injury or property damage: • Cargo must be secured. • Do not exceed cargo load rating of your vehicle. •...
Page 196: Bed Rail Tie-Down System
194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Bed Rail Tie-Down System CAUTION! The maximum load per cleat should not exceed 250 lbs (113 kg) and the angle of the load on each cleat should not exceed 60 degrees above horizontal, or damage to the cleat or cleat rail may occur.
Page 197 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 out on the cleat and slide it to the detent nearest the To remove the cleats from the utility rail, remove the end desired location. Make sure the cleat is seated in the cap by pushing up on the locking tab, located on the detent and tighten the nut.
Page 198: Slide-In Campers
196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE SLIDE-IN CAMPERS Disconnecting the Rear Camera — If Equipped Camper Applications 1. Open the tailgate to access the rear camera connector Certain truck models are not recommended for slide-in bracket located on the rear sill. campers.
Page 199: Removing The Tailgate
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 5. Connect the tailgate plug (provided in the glove box) to the tailgate wiring harness to ensure that the terminals do not corrode. 6. Tape the tailgate harness and bracket against the forward-facing surface of the tailgate. This will prevent damaging the connector and bracket when storing or reinstalling the tailgate.
Page 200: Locking Tailgate
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 6. Remove the tailgate from the vehicle. NOTE: Do not carry the tailgate loose in the truck pickup box. WARNING! To avoid inhaling carbon monoxide, which is deadly, the exhaust system on vehicles equipped with “Cap or Slide-In Campers”...
Page 201: Understanding Your Instrument Panel
UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ EVIC Displays ..... . 227 Instrument Panel Features ....203 ▫...
Page 202 200 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Customer-Programmable Features Media Center 130 With Satellite Radio (System Setup) ..... . 240 (Sales Code RES+RSC)....256 ▫...
Page 203 UNDERSTANDING YOUR INSTRUMENT PANEL 201 ▫ Using This Feature ....273 Video Entertainment System (VES)™ — If Equipped ......284 ▫...
Page 204 202 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Vacation/Storage ....297 ▫ Outside Air Intake ....298 ▫...
Page 205: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 203 INSTRUMENT PANEL FEATURES 1 — Headlight Switch 7 — 115v Power Inverter Outlet 13 — Transfer Case Position Switch 2 — Instrument Cluster 8 — Power Outlet 14 — Ignition Switch 3 — Radio 9 — Lower Switch Bank 15 —...
Page 206: Switch Bank Button Description
204 UNDERSTANDING YOUR INSTRUMENT PANEL SWITCH BANK BUTTON DESCRIPTION 1. TOW/HAUL Refer to “Starting And Operating” for more information. Upper Switch Bank 2. ESC OFF The upper switch bank is located on the center of the Refer to “Starting And Operating” for more information. instrument panel.
Page 207: Lower Switch Bank
UNDERSTANDING YOUR INSTRUMENT PANEL 205 Lower Switch Bank 2. VENTILATED SEATS Refer to “Understanding The Features Of Your Vehicle” The lower switch bank is located on the center of the for more information. instrument panel. 3. HEATED STEERING WHEEL Refer to “Understanding The Features Of Your Vehicle” for more information.
Page 208: Instrument Cluster - Base
206 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER — BASE...
Page 209: Instrument Cluster - Premium
UNDERSTANDING YOUR INSTRUMENT PANEL 207 INSTRUMENT CLUSTER — PREMIUM...
Page 210: Instrument Cluster Descriptions
208 UNDERSTANDING YOUR INSTRUMENT PANEL • Check for an inoperative outside light bulb if either INSTRUMENT CLUSTER DESCRIPTIONS indicator remains on and does not flash, or flashes at a 1. Tachometer rapid rate. The tachometer indicates engine speed in Revolutions Per Minute (RPM x 1000).
Page 211 UNDERSTANDING YOUR INSTRUMENT PANEL 209 CAUTION! WARNING! Driving with a hot engine cooling system could A hot engine cooling system is dangerous. You or damage your vehicle. If the temperature gauge reads others could be badly burned by steam or boiling “H”...
Page 212 210 UNDERSTANDING YOUR INSTRUMENT PANEL rotate at the same speed. Low range provides a greater If the light remains lit with the engine running, your gear reduction ratio to provide increased torque at the vehicle will usually be drivable; however, see an autho- wheels.
Page 213 UNDERSTANDING YOUR INSTRUMENT PANEL 211 9. 4WD Auto Indicator 11. TOW/HAUL The 4WD auto indicator will be illuminated The TOW HAUL button is located on the whenever the four-wheel drive mode is auto- center stack upper switch bank. This light will matically engaged.
Page 214 212 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: 14. Oil Pressure Gauge • The “ESC Off Indicator Light” and the “ESC The pointer should always indicate some oil pressure Activation/Malfunction Indicator Light” come on mo- when the engine is running. A continuous high or low mentarily each time the ignition switch is turned to reading under normal driving conditions may indicate a ON/RUN.
Page 215 UNDERSTANDING YOUR INSTRUMENT PANEL 213 16. Odometer Display / Electronic Vehicle Information The two trip odometers show individual trip mileage. To Center (EVIC) Display Area — If Equipped switch from odometer to trip odometers, press and release the TRIP ODOMETER button. Odometer Display The odometer display shows the total distance the ve- To reset a trip odometer, display the desired trip odom-...
Page 216 214 UNDERSTANDING YOUR INSTRUMENT PANEL running. To display the engine hours on the base cluster, depending on driving habits and vehicle usage. Press the perform the following: Place the ignition in the ON/ Odometer / Trip Odometer / ECO (Fuel Saver Indicator) RUN, but do not start the engine.
Page 217 UNDERSTANDING YOUR INSTRUMENT PANEL 215 noFUSE position. To turn off the message temporarily, press and If the vehicle diagnostic system determines that the release the Trip Odometer button on the instrument Ignition Off Draw (IOD) fuse is improperly installed, or cluster.
Page 218 216 UNDERSTANDING YOUR INSTRUMENT PANEL single chime will sound after reaching a set threshold. 18. Shift Lever Indicator Further overheating will cause the temperature gauge to The Shift Lever Indicator is self-contained within the pass H, the indicator will continuously flash and a instrument cluster.
Page 219 UNDERSTANDING YOUR INSTRUMENT PANEL 217 Center (EVIC). Refer to ”Electronic Vehicle Information cycling operation is controlled by the engine control Center (EVIC) — If Equipped” for further information. module. Post-heat operation can run for several minutes, and then the electrical system and voltmeter needle will 20.
Page 220 218 UNDERSTANDING YOUR INSTRUMENT PANEL master cylinder reservoir, it indicates a possible brake NOTE: The light may flash momentarily during sharp hydraulic system malfunction or that a problem with the cornering maneuvers, which change fluid level condi- Brake Booster has been detected by the Anti-Lock Brake tions.
Page 221 UNDERSTANDING YOUR INSTRUMENT PANEL 219 Operation of the Brake Warning Light can be checked by vehicle and shut off the engine as soon as possible. A turning the ignition switch from the OFF position to the chime will sound for four minutes when this light turns ON/RUN position.
Page 222 220 UNDERSTANDING YOUR INSTRUMENT PANEL vehicle placard or tire inflation pressure label, you should maintain correct tire pressure, even if under-inflation has determine the proper tire inflation pressure for those not reached the level to trigger illumination of the TPMS tires.) low tire pressure telltale.
Page 223 UNDERSTANDING YOUR INSTRUMENT PANEL 221 tires or wheels on your vehicle, to ensure that the the Electronic Vehicle Information Center (EVIC) screen replacement or alternate tires and wheels allow the TPMS indicating “Low Tire” for EVIC enabled clusters. to continue to function properly. 26.
Page 224 222 UNDERSTANDING YOUR INSTRUMENT PANEL Although your vehicle will usually be drivable and not WARNING! need towing, see your authorized dealer for service as soon as possible. A malfunctioning catalytic converter, as referenced above, can reach higher temperatures than in normal CAUTION! operating conditions.
Page 225 UNDERSTANDING YOUR INSTRUMENT PANEL 223 28. Front Fog Light Indicator — If Equipped 30. Transmission Temperature Warning Light This indicator will illuminate when the front fog This light indicates that there is excessive trans- lights are on. mission fluid temperature that might occur with severe usage such as trailer towing.
Page 226 224 UNDERSTANDING YOUR INSTRUMENT PANEL belt remains unbuckled, the seat belt reminder light will WARNING! flash or remain on continuously. Refer to “Occupant Restraints” in “Things To Know Before Starting Your If the Transmission Temperature Warning Light is Vehicle” for further information. illuminated and you continue operating the vehicle, in some circumstances you could cause the fluid to 32.
Page 227: Electronic Vehicle Information Center (Evic) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 225 For vehicles equipped with a premium cluster this indi- cator will display in the Electronic Vehicle Information Center (EVIC). Refer to ”Electronic Vehicle Information Center (EVIC) — If Equipped” for further information. 33. Electronic Stability Control (ESC) OFF Indicator Light —...
Page 228 226 UNDERSTANDING YOUR INSTRUMENT PANEL This system conveniently allows the driver to select a Steering wheel EVIC control button, as variety of useful information by pressing the switches it appears on the left side of the steer- mounted on the steering wheel. The EVIC consists of the ing wheel.
Page 229: Evic Displays
UNDERSTANDING YOUR INSTRUMENT PANEL 227 • Right front turn signal lamp out Steering wheel EVIC control button, as it appears on the right side of the • Left rear turn signal lamp out steering wheel. • Right rear turn signal lamp out •...
Page 230 228 UNDERSTANDING YOUR INSTRUMENT PANEL • Lights On • Park Assist On • Keyfob Battery Low • Park Assist Off • ECO (Fuel Saver Indicator) — If Equipped • Warning Object Detected • Door(s) Ajar (with a single chime, if vehicle is in •...
Page 231 UNDERSTANDING YOUR INSTRUMENT PANEL 229 • Remote start aborted — Fuel low • Adjustable Pedals Unavailable — Cruise Engaged • Remote start disabled — System fault • To Tow Vehicle Safely, Read Neutral Shift Procedure in Owners Manual • Remote start disabled — Turn key EVIC Warning Lights •...
Page 232 230 UNDERSTANDING YOUR INSTRUMENT PANEL • Electronic Speed Control Light Do not operate the vehicle until the cause is corrected. This light does not show how much oil is in the engine. This light will turn on when the electronic The engine oil level must be checked under the hood.
Page 233 UNDERSTANDING YOUR INSTRUMENT PANEL 231 If the light remains lit with the engine running, your shift the transmission into NEUTRAL and idle the ve- vehicle will usually be drivable. However, see an autho- hicle. If the temperature reading does not return to rized dealer for service as soon as possible.
Page 234 232 UNDERSTANDING YOUR INSTRUMENT PANEL • Transmission Temperature Light WARNING! This light indicates that there is excessive trans- mission fluid temperature that might occur If the Transmission Temperature Warning Light is with severe usage such as trailer towing. It may illuminated and you continue operating the vehicle, also occur when operating the vehicle in a high in some circumstances you could cause the fluid to...
Page 235: Fuel Economy / Fuel Saver Mode / Distance To Empty (Dte) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 233 Oil Change Due 2. Fully depress the accelerator pedal slowly three times Your vehicle is equipped with an engine oil change within 10 seconds. indicator system. The Oil Change Due message will 3. Turn the ignition switch to the OFF position. flash in the EVIC display for approximately 10 seconds after a single chime has sounded to indicate the next NOTE: If the indicator message illuminates when you...
Page 236 234 UNDERSTANDING YOUR INSTRUMENT PANEL will appear whenever MDS (if equipped) allows the Distance To Empty (DTE) engine to operate on four cylinders, or if you are driving Distance To Empty (DTE) Shows the estimated distance in a fuel efficient manner. that can be traveled with the fuel remaining in the tank.
Page 237: Trip Functions
UNDERSTANDING YOUR INSTRUMENT PANEL 235 • Trip B Trip Functions Press and release the ODOMETER/TRIP ODOMETER Shows the total distance traveled for Trip B since the last button until one of the following Trip Functions displays reset. in the EVIC: •...
Page 238: Vehicle Info
236 UNDERSTANDING YOUR INSTRUMENT PANEL • Engine Hours Vehicle Info (Customer Information Features) Press and release the UP or DOWN button until “Vehicle Displays the hours of engine operation. Info” displays in the EVIC and press the SELECT button. • Trailer Brake — If Equipped Press the UP and DOWN button to scroll through the Displays trailer brake output power and trailer brake available information displays, then press SELECT to...
Page 239: Units
UNDERSTANDING YOUR INSTRUMENT PANEL 237 to “Tires-General Information/Tire Inflation Pres- sures” in “Starting And Operating” for additional information. • Your system can be set to display pressure units in PSI, kPa, or BAR. Units Press and release the UP or DOWN button until “Units” displays in the EVIC and press the SELECT button.
Page 240: Compass / Temperature Display
238 UNDERSTANDING YOUR INSTRUMENT PANEL Compass / Temperature Display temperature sensor caused by the snowplow. In addi- tion, on vehicles equipped with Automatic Tempera- The compass readings indicate the direction the vehicle is ture Control (ATC), it is suggested that the interior facing.
Page 241 UNDERSTANDING YOUR INSTRUMENT PANEL 239 NOTE: A good calibration requires a level surface and 5. Complete one or more 360–degree turns (in an area an environment free from large metallic objects such as free from large metal or metallic objects) until the “CAL” buildings, bridges, underground cables, railroad tracks, indicator turns off.
Page 242: Customer-Programmable Features (System Setup)
240 UNDERSTANDING YOUR INSTRUMENT PANEL 3. Press the DOWN button until the “Compass Variance” message is displayed in the EVIC, then press the SELECT button. The last variance zone number displays in the EVIC. 4. Press and release the SELECT button until the proper variance zone is selected, according to the map.
Page 243 UNDERSTANDING YOUR INSTRUMENT PANEL 241 Use the UP or DOWN button to display one of the the feature showing the system has been activated or the following choices. check-mark is removed, showing the system has been deactivated. Select Language When in this display you may select one of five lan- Park Assist System guages for all display nomenclature, including the trip The Rear Park Assist system will scan for objects behind...
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL Auto Lock Doors Remote Unlock Sequence When this feature is selected, all doors will lock auto- When Unlock Driver Door Only On 1st Press is selected, matically when the vehicle reaches a speed of 15 mph only the driver’s door will unlock on the first press of the (24 km/h).
Page 245 UNDERSTANDING YOUR INSTRUMENT PANEL 243 position using the seat mounted switch. To make your Horn With Remote Start selection, press and release the SELECT button until a When this feature is selected, a short horn sound will check-mark appears next to the feature showing the occur when the RKE transmitter REMOTE START button system has been activated or the check-mark is removed, is pressed.
Page 246 244 UNDERSTANDING YOUR INSTRUMENT PANEL Flash Lamps With Lock Headlamps With Wipers When this feature is selected, the front and rear turn When this feature is selected and the HEADLIGHT signals will flash when the doors are locked or unlocked switch is in the AUTO position, the headlights will turn with the RKE transmitter.
Page 247 UNDERSTANDING YOUR INSTRUMENT PANEL 245 been deactivated. When this feature is deactivated, the Tilt Mirror In Reverse system reverts to the standard intermittent wiper When this feature is selected and the shift lever is placed operation. in reverse gear, the side mirrors tilt downward to allow the driver to see into the previous blind spot and avoid Easy Exit Seat —...
Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL highlighted, then press and release the SELECT button feature showing the system has been activated or the until a check-mark appears next to the setting, showing check-mark is removed, showing the system has been that setting has been selected. deactivated.
Page 249: Media Center 730N/430/430N
UNDERSTANDING YOUR INSTRUMENT PANEL 247 MEDIA CENTER 730N/430/430N (RHR/RER/RBZ/ MEDIA CENTER 130 (SALES CODE RES) RHB) CD/DVD/HDD/NAV — IF EQUIPPED NOTE: The radio sales code is located on the lower right NOTE: The sales code is located on the lower right side side of the radio faceplate.
Page 250: Operating Instructions - Radio Mode
248 UNDERSTANDING YOUR INSTRUMENT PANEL Operating Instructions — Radio Mode to seek up and the left switch to seek down. The radio will remain tuned to the new station until you make NOTE: The ignition switch must be in the ON or ACC another selection.
Page 251 UNDERSTANDING YOUR INSTRUMENT PANEL 249 4. Adjust the minutes using the right side TUNE/ Push the rotary TUNE/SCROLL control knob a second SCROLL control knob. Press the TUNE/SCROLL control time and MID will display. Turn the TUNE/SCROLL knob to save time change. control knob to the right or left to increase or decrease the mid-range tones.
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL Push the rotary TUNE/SCROLL control knob again to SET 2 in both AM and FM. This allows a total of 12 AM exit setting tone, balance, and fade. and 12 FM stations to be stored into pushbutton memory. The stations stored in SET 2 memory can be selected by AM/FM Button pressing the pushbutton twice.
Page 253: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
UNDERSTANDING YOUR INSTRUMENT PANEL 251 Operation Instructions — CD MODE For CD And If you insert a disc with the ignition ON and the radio MP3 Audio Play ON, the unit will switch from radio to CD mode and begin to play when you insert the disc. The display will NOTE: show the track number, and index time in minutes and •...
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL EJECT Button - Ejecting a CD the current selection. Pressing and holding the SEEK Press the EJECT button to eject the CD. button will allow faster scrolling through the tracks in CD and MP3 modes. TIME Button Press this button to change the display from a large CD If you have ejected a disc and have not removed it within...
Page 255: Notes On Playing Mp3 Files
UNDERSTANDING YOUR INSTRUMENT PANEL 253 SET/RND Button (Random Play Button) Supported Medium Formats (File Systems) Press this button while the CD is playing to activate The medium formats supported by the radio are ISO 9660 Random Play. This feature plays the selections on the Level 1 and Level 2 and includes the Joliet extension.
Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL exceeding 20 folders will result in this display. With Supported MP3 File Formats 200 files, exceeding 50 folders will result in this The radio will recognize only files with the *.MP3 exten- display.) sion as MP3 files. Non-MP3 files named with the *.MP3 extension may cause playback problems.
Page 257: Operation Instructions - Auxiliary Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 255 Loading times for playback of MP3 files may be affected MPEG Specifi- Sampling Fre- Bit Rate (kbps) by the following: cation quency (kHz) • Media - CD-RW media may take longer to load than 160, 128, 144, MPEG-2 Audio 112, 96, 80, 64, CD-R media...
Page 258: Media Center 130 With Satellite Radio (Sales Code Res+Rsc)
256 UNDERSTANDING YOUR INSTRUMENT PANEL MP3 player, or cassette player, and utilize the vehicle’s audio system to amplify the source and play through the vehicle speakers. Pressing the DISC/AUX button will change the mode to auxiliary device if the AUX jack is connected. NOTE: The AUX device must be turned on and the device’s volume set to proper level.
Page 259 UNDERSTANDING YOUR INSTRUMENT PANEL 257 Power Switch/Volume Control (Rotary) Voice Command System (Radio) — If Equipped Push the ON/VOLUME control knob to turn on the Refer to “Voice Command” in the Uconnect™ User radio. Push the ON/VOLUME control knob a second Manual located on the DVD for further details.
Page 260 258 UNDERSTANDING YOUR INSTRUMENT PANEL If your vehicle is not equipped with or this feature is not 4. Adjust the minutes using the right side TUNE/ available on your vehicle, a “Not Equipped With SCROLL control knob. Press the TUNE/SCROLL control Uconnect Phone”...
Page 261 UNDERSTANDING YOUR INSTRUMENT PANEL 259 RW/FF Push the rotary TUNE/SCROLL control knob a third Pressing the RW (Rewind) or FF (Fast Forward) buttons time and TREBLE will display. Turn the TUNE/SCROLL causes the tuner to search for the next frequency in the control knob to the right or left to increase or decrease the direction of the arrows.
Page 262 260 UNDERSTANDING YOUR INSTRUMENT PANEL or turning the TUNE/SCROLL control knob within five Program Type 16-Digit Character Display seconds will allow the program format type to be se- News News lected. Many radio stations do not currently broadcast Nostalgia Nostalga Music Type information.
Page 263 UNDERSTANDING YOUR INSTRUMENT PANEL 261 By pressing the SEEK button when the Music Type icon the minutes using the right side TUNE/SCROLL is displayed, the radio will be tuned to the next frequency control knob. Press the TUNE/SCROLL control knob station with the same selected Music Type name.
Page 264: Operation Instructions - Cd Mode For Cd And Mp3 Audio Play
262 UNDERSTANDING YOUR INSTRUMENT PANEL display window. Each button can be set for SET 1 and Operation Instructions — CD MODE for CD and SET 2 in both AM and FM. This allows a total of 12 AM MP3 Audio Play and 12 FM stations to be stored into pushbutton memory.
Page 265 UNDERSTANDING YOUR INSTRUMENT PANEL 263 If you insert a disc with the ignition ON/RUN and the EJECT Button - Ejecting a CD radio ON, the unit will switch from radio to CD mode Press the EJECT button to eject the CD. and begin to play when you insert the disc.
Page 266: Notes On Playing Mp3 Files
264 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button Press the SET/RND button a second time to stop Ran- Press this button to change the display from a large CD dom Play. playing time display to a small CD playing time display. Notes On Playing MP3 Files RW/FF The radio can play MP3 files;...
Page 267 UNDERSTANDING YOUR INSTRUMENT PANEL 265 The radio uses the following limits for file systems: Multisession disc formats are supported by the radio. Multisession discs may contain combinations of normal • Maximum number of folder levels: 8 CD audio tracks and computer files (including MP3 files). •...
Page 268 266 UNDERSTANDING YOUR INSTRUMENT PANEL Playback of MP3 Files MPEG Sampling Bit Rate (kbps) When a medium containing MP3 data is loaded, the Specification Frequency (kHz) radio checks all files on the medium. If the medium 320, 256, 224, contains a lot of folders or files, the radio will take more MPEG-1 Audio 192, 160, 128, 48, 44.1, 32...
Page 269: List Button (Cd Mode For Mp3 Play)
UNDERSTANDING YOUR INSTRUMENT PANEL 267 LIST Button (CD Mode for MP3 Play) Press and hold the INFO button again for three seconds Pressing the LIST button will bring up a list of all folders to return to elapsed time display. on the disc.
Page 270: Uconnect™ Multimedia (Satellite Radio) - If Equipped
268 UNDERSTANDING YOUR INSTRUMENT PANEL TIME Button (Auxiliary Mode) radio system in your vehicle. Sirius will supply a wel- Press this button to change the display to time of day. The come kit that contains general information, including time of day will display for five seconds (when the how to setup your on-line listening account.
Page 271 UNDERSTANDING YOUR INSTRUMENT PANEL 269 using the TUNE/SCROLL control knob until Sirius ID is Reception Quality selected. Press the TUNE/SCROLL control knob and the Satellite reception may be interrupted due to one of the Sirius ID number will display. The Sirius ID number following reasons: display will time out in two minutes.
Page 272 270 UNDERSTANDING YOUR INSTRUMENT PANEL SEEK Buttons additional three seconds will make the radio display the Press and release the SEEK buttons to search for the next Song Title all of the time (press and hold again to return channel in Satellite mode. Press the right switch to seek to normal display).
Page 273 UNDERSTANDING YOUR INSTRUMENT PANEL 271 Toggle the MUSIC TYPE button again to select the music SET Button – To Set the Pushbutton Memory type. When you are receiving a channel that you wish to commit to pushbutton memory, press the SET button. By pressing the SEEK button when the Music Type The symbol SET 1 will now show in the display window.
Page 274: Operating Instructions (Uconnect™ Phone) - If Equipped
272 UNDERSTANDING YOUR INSTRUMENT PANEL Every time a preset button is used, a corresponding This feature allows an iPod to be plugged into the button number will display. vehicle’s sound system through a 16–pin connector, using the provided interface cable. Buttons 1 - 6 These buttons tune the radio to the channels that you iPod control supports Mini, 4G, Photo, Nano, 5G iPod...
Page 275: Connecting The Ipod
UNDERSTANDING YOUR INSTRUMENT PANEL 273 Connecting The iPod Using This Feature Use the provided connection cable to connect an iPod to By using the provided connection cable to connect an the vehicle’s 16–pin connector port (which is located in iPod to the vehicle’s iPod control 16–pin connector the glove compartment on some vehicles).
Page 276: Play Mode
274 UNDERSTANDING YOUR INSTRUMENT PANEL • Jump backward in the current track by pressing and faceplate. Once in the iPod control mode, iPod audio tracks (if available from iPod ) start playing over the holding the << RW button. Holding the << RW vehicle’s audio system.
Page 277: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 275 • While a track is playing, press the INFO button to see Shuffle OFF modes for the iPod . If the RND icon is the associated metadata (artist, track title, album, etc.) showing on the radio display, then the shuffle mode is for that track.
Page 278 276 UNDERSTANDING YOUR INSTRUMENT PANEL • Pressing a PRESET button will display the current fast will scroll through the list faster. During fast scroll, a slight delay in updating the information on list on the top line and the first item in that list on the radio display may be noticed.
Page 279: Ipod /Usb/Mp3 Control - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 277 iPod /USB/MP3 CONTROL — IF EQUIPPED CAUTION! NOTE: This section is for sales code RES and REQ/ • Leaving the iPod (or any supported device) any- REL/RET radios only with Uconnect™. For sales code where in the vehicle in extreme heat or cold can RBZ/RHB, RHR, RHP, RHW or RB2 touch-screen radio alter the operation or damage the device.
Page 280: Connecting The Ipod Or External Usb Device
278 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: • If the radio has a USB port, refer to the appropriate Uconnect™ Multimedia radio User’s Manual for iPod or external USB device support capability. • Connecting an iPod or consumer electronic audio device to the AUX port located in the radio faceplate, plays media, but does not use the iPod /MP3 control feature to control the connected device.
Page 281: Using This Feature
UNDERSTANDING YOUR INSTRUMENT PANEL 279 NOTE: If the audio device battery is completely dis- Controlling The iPod or External USB Device charged, it may not communicate with the iPod /USB/ Using Radio Buttons MP3 control system until a minimum charge is attained. To get into the iPod /USB/MP3 control mode and access Leaving the audio device connected to the iPod /USB/ a connected audio device, either press the “AUX”...
Page 282 280 UNDERSTANDING YOUR INSTRUMENT PANEL • Turning it clockwise (forward) by one click, while during play mode will jump to the next track in the playing a track, skips to the next track or press VR list, or can press VR button and say Next or Previous button and say Next Track .
Page 283: List Or Browse Mode
UNDERSTANDING YOUR INSTRUMENT PANEL 281 • Turning it clockwise (forward) and counterclock- SCAN button again. During Scan mode, pressing the << SEEK and SEEK >> buttons will select the previ- wise (backward) scrolls through the lists, displaying ous and next tracks. the track detail on the radio display.
Page 284 282 UNDERSTANDING YOUR INSTRUMENT PANEL • Preset 2 – Artists device, then follow the same steps to go to the desired track in that list. Not all iPod or external USB device • Preset 3 – Albums sub-menu levels are available on this system. •...
Page 285: Bluetooth Streaming Audio (Btsa)
UNDERSTANDING YOUR INSTRUMENT PANEL 283 phone system. Seven devices can be paired to Uconnect™ WARNING! phone system, but just one can be selected and played. Do not plug in or remove the iPod or external USB Selecting different Audio Device device while driving.
Page 286: Video Entertainment System (Ves)™ - If Equipped
284 UNDERSTANDING YOUR INSTRUMENT PANEL • Nine different medias to choose from in each screen Browse Browsing is not available on a BTSA device. Only the (AM, FM, Sirius Radio, DVD1, DVD2, Hard Disc Drive current song that is playing will display info. (HDD), AUX in radio, AUX1, AUX2) The LCD screen is located in the overhead compartment VIDEO ENTERTAINMENT SYSTEM (VES)™...
Page 287: Steering Wheel Audio Controls - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 285 STEERING WHEEL AUDIO CONTROLS — IF EQUIPPED The remote sound system controls are located on the rear surface of the steering wheel. Reach behind the wheel to access the switches. VES™ Remote Control Location NOTE: Refer to the “Uconnect™ Multimedia” section of Uconnect™...
Page 288: Radio Operation
286 UNDERSTANDING YOUR INSTRUMENT PANEL The right hand control is a rocker type switch with a The button located in the center of the left hand control pushbutton in the center. Pressing the top of the switch will tune to the next pre-set station that you have will increase the volume, and pressing the bottom of the programmed in the radio pre-set pushbuttons.
Page 289: Cd/Dvd Disc Maintenance
UNDERSTANDING YOUR INSTRUMENT PANEL 287 CD/DVD DISC MAINTENANCE NOTE: If you experience difficulty in playing a particu- To keep a CD/DVD in good condition, take the following lar disc, it may be damaged (i.e., scratched, reflective precautions: coating removed, a hair, moisture or dew on the disc) oversized, or have protection encoding.
Page 290: Climate Controls
288 UNDERSTANDING YOUR INSTRUMENT PANEL CLIMATE CONTROLS Manual Heating and Air Conditioning System The Climate Control System allows you to regulate the The controls for the manual heating and air conditioning temperature, amount, and direction of air circulating system in this vehicle consist of a series of outer rotary throughout the vehicle.
Page 291 UNDERSTANDING YOUR INSTRUMENT PANEL 289 Front Blower Control temperatures. Rotating the knob clockwise, into the red There are four blower speeds. Use this area, indicates warmer temperatures. control to regulate the amount of air NOTE: If your air conditioning performance seems forced through the system in any lower than expected, check the front of the A/C con- mode you select.
Page 292 290 UNDERSTANDING YOUR INSTRUMENT PANEL Panel Mode Mix Mode Air is directed through the outlets in the instrument Air is directed through the floor, defrost and side panel. These outlets can be adjusted to direct airflow. window demist outlets. This setting works best in cold or snowy conditions that require extra heat at Bi-Level Mode the windshield.
Page 293 UNDERSTANDING YOUR INSTRUMENT PANEL 291 • In cold or damp weather, the use of the Recirculation Recirculation Control Press this button to choose between mode will cause windows to fog on the inside because outside air intake or recirculation of of moisture buildup inside the vehicle.
Page 294 292 UNDERSTANDING YOUR INSTRUMENT PANEL Economy Mode MAX A/C If ECONOMY mode is desired, press the A/C button to For maximum cooling, when MAX turn off the LED indicator and the A/C compressor. A/C is selected the A/C is turned on Rotate the temperature control knob to the desired automatically and the air is recircu- temperature.
Page 295: Automatic Temperature Control (Atc) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 293 Automatic Temperature Control (ATC) — If Equipped • The Automatic Temperature Control (ATC) allows both driver and front passenger seat occupants to select individual comfort settings. • When occupants in the vehicle select an Auto mode operation, Auto blower operation is set by using rotary knobs on the control unit and a comfort temperature setting by using the temperature up and down buttons.
Page 296 294 UNDERSTANDING YOUR INSTRUMENT PANEL Automatic Operation NOTE: • It is not necessary to move the temperature settings for 1. Position the MODE control knob to the Auto position cold or hot vehicles. The system automatically adjusts on the Automatic Temperature Control (ATC) Panel. the temperature, mode and fan speed to provide 2.
Page 297 UNDERSTANDING YOUR INSTRUMENT PANEL 295 Manual Operation selected. This allows the front occupants to control the This system offers a full complement of manual override volume of air circulated in the vehicle and cancel the features. Auto mode. NOTE: Each of these features operate independently The operator can also select the direction of the airflow from each other.
Page 298 296 UNDERSTANDING YOUR INSTRUMENT PANEL Floor Mode The Air Conditioning (A/C) button allows the Air comes from the floor outlets. A slight amount of operator to manually activate or deactivate the air air is directed through the defrost and side window conditioning system.
Page 299: Summer Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 297 Recirculation mode should only be used temporarily. The Winter Operation recirculation LED will illuminate on the blower control To ensure the best possible heater and defroster perfor- knob when this button is selected. Push the button a mance, make sure the engine cooling system is function- second time to turn off the Recirculation mode LED and ing properly and the proper amount, type, and concen-...
Page 300: Outside Air Intake
298 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging and Frosting Outside Air Intake Vehicle windows tend to fog on the inside of the glass in Make sure the air intake, located directly in front of the mild, rainy and/or humid weather. Windows may frost windshield, is free of obstructions such as leaves.
Page 301: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 299 Operating Tips...
Page 303 STARTING AND OPERATING CONTENTS ▫ Key Ignition Park Interlock ... . . 311 Starting Procedures ....307 ▫...
Page 304 302 STARTING AND OPERATING ▫ Shifting Procedure – Manually Shifted ▫ Off-Road Driving Tips And Vehicle Transfer Case ..... . . 326 Characteristics .
Page 305 STARTING AND OPERATING 303 ▫ Power Steering Fluid Check ... . . 388 Driving Through Water ....365 ▫...
Page 306 304 STARTING AND OPERATING ▫ ESC Activation/Malfunction Indicator Light ▫ Spare Tire Matching Original Equipped Tire And ESC Off Indicator Light ... . 401 And Wheel – If Equipped ....416 ▫...
Page 307 STARTING AND OPERATING 305 ▫ Directional Tires – If Equipped ... 426 ▫ E-85 Usage In Non-Flex Fuel Vehicles ..441 ▫ Dual Rear Wheels ....426 ▫...
Page 308 306 STARTING AND OPERATING ▫ Replacement Parts ....448 ▫ Towing Requirements ....459 ▫...
Page 309: Starting Procedures
STARTING AND OPERATING 307 STARTING PROCEDURES pedal. Turn the key fob to the START position and release Before starting your vehicle, adjust your seat, adjust both when the engine starts. If the engine fails to start within inside and outside mirrors, and fasten your seat belt. 10 seconds, turn the key fob to the OFF position, wait five seconds, then repeat the “Normal Starting”...
Page 310: Extreme Cold Weather (Below -20°F Or 29°C)
308 STARTING AND OPERATING Extreme Cold Weather (Below –20°F or 29°C) WARNING! To ensure reliable starting at these temperatures, use of • Never pour fuel or other flammable liquids into an externally powered electric engine block heater (avail- able from your authorized dealer) is recommended. the throttle body air inlet opening in an attempt to start the vehicle.
Page 311: After Starting
STARTING AND OPERATING 309 If the engine has been flooded, it may start to run, but not 1500 Models have enough power to continue running when the key The engine block heater cord is routed under the hood on fob is released. If this occurs, continue cranking with the the passenger side of the vehicle near the right head lamp accelerator pedal pushed all the way to the floor.
Page 312: Automatic Transmission
310 STARTING AND OPERATING WARNING! CAUTION! (Continued) • Do not shift from REVERSE, PARK, or NEUTRAL Remember to disconnect the engine block heater into any forward gear when the engine is above cord before driving. Damage to the 110-115 Volt idle speed.
Page 313: Key Ignition Park Interlock
STARTING AND OPERATING 311 Key Ignition Park Interlock Four–Speed Automatic Transmission – If This vehicle is equipped with a Key Ignition Park Inter- Equipped lock which requires the shift lever to be placed in PARK NOTE: Under extremely cold temperatures (-6°F (-21°C) prior to turning the key fob to the LOCK position.
Page 314 312 STARTING AND OPERATING Never use PARK while the vehicle is in motion. Apply WARNING! (Continued) the parking brake when leaving the vehicle in this range. • It is dangerous to move the shift lever out of PARK Always apply the parking brake first, then place the shift or NEUTRAL if the engine speed is higher than lever in the PARK position.
Page 315 STARTING AND OPERATING 313 NEUTRAL WARNING! (Continued) This range is used when the vehicle is standing for • Unintended movement of a vehicle could injure prolonged periods with the engine running. The engine those in and near the vehicle. As with all vehicles, may be started in this range.
Page 316 314 STARTING AND OPERATING Overdrive Operation gear for operation at this temperature. Normal operation The Overdrive automatic transmission contains an elec- will resume when the transmission fluid temperature has tronically controlled fourth gear (OVERDRIVE). The risen to a suitable level. transmission will automatically shift from third gear to If the transmission temperature gets extremely hot, the OVERDRIVE if the following conditions are present:...
Page 317 STARTING AND OPERATING 315 performance and reduce the potential for transmission The “TOW/HAUL Indicator Light” will illuminate in the overheating or failure due to excessive shifting. When instrument cluster to indicate when the switch has been operating in TOW/HAUL mode, the transmission will activated.
Page 318: Five-Speed Automatic Transmission - If Equipped
316 STARTING AND OPERATING 4. Wait approximately 10 seconds, then restart the en- Five–Speed Automatic Transmission – If gine. Equipped The shift lever display located in the instrument panel 5. Move the shift lever to the desired gear range. cluster indicates the transmission gear range. The shift If the problem is no longer detected, the transmission will lever is mounted either on the right side of the steering return to normal operation.
Page 319 STARTING AND OPERATING 317 into 3 (third gear), the transmission will never shift above third gear, but can shift down to 2 (second gear) or 1 (first gear), when needed. Console Shift Lever On vehicles equipped with 4.7L or 5.7L engines, use of ERS (or TOW/HAUL mode) also enables an additional underdrive gear which is not normally used during Column Shift Lever...
Page 320 318 STARTING AND OPERATING through third gear are underdrive gears, and fourth gear WARNING! is direct drive. ERS fifth gear (Overdrive) is the same as the normal fourth gear. Do not downshift for additional engine braking on a slippery surface. The drive wheels could lose their When in the DRIVE position in first through fourth gear, grip and the vehicle could skid.
Page 321 STARTING AND OPERATING 319 Gear Ranges WARNING! (Continued) Do not race the engine when shifting from PARK or • Your vehicle could move and injure you and others NEUTRAL position into another gear range. if it is not completely in PARK. Check by trying to PARK move the shift lever back and forth without first This range supplements the parking brake by locking the...
Page 322 320 STARTING AND OPERATING NEUTRAL WARNING! (Continued) This range is for when the vehicle is standing for pro- • Unintended movement of a vehicle could injure longed periods with the engine running. The engine may those in and near the vehicle. As with all vehicles, be started in this range.
Page 323 STARTING AND OPERATING 321 • the engine coolant (antifreeze) has reached normal If the transmission temperature gets extremely hot, the operating temperature; transmission will automatically select the most desirable gear for operation at this temperature. If the transmission • vehicle speed is above approximately 30 mph temperature becomes hot enough, the “Transmission (48 km/h);...
Page 324 322 STARTING AND OPERATING When To Use TOW/HAUL Mode When driving in hilly areas, towing a trailer, carrying a heavy load, etc., and frequent transmission shifting oc- curs, press the TOW/HAUL switch. This will improve performance and reduce the potential for transmission overheating or failure due to excessive shifting.
Page 325 STARTING AND OPERATING 323 The “TOW/HAUL Indicator Light” will illuminate in the NOTE: • The torque converter clutch will not engage until the instrument cluster to indicate when the switch has been activated. Pressing the switch a second time restores transmission fluid and engine coolant (antifreeze) are normal operation.
Page 326: Four-Wheel Drive Operation - If Equipped
324 STARTING AND OPERATING FOUR-WHEEL DRIVE OPERATION — IF When additional traction is required, the 4H and 4L EQUIPPED positions can be used to lock the front and rear drive- Four-wheel drive trucks are equipped with either a shafts together and force the front and rear wheels to manually shifted transfer case or an electronically shifted rotate at the same speed.
Page 327 STARTING AND OPERATING 325 When operating your vehicle in 4L, the engine speed is NOTE: Delayed shifts out of four-wheel drive may be approximately three times that of the 2H or 4H positions experienced due to uneven tire wear, low or uneven tire at a given road speed.
Page 328: Shifting Procedure - Manually Shifted
326 STARTING AND OPERATING For additional information on the appropriate use of each transfer case mode position, see the information below: Four-Wheel Drive Low Range - This range locks the front and rear driveshafts together forcing the front and rear wheels to rotate at the same speed.
Page 329: Transfer Case Position Indicator Light
STARTING AND OPERATING 327 2H or 4H ⇔ 4L • Shifting into or out of 4L is possible with the vehicle With the vehicle rolling at 2 to 3 mph (3 to 5 km/h), shift completely stopped, however difficulty may occur due the transmission into NEUTRAL.
Page 330: Electronically Shifted Transfer Case (Four-Position Switch) - If Equipped
328 STARTING AND OPERATING Electronically Shifted Transfer Case This electronically shifted transfer case provides four (Four-Position Switch) – If Equipped mode positions: This is an electronic shift transfer case and is operated by • Two-wheel drive high range (2WD) the 4WD Control Switch (Transfer Case Switch), which is •...
Page 331 STARTING AND OPERATING 329 section for specific shifting instructions. The 4WD LOCK If All Shift Conditions Are Met: and 4WD LOW positions are designed for loose, slippery 1. The current position indicator light will turn OFF. road surfaces only. Driving in the 4WD LOCK and 4WD LOW positions on dry hard surfaced roads may cause 2.
Page 332 330 STARTING AND OPERATING the control knob back to the current position, wait five NOTE: Do not attempt to make a shift while only the seconds, and retry selection. To find the shift require- front or rear wheels are spinning, as this can cause ments, refer to the Shifting Procedure for your transfer damage to driveline components.
Page 333 STARTING AND OPERATING 331 4WD LOCK WARNING! Four-Wheel Drive Lock Range - This range locks the front and rear driveshafts together forcing the front and rear You or others could be injured if you leave the wheels to rotate at the same speed. This range provides vehicle unattended with the transfer case in the additional traction for loose, slippery road surfaces only.
Page 334: Shifting Procedure
332 STARTING AND OPERATING Shifting Procedure When the shift is complete, the position indicator light for the selected position will stop flashing and remain NOTE: • If any of the requirements to select a new transfer case position have not been met, the transfer case will not 2WD⇔...
Page 335 STARTING AND OPERATING 333 selected position indicator light will flash and the origi- 3. While still rolling, rotate the transfer case control nal position indicator light will remain ON. At this time, switch to the desired position. reduce speed and stop spinning the wheels to complete 4.
Page 336: Electronically Shifted Transfer Case (Five-Position Switch) - If Equipped
334 STARTING AND OPERATING NOTE: • If Steps 1 or 2 of either the Preferred or Alternate Procedure are not satisfied prior to attempting the shift, then the desired position indicator light will flash continuously while the original position indicator light is ON, until all requirements have been met.
Page 337 STARTING AND OPERATING 335 • Four-wheel drive low range (4WD LOW) When additional traction is required, the transfer case 4WD LOCK and 4WD LOW positions can be used to lock • Neutral (NEUTRAL) the front and rear driveshafts together forcing the front This electronically shifted transfer case is designed to be and rear wheels to rotate at the same speed.
Page 338 336 STARTING AND OPERATING Transfer Case Position Indicator Lights 2. The newly selected position indicator light will con- The Transfer Case Position Indicator Lights (4WD, tinue to flash. 4LOW, and 4WD AUTO) are located on the instrument 3. The transfer case will not shift. cluster and indicate the current and desired transfer case selection.
Page 339 STARTING AND OPERATING 337 Proper operation of four-wheel drive vehicles depends WARNING! on tires of equal size, type and circumference on each wheel. Any difference in tire size can cause damage to the Always engage the parking brake when powering transfer case.
Page 340: Shifting Procedure
338 STARTING AND OPERATING For additional information on the appropriate use of each 4WD LOW transfer case mode position, see the information below: Four-Wheel Drive Low Range - This range provides low speed four-wheel drive. Locks the front and rear drive- shafts together forcing the front and rear wheels to rotate Rear-Wheel Drive High Range - This range is for normal at the same speed.
Page 341 STARTING AND OPERATING 339 position will remain ON, and the newly selected the vehicle in motion, the transfer case will engage/ position indicator light will continue to flash until all disengage faster if you momentarily release the accelera- the requirements for the selected position have been tor pedal after turning the control switch.
Page 342: Axle Locker System (2500 Models Only) - If Equipped
340 STARTING AND OPERATING 2. Shift the transmission into NEUTRAL. NOTE: If Steps 1 or 2 of either the Preferred or Alternate Procedure are not satisfied prior to attempting the shift or 3. While still rolling, rotate the transfer case control if they no longer are being met while the shift attempt is switch to the desired position.
Page 343 STARTING AND OPERATING 341 stuck. The locking front and rear differentials should only The switch has three positions, AXLE UNLOCK, REAR be engaged during low-speed, extreme off-road situa- LOCK, and FRONT/REAR LOCK. Under normal driv- tions where one wheel is likely to not be in contact with ing conditions, the switch should be left in the AXLE the ground.
Page 344 342 STARTING AND OPERATING position to REAR LOCK while traveling less than 3 mph To lock the front axle; move the axle locker switch to (5 km/h). The RR indicator light will remain on when the FRONT/REAR LOCK while traveling less than 3 mph rear axle is locked.
Page 345: Stabilizer/Sway Bar System - Power Wagon Only
STARTING AND OPERATING 343 To unlock the rear axle; move the axle locker switch to AXLE UNLOCK. The REAR LOCK indicator light will go out when the rear axle is unlocked. STABILIZER/SWAY BAR SYSTEM — POWER WAGON ONLY Your vehicle is equipped with an electronic disconnecting stabilizer/sway bar.
Page 346 344 STARTING AND OPERATING the Off-Road position. The amber indicator light will WARNING! flash until the stabilizer/sway bar has been fully discon- nected. Do not disconnect the stabilizer bar and drive on hard surfaced roads or at speeds above 18 mph NOTE: The stabilizer/sway bar may be torque locked (29 km/h), you may lose control of the vehicle, which due to left and right suspension height differences.
Page 347: Safe Off-Road Driving - Power Wagon Only
STARTING AND OPERATING 345 (ORV) trails or recreation areas. You should always tread WARNING! lightly and only use established roads, trails or ORV recreational areas. The National Forest Service, Bureau of If the stabilizer/sway bar will not return to On-Road Land Management or local Department of Natural Re- mode, vehicle stability is greatly reduced.
Page 348 346 STARTING AND OPERATING distance up the ramp divided by the wheelbase of the CAUTION! vehicle and multiplied by 1,000 is the RTI. This vehicle has an RTI of 655, which means you can articulate one The door sill height is 25 inches. Water may intrude front wheel 32 inches in the air while the other three into the interior of the vehicle at greater depths.
Page 349 STARTING AND OPERATING 347 your vehicle’s steering, handling and traction. Control- WARNING! ling your vehicle is one of the keys to successful off-road driving, so always keep a firm grip on the steering wheel Always wear your seat belt and firmly tie down and maintain a good driving posture.
Page 350: Driving In Snow, Mud And Sand
348 STARTING AND OPERATING Driving In Snow, Mud And Sand CAUTION! There is a drastic reduction in traction when driving in snow, mud or sand. The vehicle will be less responsive to On icy or slippery roads, do not downshift at high steering, acceleration and braking inputs.
Page 351: Crossing Obstacles (Rocks And Other High Points)
STARTING AND OPERATING 349 • Sand – Soft sand is very difficult to travel through CAUTION! with full tire pressure. When crossing soft sandy spots in a trail maintain your vehicle’s momentum and do Reduced tire pressures may cause tire unseating and not stop.
Page 352 350 STARTING AND OPERATING the tire is tougher and thicker than the side wall and is WARNING! designed to take the abuse. Always look ahead and make every effort to cross the large rocks with your tires. Crossing obstacles can cause abrupt steering system loading which could cause you to loose control of CAUTION! your vehicle.
Page 353 STARTING AND OPERATING 351 caught in a rut, dig a small trench to the right or left at a CAUTION! 45-degree angle ahead of the front tires. Use the removed dirt to fill the rut ahead of the turnout you just created. Do not attempt to cross a log with a greater diameter You should now be able to drive out following the trench than the running ground clearance or the vehicle will...
Page 354: Hill Climbing
352 STARTING AND OPERATING the vehicle if something goes wrong? If everything CAUTION! looks good and you feel confident, then change trans- mission into a lower gear, shift the transfer case into 4L Winching or rocking the vehicle off hard objects (Low) and proceed with caution.
Page 355 STARTING AND OPERATING 353 fresh bite into the surface and will usually provide ability to proceed then make sure you are in 4L (Low enough traction to complete the climb. If you do not Range) with the transmission in first gear (manually make it to the top, place the vehicle in REVERSE and select first gear on automatic transmissions) and pro- back straight down the grade using engine resistance...
Page 356: Driving Through Water
354 STARTING AND OPERATING sure the surface has good traction with firm and stable WARNING! soils. If possible transverse the incline at an angle heading slightly up or down. If the engine stalls or you lose headway or cannot make it to the top of a steep hill or grade, never WARNING! attempt to turn around.
Page 357 STARTING AND OPERATING 355 your vehicle’s abilities and be able to recover it if CAUTION! something goes wrong. You should never stop or shut a vehicle off when crossing deep water unless you ingested Water ingestion into the axles, transmission, transfer water into the engine air intake.
Page 358 356 STARTING AND OPERATING crossing is the water depth, current and bottom con- CAUTION! ditions. On soft bottoms the vehicle will sink in, effectively increasing the water level on the vehicle. Be Muddy waters can reduce the cooling system effec- sure to consider this when determining the depth and tiveness by depositing debris onto the radiator.
Page 359: Airing Down For Off-Road Driving
STARTING AND OPERATING 357 downstream out of control if the water is deep enough form to the ground contour. Different terrain, tires, and to push on the large surface area of the vehicle’s body. vehicles require different tire pressure. Hard surfaces like Before you proceed determine the speed of the current, rock and heavier vehicles require higher pressures than the water’s depth, approach angle, bottom condition...
Page 360: Vehicle Recovery
358 STARTING AND OPERATING Vehicle Recovery vehicle impingement on the surroundings, then using a If you drive off-road, you may encounter a situation tow strap to the vehicle tow hooks would be fast and where you will need to recover your vehicle. Vehicle easy.
Page 361 STARTING AND OPERATING 359 • Rock Cycling Your Vehicle – Rock cycling your ve- CAUTION! hicle is one of the easiest, fastest and most commonly used methods. This simply involves shifting your Damage can occur when spinning your tires at an vehicle from DRIVE to REVERSE, while applying excessive high speed.
Page 362 360 STARTING AND OPERATING straps together using a 1 ⁄ inch hard wood dowel. WARNING! This will keep the straps from becoming knotted and is safer than using a clevis pin if the strap breaks. Next Never use tow straps with end hooks or link two have the tow vehicle backup, leaving two to three feet straps with a clevis pin.
Page 363 STARTING AND OPERATING 361 out of the situation in a slow controlled manner. This as you power the winch in. Be careful not to allow control works well for avoiding further vehicle dam- slack in the cable as you recover the vehicle. Do not try age.
Page 364: After Driving Off-Road
362 STARTING AND OPERATING • Check for accumulations of plants or brush. These After Driving Off-Road Off-road operation puts more stress on your vehicle than things could be a fire hazard. They might hide damage does most on-road driving. After going off-road, it is to fuel lines, brake hoses, axle pinion seals, and always a good idea to check for damage.
Page 365: Limited-Slip Differential
STARTING AND OPERATING 363 • If you experience unusual vibration after driving in will supply maximum traction. When starting with only mud, slush or similar conditions, check the wheels for one rear wheel on an excessively slippery surface, slight impacted material. Impacted material can cause a momentary application of the parking brake may be wheel imbalance and freeing the wheels of it will necessary to gain maximum traction.
Page 366: Driving On Slippery Surfaces
364 STARTING AND OPERATING DRIVING ON SLIPPERY SURFACES Traction When driving on wet or slushy roads, it is possible for a Acceleration wedge of water to build up between the tire and road Rapid acceleration on snow covered, wet, or other slip- surface.
Page 367: Driving Through Water
STARTING AND OPERATING 365 DRIVING THROUGH WATER Shallow Standing Water Driving through water more than a few inches/ Although your vehicle is capable of driving through centimeters deep will require extra caution to ensure shallow standing water, consider the following Caution safety and prevent damage to your vehicle.
Page 368 366 STARTING AND OPERATING CAUTION! (Continued) WARNING! • Driving through standing water may cause dam- • Driving through standing water limits your vehi- age to your vehicle’s drivetrain components. Al- cle’s traction capabilities. Do not exceed 5 mph ways inspect your vehicle’s fluids (i.e., engine oil, (8 km/h) when driving through standing water.
Page 369: Off-Road Driving Tips
STARTING AND OPERATING 367 OFF-ROAD DRIVING TIPS always a good idea to check for damage. That way you Care should be taken when attempting to climb steep can get any problems taken care of right away and have hills or driving diagonally across a hill or slope. If natural your vehicle ready when you need it.
Page 370: Winch Usage (Power Wagon Only) - If Equipped
368 STARTING AND OPERATING • After extended operation in mud, sand, water, or WINCH USAGE (POWER WAGON ONLY) — IF similar dirty conditions, have the radiator, fan, brake EQUIPPED rotors, wheels, brake linings, and axle yokes inspected Things To Know Before Using Your Winch and cleaned as soon as possible.
Page 371 STARTING AND OPERATING 369 2. Attach the hook to a suitable anchor point. Low Voltage Interrupt Your winch is equipped with a device that will interrupt CAUTION! winch function if the vehicle charging system voltage drops to a low level. The winch will not power-in or out Be certain the anchor will withstand the load re- for 30 seconds if this device is tripped.
Page 372: Understanding The Features Of Your Winch
370 STARTING AND OPERATING Understanding The Features Of Your Winch Winch Components...
Page 373 STARTING AND OPERATING 371 1. Motor: The winch motor is powered by the vehicle 6. Clutch Lever: The clutch lever allows the winch drum charging system and features a thermal protection switch to be disconnected from the winch motor to allow the that automatically stops motor function in the power-in wire rope to be pulled from the winch by hand.
Page 374: Winch Accessories
372 STARTING AND OPERATING Winch Accessories Snatch/Block Pulley: Used properly, the multi-purpose The following accessories are necessary to attach the snatch block allows you to (1) winch to anchors, change direction of pull, and for safe increase the winch’s pulling winching.
Page 375: Operating Your Winch
STARTING AND OPERATING 373 Clevis/D-Shackles: Operating Your Winch D-Shackle is a safe means of WARNING! connecting the looped ends of cables, straps and snatch Failure to observe any of these warnings regarding blocks. The shackle’s pin is proper winch usage may result in severe injury. threaded to allow easy re- •...
Page 376 374 STARTING AND OPERATING WARNING! (Continued) WARNING! (Continued) • Always stand clear of wire rope and load and keep • Always disconnect the remote control when not in others away during winching. use. • Always keep hands and clothing clear of the wire •...
Page 377 STARTING AND OPERATING 375 3. Use the right equipment for the situation. CAUTION! (Continued) 4. Always wear leather gloves and do not allow the wire • Always inspect winch installation and wire rope rope to slip through your hands when handling the rope. condition before operating the winch.
Page 378 376 STARTING AND OPERATING 3. Disengage the clutch to allow free spooling of the winch drum, rotate the clutch lever on the winch to disengage. Freespooling conserves battery power. 1. Inspect the winch, winch mount, and wire rope for damage. Do not use the winch if the mount is loose or rope shows excessive wear or damage.
Page 379 STARTING AND OPERATING 377 4. Free the winch hook and attach the hook strap. Free and over-wrapped when slackened, leading to wire rope the winch hook from its anchor point. Attach the hook damage. To prevent losing the end, hold the hook strap strap to the hook (if not attached).
Page 380 378 STARTING AND OPERATING NOTE: How to choose an anchor point: A secure anchor is critical to winching operations. An anchor must be strong enough to hold while winching. Natural an- chors include trees, stumps and rocks. Hook the cable as low as possible.
Page 381 STARTING AND OPERATING 379 9. Connect the remote control to the winch control box, located behind the front bumper. Be careful not to let the remote control cord dangle in front of the winch. If you choose to control the winch from inside your vehicle, always pass the remote through a window to avoid pinching the cord in the door.
Page 382 380 STARTING AND OPERATING 10. Put wire rope under tension. Using the remote con- 12. Check wire rope. The wire rope should be neatly trol switch, slowly wind the wire rope until no slack wound around the spooling drum. Improper winding remains.
Page 383 STARTING AND OPERATING 381 13. In certain situations you the vehicle and never near the wire rope or snatch may decide to throw a heavy block. Your situation may have other no people zones. blanket or similar object over the wire rope. A heavy blan- ket can absorb energy should the wire rope break.
Page 384 382 STARTING AND OPERATING For additional assistance, the winched vehicle can be NOTE: • Avoid overheating the winch motor. For extended slowly driven while being pulled by the winch. Continue pulling until the vehicle is on stable ground. If you are winching, stop at reasonable intervals to allow the able to drive the vehicle, the winching operation is winch motor to cool down.
Page 385 STARTING AND OPERATING 383 section of the rope and reposition it to the opposite end of the drum, which will free up space for continued winching. 16. Secure vehicle. Once recovery of the vehicle’s is complete, be sure to secure the vehicle’s brakes and put the transmission in PARK.
Page 386 384 STARTING AND OPERATING Arrange the wire rope so it will not kink or tangle when spooled. Be sure any wire rope already on the spooling drum is wound tightly and evenly layered. Tighten and straighten the layer if necessary. Keep the wire rope under light tension and spool the wire rope back and onto the winch drum in even layers.
Page 387: Rigging Techniques
STARTING AND OPERATING 385 Rigging Techniques How to Change the Pulling Direction Various winching situations will require application of other winching techniques. These could range from too little distance to achieve maximum pull using straight line rigging, simply increasing pulling power, or main- taining a straight-line pulling situation.
Page 388 386 STARTING AND OPERATING All winching operations should have a straight line from Double Line the winch to the object being pulled. This minimizes the wire rope collecting on one side of the drum affecting pulling efficiency and damaging wire rope. A snatch block, secured to a point directly in front of the vehicle will enable you to change your pulling direction while still allowing the wire rope to be at 90°...
Page 389: Power Steering
STARTING AND OPERATING 387 vehicle’s frame/tow hook and run the wire rope through NOTE: • Increased noise levels at the end of the steering wheel a snatch block. Disengage the clutch and, using the snatch block, pull out enough wire to reach your anchor travel are considered normal and do not indicate that point.
Page 390: Power Steering Fluid Check
388 STARTING AND OPERATING CAUTION! CAUTION! Prolonged operation of the steering system at the end Do not use chemical flushes in your power steering of the steering wheel travel will increase the steering system as the chemicals can damage your power fluid temperature and it should be avoided when steering components.
Page 391: Multi-Displacement System (Mds) (If Equipped) - 5.7L Engine Only
STARTING AND OPERATING 389 MULTI-DISPLACEMENT SYSTEM (MDS) (IF EQUIPPED) — 5.7L ENGINE ONLY This feature offers improved fuel economy by shutting off four of the engine’s eight cylinders during light load and cruise conditions. The system is automatic with no driver inputs or additional driving skills required.
Page 392 390 STARTING AND OPERATING NOTE: WARNING! • When the parking brake is applied and the transmis- • Never use the PARK position as a substitute for sion is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound the parking brake.
Page 393: Brake System
STARTING AND OPERATING 391 substantial increase in braking effort to stop the vehicle. WARNING! (Continued) If either the front or rear hydraulic system loses normal • Always fully apply the parking brake when leav- braking capability, the remaining system will still func- ing your vehicle or it may roll and cause damage or tion with some loss of overall braking effectiveness.
Page 394: Electronic Brake Control System
392 STARTING AND OPERATING ELECTRONIC BRAKE CONTROL SYSTEM WARNING! Your vehicle is equipped with an advanced electronic • ABS cannot prevent the natural laws of physics brake control system that includes Anti-Lock Brake Sys- tem (ABS), Traction Control System (TCS), Brake Assist from acting on the vehicle, nor can it increase System (BAS), Hill Start Assist (HSA), Electronic Stability braking or steering efficiency beyond that af-...
Page 395: Brake Assist System (Bas) - If Equipped
STARTING AND OPERATING 393 pressure is applied to the slipping wheel(s), and engine applies optimum pressure to the brakes. The system power is reduced to provide enhanced acceleration and applies optimum pressure to the brakes in emergency stability. A feature of the TCS functions similarly to a braking conditions.
Page 396: Hill Start Assist (Hsa) - If Equipped
394 STARTING AND OPERATING and the vehicle will roll down the incline. The system will WARNING! (Continued) release brake pressure in proportion to the amount of • The BAS cannot prevent collisions, including throttle applied. those resulting from excessive speed in turns, During operation, HSA will activate the brake control following another vehicle too closely, or hydro- system and a clicking noise may occur.
Page 397 STARTING AND OPERATING 395 Towing and Hauling with HSA WARNING! The HSA system does not know if your vehicle is loaded or towing a trailer unless the TOW/HAUL switch, lo- There may be situations on minor hills (i.e., less than cated on the center stack, is selected.
Page 398 396 STARTING AND OPERATING WARNING! WARNING! (Continued) • HSA is not a parking brake. If you stop the vehicle • If you use a trailer brake controller with your on a hill without putting the transmission in trailer, your trailer brakes may be activated and PARK or using the parking brake, it will roll down deactivated with the brake switch.
Page 399: Electronic Stability Control (Esc) - If Equipped
STARTING AND OPERATING 397 3. With the engine running and the brake applied, rotate EVIC Equipped Vehicles the steering wheel 180° counterclockwise from center. HSA is a Customer Programmable Feature on a EVIC equipped vehicle. If you wish to turn off the HSA feature, 4.
Page 400 398 STARTING AND OPERATING ESC uses sensors in the vehicle to determine the vehicle All Two-Wheel Drive Vehicles and Four-Wheel path intended by the driver and compares it to the actual Drive Vehicles in 2WD, 4WD AUTO, or 4WD path of the vehicle. When the actual path does not match LOCK Modes Can Choose the Following ESP the intended path, ESC applies the brake of the appro- Operating Modes:...
Page 401 STARTING AND OPERATING 399 Indicator Light will be illuminated. All other stability WARNING! features of ESC function normally. This mode is intended to be used if the vehicle is in deep snow, sand, or gravel In the “Partial Off” mode, the engine torque reduc- conditions and more wheel spin than ESC would nor- tion and stability features are desensitized.
Page 402 400 STARTING AND OPERATING and the “ESC Off” message will appear in the odometer. when ESC is off. To turn ESC on again, momentarily Press and release the trip odometer button located on the press the “ESC Off” switch. This will restore the normal instrument cluster to clear this message.
Page 403: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
STARTING AND OPERATING 401 ESC Activation/Malfunction Indicator Light and Malfunction Indicator Light” begins to flash during ac- ESC OFF Indicator Light celeration, ease up on the accelerator and apply as little The “ESC Activation/Malfunction Indicator throttle as possible. Be sure to adapt your speed and Light”...
Page 404: Trailer Sway Control (Tsc) - If Equipped
402 STARTING AND OPERATING Trailer Sway Control (TSC) – If Equipped TSC is only active in the default “ESC On” mode. TSC The TSC system uses sensors in the vehicle to recognize can be disabled by pressing the “ESC Off” switch and an excessively swaying trailer and will take the appro- entering “ESC Partial Off”...
Page 405: Tire Safety Information
STARTING AND OPERATING 403 TIRE SAFETY INFORMATION NOTE: • P (Passenger) - Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 406 404 STARTING AND OPERATING • High flotation tire sizing is based on U.S. design Tires designed to this standard have the letter “T” molded into the sidewall preceding the size designa- standards and it begins with the tire diameter molded tion.
Page 407 STARTING AND OPERATING 405 EXAMPLE: Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 408: Tire Identification Number (Tin)
406 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 409: Tire Terminology And Definitions
STARTING AND OPERATING 407 Tire Terminology and Definitions Term Definition B-Pillar The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof. Cold Tire Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 410: Tire Loading And Tire Pressure
408 STARTING AND OPERATING Tire Loading And Tire Pressure Tire and Loading Information Placard Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle Tire Placard Location...
Page 411 STARTING AND OPERATING 409 To determine the maximum loading conditions of your 3) tire size designed for your vehicle vehicle, locate the statement “The combined weight of 4) cold tire inflation pressures for the front, rear, and occupants and cargo should never exceed XXX lbs or spare tires.
Page 412 410 STARTING AND OPERATING 4. The resulting figure equals the available amount of NOTE: • The following table shows examples on how to calcu- cargo and luggage load capacity. For example, if “XXX” amount equals 1,400 lbs (635 kg) and there will be five late total load, cargo/luggage, and towing capacities 150 lb (68 kg) passengers in your vehicle, the amount of of your vehicle with varying seating configurations...
Page 413 STARTING AND OPERATING 411...
Page 414: Tires - General Information
412 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 415: Tire Inflation Pressures
STARTING AND OPERATING 413 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side “B” Pillar. hicle to the other can cause the vehicle to drift to Some vehicles may have Supplemental Tire Pressure the right or left.
Page 416 414 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the Winter.
Page 417: Tire Pressures For High Speed Operation
STARTING AND OPERATING 415 Tire Pressures For High Speed Operation Radial Ply Tires The manufacturer advocates driving at safe speeds WARNING! within posted speed limits. Where speed limits or condi- tions are such that the vehicle can be driven at high Combining radial ply tires with other types of tires speeds, maintaining correct tire inflation pressure is very on your vehicle will cause your vehicle to handle...
Page 418: Spare Tire Matching Original Equipped Tire And Wheel - If Equipped
416 STARTING AND OPERATING Spare Tire Matching Original Equipped Tire and CAUTION! Wheel – If Equipped The spare tire of your vehicle is equivalent in look and Because of the reduced ground clearance, do not take function as the original equipment tire and wheel found your vehicle through an automatic car wash with a on the front or rear axle of your vehicle.
Page 419: Full Size Spare - If Equipped
STARTING AND OPERATING 417 Since this tire has limited tread life the original equip- Full Size Spare – If Equipped ment tire should be repaired (or replaced) and reinstalled The full size spare is for temporary emergency use only. on your vehicle at the first opportunity. This tire may look like the original equipped tire on the front or rear axle of your vehicle, but it is not.
Page 420: Tire Spinning
418 STARTING AND OPERATING your original equipment tire, replace (or repair) the Tire Spinning original equipment tire and reinstall on the vehicle at the When stuck in mud, sand, snow, or ice conditions, do not first opportunity. spin your vehicle’s wheels faster than 30 mph (48 km/h) or for longer than 30 seconds continuously without WARNING! stopping when you are stuck.
Page 421: Tread Wear Indicators
STARTING AND OPERATING 419 Tread Wear Indicators These indicators are molded into the bottom of the tread Tread wear indicators are in the original equipment tires grooves. They will appear as bands when the tread depth to help you in determining when your tires should be becomes 1/16 in (2 mm).
Page 422: Replacement Tires
420 STARTING AND OPERATING Replacement Tires WARNING! The tires on your new vehicle provide a balance of many characteristics. They should be inspected regularly for Tires and the spare tire should be replaced after six wear and correct cold tire inflation pressure. The manu- years, regardless of the remaining tread.
Page 423: Supplemental Tire Pressure Information - If Equipped
STARTING AND OPERATING 421 WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 424: Tire Chains
422 STARTING AND OPERATING TIRE CHAINS CAUTION! (Continued) Use “Class S” chains, or other traction aids that meet SAE • Because of limited chain clearance between tires Type “S” specifications. and other suspension components, it is important Use “Class U” chains on 2500/3500 model trucks, or that only chains in good condition are used.
Page 425 STARTING AND OPERATING 423 • On 4x2 2500 model trucks, the use of class “U” snow CAUTION! (Continued) chains is permitted on the rear wheels only of trucks • Observe the tire chain manufacturer’s instructions equipped with LT245/70R17E or LT265/70R17E tires. on method of installation, operating speed, and •...
Page 426: Snow Tires
424 STARTING AND OPERATING If you need snow tires, select tires equivalent in size and CAUTION! type to the original equipment tires. Use snow tires only in sets of four; failure to do so may adversely affect the Do not use tire chains on the front wheels of any safety and handling of your vehicle.
Page 427: Tire Rotation Recommendations
STARTING AND OPERATING 425 TIRE ROTATION RECOMMENDATIONS The suggested rotation method is the “forward cross” Tires on the front and rear axles of vehicles operate at shown in the following diagram. This rotation pattern different loads and perform different steering, driving, does not apply to some directional tires that must not be and braking functions.
Page 428: Directional Tires - If Equipped
426 STARTING AND OPERATING Directional Tires – If Equipped Dual Rear Wheels For the R/T package with 22” tires & wheels, tire rotation must be performed with consideration of the tire rotation direction. The recommended rotation pattern for direc- tional tires is shown below. Tire Rotation The tires used on dual wheel assemblies should be matched for wear to prevent overloading one tire in a set.
Page 429: Tire Pressure Monitor System (Tpms)
STARTING AND OPERATING 427 TIRE PRESSURE MONITOR SYSTEM (TPMS) CAUTION! The Tire Pressure Monitor System (TPMS) will warn the driver of a low tire pressure based on the vehicle recom- 3500 Dual Rear Tires have only one approved direc- mended cold placard pressure. tion of rotation.
Page 430 428 STARTING AND OPERATING The TPMS will warn the driver of a low tire pressure if For example, your vehicle may have a recommended the tire pressure falls below the low-pressure warning cold (parked for more than three hours) placard pressure limit for any reason, including low temperature effects of 30 psi (207 kPa).
Page 431 STARTING AND OPERATING 429 NOTE: CAUTION! • The TPMS is not intended to replace normal tire care • The TPMS has been optimized for the original and maintenance or to provide warning of a tire failure or condition. equipment tires and wheels. TPMS pressures and warning have been established for the tire size •...
Page 432: Base System
430 STARTING AND OPERATING • Seasonal temperature changes will affect tire pressure, The matching full size spare wheel and tire assembly (if and the TPMS will monitor the actual tire pressure in equipped) has a TPM sensor. The matching full size spare the tire.
Page 433 STARTING AND OPERATING 431 turn off. The vehicle may need to be driven for up to 3. Accumulation of snow or ice around the wheels or 20 minutes above 15 mph (24 km/h) in order for the wheel housings. TPMS to receive this information. 4.
Page 434: Premium System - If Equipped
432 STARTING AND OPERATING Premium System – If Equipped The matching full size spare wheel and tire assembly (if The Tire Pressure Monitor System (TPMS) uses wireless equipped) has a TPM sensor. The full size spare can be technology with wheel rim mounted electronic sensors to used in place of any of the four road tires.
Page 435 STARTING AND OPERATING 433 Should this occur, you should stop as soon as possible and inflate the tires with a low pressure condition (those flashing in the EVIC graphic) to the vehicle’s recom- mended cold placard pressure inflation value. Once the system receives the updated tire pressures, the system will automatically update, the graphic display in the EVIC will stop flashing, and the TPM Telltale Light will...
Page 436 434 STARTING AND OPERATING Check TPMS Warning If the ignition switch is cycled, this sequence will repeat, If a system fault is detected, the TPM Telltale Light will flash providing the system fault still exists. If the system fault on and off for 75 seconds and then remain on solid. The no longer exists, the TPM Telltale Light will no longer system fault will also sound a chime.
Page 437: Tire Pressure Monitor System (Tpms) Tire Light Load Inflation Switch Description (2500 Models) - If Equipped
STARTING AND OPERATING 435 Vehicles with Full Size Spare Tire Pressure Monitor System (TPMS) Tire Light Load Inflation Switch Description (2500 Models) – 1. The matching full size spare wheel and tire assembly If Equipped has a TPM sensor that can be monitored by the TPMS. WARNING! 2.
Page 438 436 STARTING AND OPERATING The TPMS tire light load inflation switch will allow the driver to switch between the max load inflation pressure (cold) low pressure warning threshold and the light load inflation pressure (cold) low pressure warning threshold depending on the vehicle’s load condition. The Tire and Loading Information label defines the recommended front and rear cold tire inflation pressures for the vehicle when operating in the Max Load condition.
Page 439 STARTING AND OPERATING 437 Tire Light Load Inflation Switch Operation – If Equipped • This vehicle may have different recommended tire pressure values between the front and rear tires as shown in both the Tire Loading Information Label and the Supplemental Tire Pressure Information Label. It is also equipped to be driven with tire pressures appro- priate to either a Light Load condition or the vehicle Max Load condition.
Page 440 438 STARTING AND OPERATING Tire Pressure Information label. The Supplemental Tire the rear face of the driver door. Using an accurate tire Pressure Information label is located on the rear face of pressure gauge, re-check the tire pressures for the light the driver door opening.
Page 441: General Information
STARTING AND OPERATING 439 • This device may not cause harmful interference. the max load inflation pressure (cold) values to switch the TPMS system to the max load inflation pressure • This device must accept any interference received, (cold) low pressure warning threshold. If after pressing including interference that may cause undesired the tire light load inflation switch, and tire pressures are operation.
Page 442: 5.7L Engine
440 STARTING AND OPERATING use of premium gasoline is not recommended, as it will as hard starting, stalling, and hesitations. If you experi- not provide any benefit over regular gasoline in these ence these symptoms, try another brand of gasoline engines.
Page 443: Gasoline/Oxygenate Blends
STARTING AND OPERATING 441 The manufacturer supports the use of reformulated gaso- Problems that result from using gasoline containing lines. Properly blended reformulated gasolines will pro- Methanol or gasoline containing more than 10% Ethanol vide excellent performance and durability for the engine are not the responsibility of the manufacturer and may and fuel system components.
Page 444: Mmt In Gasoline
442 STARTING AND OPERATING To fix a Non-FFV vehicle inadvertently fueled once with of gasoline may not be indicated on the gasoline pump, E-85 perform the following: therefore, you should ask your gasoline retailer whether or not his/her gasoline contains MMT. It is even more •...
Page 445: Fuel System Cautions
STARTING AND OPERATING 443 Fuel System Cautions CAUTION! (Continued) • The use of fuel additives, which are now being CAUTION! sold as octane enhancers are not recommended. Follow these guidelines to maintain your vehicle’s Most of these products contain high concentra- performance: tions of methanol.
Page 446: Carbon Monoxide Warnings
444 STARTING AND OPERATING Carbon Monoxide Warnings WARNING! (Continued) • Guard against carbon monoxide with proper WARNING! maintenance. Have the exhaust system inspected Carbon monoxide (CO) in exhaust gases is deadly. every time the vehicle is raised. Have any abnor- Follow the precautions below to prevent carbon mal conditions repaired promptly.
Page 447: Ethanol Fuel (E-85)
STARTING AND OPERATING 445 E-85 Fuel Cap E-85 Badge Ethanol Fuel (E-85) CAUTION! E-85 is a mixture of approximately 85% fuel ethanol and 15% unleaded gasoline. Only vehicles with the E-85 fuel filler door label can operate on E-85.
Page 448: Fuel Requirements
446 STARTING AND OPERATING When you do switch fuel types it is recommended that: WARNING! • you do not switch when the fuel gauge indicates less Ethanol vapors are extremely flammable and could than 1/4 full cause serious personal injury. Never have any smok- •...
Page 449: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles
(mpg)/miles per liter and your driving range to decrease tensive fleet testing, to provide additional protection to by about 30%, compared to gasoline operation. Chrysler Group LLC engines. Use MOPAR or an equivalent oil meeting the specification MS-6395.
Page 450: Maintenance
448 STARTING AND OPERATING Replacement Parts ADDING FUEL Many components in your Flexible Fuel Vehicle (FFV) are The fuel filler cap (gas cap) is located behind the fuel filler designed to be compatible with ethanol. Always be sure door, on the left side of the vehicle. Open the fuel door and that your vehicle is serviced with correct ethanol com- remove the fuel cap by turning it counter-clockwise.
Page 451 STARTING AND OPERATING 449 CAUTION! WARNING! • Damage to the fuel system or emissions control • Never have any smoking materials lit in or near system could result from using an improper fuel the vehicle when the gas cap is removed or the tank filler tube cap (gas cap).
Page 452: Loose Fuel Filler Cap Message
450 STARTING AND OPERATING • When the fuel nozzle “clicks” or shuts off, the fuel This label contains the month and year of manufacture, tank is full. Gross Vehicle Weight Rating (GVWR), Gross Axle Weight Rating (GAWR) front and rear, and Vehicle Identification Loose Fuel Filler Cap Message Number (VIN).
Page 453 STARTING AND OPERATING 451 Gross Axle Weight Rating (GAWR) Inflation Pressure The GAWR is the maximum permissible load on the front This is the cold tire inflation pressure for your vehicle for and rear axles. The load must be distributed in the cargo all loading conditions up to full GAWR.
Page 454: Trailer Towing
452 STARTING AND OPERATING The entire vehicle should first be weighed on a commer- CAUTION! cial scale to insure that the GVWR has not been exceeded. The weight on the front and rear of the vehicle should Do not load your vehicle any heavier than the GVWR then be determined separately to be sure that the load is or the maximum front and rear GAWR.
Page 455: Common Towing Definitions
STARTING AND OPERATING 453 Common Towing Definitions Gross Combination Weight Rating (GCWR) The following trailer towing related definitions will assist The GCWR is the total permissible weight of your vehicle you in understanding the following information: and trailer when weighed in combination. Gross Vehicle Weight Rating (GVWR) NOTE: The GCWR rating includes a 150 lbs (68 kg) The GVWR is the total allowable weight of your vehicle.
Page 456 454 STARTING AND OPERATING that typically provides adjustable friction associated with WARNING! the telescoping motion to dampen any unwanted trailer swaying motions while traveling. It is important that you do not exceed the maximum front or rear GAWR. A dangerous driving condition Weight-Carrying Hitch can result if either rating is exceeded.
Page 457 STARTING AND OPERATING 455 safety. The addition of a friction/hydraulic sway control also dampens sway caused by traffic and crosswinds and contributes positively to tow vehicle and trailer stability. Trailer sway control and a weight distributing (load equalizing) hitch are recommended for heavier Tongue Weights (TW) and may be required depending on vehicle and trailer configuration/loading to comply with GAWR requirements.
Page 458 456 STARTING AND OPERATING EXAMPLE — With Weight-Distributing Hitch (Correct) EXAMPLE — Improper Adjustment of Weight- Distributing Hitch (Incorrect) Fifth-Wheel Hitch The fifth-wheel hitch is a special high platform with a coupling that mounts over the rear axle of the tow vehicle in the truck bed.
Page 459: Trailer Hitch Classification
STARTING AND OPERATING 457 Gooseneck Hitch Trailer Hitch Classification Definitions The gooseneck hitch employs a pivoted coupling arm Class Max. Trailer Hitch Industry which attaches to a ball mounted in the bed of a pickup Standards truck. The coupling arm connects to the hitch mounted Class I - Light Duty 2,000 lbs (907 kg) over the rear axle in the truck bed.
Page 460: Trailer Towing Weights (Maximum Trailer Weight Ratings)
458 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) NOTE: For additional trailer towing information in- cluding maximum trailer and tongue weight rating for your vehicle, refer to the following website addresses: • http:// www.dodge.com/bodybuilder. • http:// www.dodge.ca (Canada). Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer.
Page 461: Towing Requirements
STARTING AND OPERATING 459 NOTE: Remember that everything put into or on the CAUTION! trailer adds to the load on your vehicle. Also, additional • Do not tow a trailer at all during the first 500 miles factory-installed options or dealer-installed options must be considered as part of the total load on your vehicle.
Page 462 460 STARTING AND OPERATING WARNING! WARNING! (Continued) • Safety chains must always be used between your Improper towing can lead to a collision. Follow these vehicle and trailer. Always connect the chains to guidelines to make your trailer towing as safe as the hook retainers of the vehicle hitch.
Page 463 STARTING AND OPERATING 461 • Check the trailer tires for proper tire inflation pres- WARNING! (Continued) sures before trailer usage. 2. GTW • Check for signs of tire wear or visible tire damage 3. GAWR before towing a trailer. Refer to “Tires – General 4.
Page 464 462 STARTING AND OPERATING • An electronically actuated trailer brake controller is WARNING! required when towing a trailer with electronically • Do not connect trailer brakes to your vehicle’s actuated brakes. When towing a trailer equipped with a hydraulic surge actuated brake system, an electronic hydraulic brake lines.
Page 465 STARTING AND OPERATING 463 NOTE: This module has been designed and verified for The user interface consists of the following: electric trailer brakes. To determine the type of brakes on GAIN/ Brake Output Power Display your trailer, check with your trailer manufacturer or Shows the current GAIN setting.
Page 466 464 STARTING AND OPERATING Manual Brake Control Lever If a fault is detected in the trailer wiring or the Integrated Slide the manual brake control lever to the right to Trailer Brake Module (ITBM), the “Trailer Brake Status activate power to the trailer’s electric brakes independent Indicator Light”...
Page 467 STARTING AND OPERATING 465 Adjusting GAIN 5. In a traffic-free environment, tow the trailer on a dry, level surface at a speed of 20–25 mph (30–40 km/h) and NOTE: This should only be performed in a traffic free squeeze the manual brake control lever completely. environment at speeds of approximately 20–25 mph (30–40 km/h).
Page 468 466 STARTING AND OPERATING NOTE: CAUTION! • An aftermarket controller may be available for use with trailers with air or electric-over-hydraulic trailer The ITBM module has been designed and verified brake systems. To determine the type of brakes on for electric trailer brakes. Connecting a trailer that is your trailer and the availability of controllers, check not compatible with the ITBM system may result in with your trailer manufacturer or dealer.
Page 469 STARTING AND OPERATING 467 Towing Requirements – Trailer Lights and Wiring Whenever you pull a trailer, regardless of the trailer size, stop lights and turn signals on the trailer are required for motoring safety. The Trailer Tow Package will include a four and seven- pin wiring harness.
Page 470: Towing Tips
468 STARTING AND OPERATING WARNING! Any work done to the vehicle’s electrical system or wiring should be performed by a qualified automo- tive technician. If done improperly it may cause damage to the electrical system wiring and could result in serious or fatal injury. Towing Tips Before setting out on a trip, practice turning, stopping and backing the trailer up in an area away from heavy...
Page 471 STARTING AND OPERATING 469 NOTE: Using “TOW/HAUL” mode or a lower gear Electronic Speed Control – If Equipped range while operating the vehicle under heavy operating − Do not use in hilly terrain or with heavy loads. conditions will improve performance and extend trans- −...
Page 472: Snowplow
470 STARTING AND OPERATING SNOWPLOW WARNING! 1500 Models Only Attaching a snowplow to this vehicle could adversely NOTE: Do not use this model vehicle for snowplow affect performance of the airbag system in a collision. applications. Do not expect that the airbag will perform as de- scribed earlier in this manual WARNING! 2500/3500 Models Only...
Page 473 STARTING AND OPERATING 471 • Check the runners and cutting edge for excessive wear. WARNING! The cutting edge should be 1/4 to 1/2 in (6 cm to 1.2 cm) above ground in snow plowing position. Attaching a snowplow to this vehicle could adversely affect performance of the airbag system in a collision.
Page 474 472 STARTING AND OPERATING The loaded vehicle weight, including the snowplow Maintain and operate your vehicle and snowplow equip- system, all aftermarket accessories, driver, passengers, ment following the recommendations provided by the options, and cargo, must not exceed either the Gross specific snowplow manufacturer.
Page 475 STARTING AND OPERATING 473 NOTE: During snowplow usage on vehicles equipped When plowing snow, to avoid transmission and drive- with outside temperature display, the display may show train damage, the following precautions should be ob- higher temperatures than the outside ambient tempera- served.
Page 476: Recreational Towing (Behind Motorhome, Etc.)
474 STARTING AND OPERATING RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle Towing Condition Wheels OFF the Two-Wheel Drive Four-Wheel Drive Models Ground Models See Instructions • Automatic transmission in PARK • Manual transmission in gear Flat Tow NONE NOT ALLOWED (NOT in NEUTRAL (N)
Page 477: Recreational Towing - Two-Wheel Drive Models
STARTING AND OPERATING 475 Recreational Towing – Two-Wheel Drive Models 6. Install a suitable clamping device, designed for tow- DO NOT flat tow this vehicle. Damage to the drivetrain ing, to secure the front wheels in the straight position. will result. CAUTION! Recreational towing (for two-wheel drive models) is •...
Page 478 476 STARTING AND OPERATING must be placed in gear (NOT in NEUTRAL) for recre- CAUTION! (Continued) ational towing. Refer to the following for the proper • Before recreational towing, perform the procedure transfer case NEUTRAL shifting procedure for your outlined under “Shifting Into NEUTRAL” to be vehicle.
Page 479 STARTING AND OPERATING 477 Shifting Into Neutral (N) – Manual Shift Transfer CAUTION! Case (If Equipped) Use the following procedure to prepare your vehicle for It is necessary to follow these steps to be certain that recreational towing. the transfer case is fully in Neutral (N) before recre- ational towing to prevent damage to internal parts.
Page 480 478 STARTING AND OPERATING 8. Release the brake pedal (and clutch pedal on manual 13. Remove the key fob from the ignition switch. transmissions) for five seconds and ensure that there is 14. Attach the vehicle to the tow vehicle using a suitable no vehicle movement.
Page 481 STARTING AND OPERATING 479 6. Shift the transfer case lever to the desired position. Shifting Into Neutral – Electronic Shift Transfer Case (If Equipped) NOTE: When shifting out of transfer case Neutral (N), Use the following procedure to prepare your vehicle for turning the engine OFF may be required to avoid gear recreational towing: clash.
Page 482 480 STARTING AND OPERATING light will blink while the shift is in progress. The light CAUTION! will stop blinking (stay on solid) when the shift to NEUTRAL is complete. It is necessary to follow these steps to be certain that the transfer case is fully in NEUTRAL before recre- 7.
Page 483 STARTING AND OPERATING 481 14. Shift the transmission into PARK or place manual NOTE: • The transfer case cannot be shifted into NEUTRAL transmission in gear (not in Neutral). from the 4WD AUTO (if equipped) position. CAUTION! • Steps 1 through 5 are requirements that must be met prior to pressing the NEUTRAL button, and must Damage to the transmission may occur if the trans- continue to be met until the shift has been completed.
Page 484 482 STARTING AND OPERATING Shifting Out of Neutral – Electronic Shift Transfer 8. After the NEUTRAL button has been released, the Case (If Equipped) transfer case will shift to the position identified by the Use the following procedure to prepare your vehicle for selector switch.
Page 485 STARTING AND OPERATING 483 • The ignition switch must be in the ON/RUN position 15. Shift the transmission into gear, release the brake pedal (and clutch pedal on manual transmissions), and for a transfer case shift to take place and for the check that the vehicle operates normally.
Page 487: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....487 Hoisting ......506 Jacking And Tire Changing .
Page 488 486 WHAT TO DO IN EMERGENCIES ▫ Two-Wheel Drive Models ....516 Towing A Disabled Vehicle ....514 ▫...
Page 489: Hazard Warning Flashers
WHAT TO DO IN EMERGENCIES 487 HAZARD WARNING FLASHERS JACKING AND TIRE CHANGING The Hazard Warning flasher switch is located on the WARNING! upper switch bank just below the radio. • Do not attempt to change a tire on the side of the Press the switch to turn on the Hazard Warning flasher.
Page 490: Jack Location
488 WHAT TO DO IN EMERGENCIES WARNING! (Continued) • The jack is designed to be used as a tool for changing tires only. The jack should not be used to lift the vehicle for service purposes. The vehicle should be jacked on a firm level surface only. Avoid ice or slippery areas.
Page 491 WHAT TO DO IN EMERGENCIES 489 Jack And Tools (1500 Series) Jack And Tools (2500/3500 Series)
Page 492 490 WHAT TO DO IN EMERGENCIES WARNING! After using the jack and tools, always reinstall them in the original carrier and location. While driving you may experience abrupt stopping, rapid accelera- tion or sharp turns. A loose jack, tools, bracket or other objects in the vehicle may move around with force, resulting in serious injury.
Page 493 WHAT TO DO IN EMERGENCIES 491 Folding Flap And Rolling Bag Tying Bag To Jack With Straps...
Page 494 492 WHAT TO DO IN EMERGENCIES 4. Place the jack and tools in the storage position holding the jack by the jack turn-screw, slip the jack and tools under the seat so that the bottom slot engages into the fastener on the floor, and then secure to the floor pan using the wing bolt.
Page 495: Removing The Spare Tire
WHAT TO DO IN EMERGENCIES 493 Removing The Spare Tire Remove the spare tire before attempting to jack up the truck. Attach the wheel wrench to the jack extension tube. Insert the tube through the access hole between the lower tailgate and the top of the bumper and into the winch mechanism tube.
Page 496: Preparations
494 WHAT TO DO IN EMERGENCIES NOTE: The winch mechanism is designed for use with the jack extension tube only. Use of an air wrench or other power tools is not recommended and can damage the winch. Preparations 1. Park the vehicle on a firm, level surface. Avoid ice or slippery areas.
Page 497: Instructions
WHAT TO DO IN EMERGENCIES 495 4. Place the shift lever into PARK. On four-wheel drive Instructions vehicles, shift the transfer case to the 4L position. WARNING! 5. Turn the ignition OFF. Carefully follow these tire changing warnings to 6. Block both the front and rear of the help prevent personal injury or damage to your wheel diagonally opposite the jacking vehicle:...
Page 498 496 WHAT TO DO IN EMERGENCIES WARNING! (Continued) CAUTION! • Do not let anyone sit in the vehicle when it is on a Do not attempt to raise the vehicle by jacking on jack. locations other than those indicated in the Jacking •...
Page 499 WHAT TO DO IN EMERGENCIES 497 4X4 Jacking Location 4X2 Jacking Location Operate the jack using the jack drive tube and the wheel wrench. The tube extension may be used but is not required.
Page 500 498 WHAT TO DO IN EMERGENCIES For 4x2 and 4x4 trucks, when changing a rear wheel, CAUTION! assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the Before raising the wheel off the ground, make sure axle between the wheel and the shock bracket with the that the jack will not damage surrounding truck parts drive tubes extending to the rear.
Page 501 WHAT TO DO IN EMERGENCIES 499 For 2500/3500 4x4 series trucks, when changing the front wheel, assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the axle as close to the tire as possible with the drive tubes extending to the front.
Page 502 500 WHAT TO DO IN EMERGENCIES For 4x2 and 4x4 trucks, when changing a rear wheel, CAUTION! assemble the jack drive tube to the jack and connect the drive tube to the extension tube. Place the jack under the Before raising the wheel off the ground, make sure axle between the spring and the shock absorber with the that the jack will not damage surrounding truck parts drive tubes extending to the rear.
Page 503 WHAT TO DO IN EMERGENCIES 501 5. Remove the wheel nuts and pull the wheel off. On WARNING! single rear-wheel (SRW) trucks, install the spare wheel and wheel nuts with the cone shaped end of the wheel A loose tire or jack thrown forward in a collision or nuts toward the wheel.
Page 504: Hub Caps/Wheel Covers - If Equipped
502 WHAT TO DO IN EMERGENCIES Hub Caps/Wheel Covers — If Equipped CAUTION! The hub caps must be removed before raising the vehicle • Use a back-and-forth motion to remove the hub off the ground. cap. Do not use a twisting motion when removing For 2500/3500 single rear-wheel (SRW) models, use the the hub cap, damage to the hub cap finish may blade on the end of the lug wrench to pry the hub cap off.
Page 505: Wheel Nuts
WHAT TO DO IN EMERGENCIES 503 Replace the wheel skins first using a rubber mallet. When Disc Type Nut Stud Size Torque Torque replacing the hub caps, tilt the cap retainer over the lug Wheels Ft. Lbs. Newton nut bolt circle and strike the high side down with a Meters rubber mallet.
Page 506 504 WHAT TO DO IN EMERGENCIES 8-Stud — Dual Rear Wheels Slots in the wheels will assist in properly orienting the Dual wheels are flat-mounted and center-piloted. The lug inner and outer wheels. Align these slots when assem- nuts are a two-piece assembly. When the tires are being bling the wheels for best access to the tire valve on the rotated or replaced, clean these lug nuts and add two inner wheel.
Page 507: To Stow The Flat Or Spare
WHAT TO DO IN EMERGENCIES 505 These dual rear wheels should be tightened as follows: 2. Retighten the wheel nuts in the same sequence to the torques listed in the table. Go through the sequence a second time to verify that specific torque has been achieved.
Page 508: Hoisting
506 WHAT TO DO IN EMERGENCIES HOISTING WARNING! A conventional floor jack may be used at the jacking locations. Refer to the graphics that show jacking loca- A loose tire thrown forward in a collision or hard tions. However, a floor jack or frame hoist must never be stop could injure the occupants in the vehicle.
Page 509: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 507 NOTE: When using a portable battery booster pack NOTE: The positive battery post is covered with a follow the manufacturer’s operating instructions and protective cap. Lift up on the cap to gain access to the precautions.
Page 510: Jump-Starting Procedure
508 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park WARNING! the vehicle within the jumper cables reach, set the • Take care to avoid the radiator cooling fan when- parking brake and make sure the ignition is OFF. ever the hood is raised.
Page 511 WHAT TO DO IN EMERGENCIES 509 CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.
Page 512: Freeing A Stuck Vehicle
510 WHAT TO DO IN EMERGENCIES 8. Disconnect the opposite end of the positive (+) jumper FREEING A STUCK VEHICLE cable from the positive (+) post of the booster battery. If the vehicle becomes stuck in snow, sand or mud, it can often be moved by a rocking motion.
Page 513: Emergency Tow Hooks - If Equipped
WHAT TO DO IN EMERGENCIES 511 CAUTION! WARNING! • When “rocking” a stuck vehicle by moving be- Fast spinning tires can be dangerous. Forces gener- tween DRIVE and REVERSE, do not spin the ated by excessive wheel speeds may cause damage, or wheels faster than 15 mph (24 km/h), or drivetrain even failure, of the axle and tires.
Page 514: Shift Lever Override
512 WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE WARNING! If a malfunction occurs and the shift lever cannot be • Chains are not recommended for freeing a stuck moved out of the PARK position, you can use one of the following procedures to temporarily move the shift lever: vehicle.
Page 515: Center Console Shifter - If Equipped
WHAT TO DO IN EMERGENCIES 513 Center Console Shifter — If Equipped To access the override, carefully remove (using a flat- bladed screwdriver) the override access cover which is located on the right of the shift lever gate. 1. Firmly set the parking brake. 2.
Page 516: Towing A Disabled Vehicle
514 WHAT TO DO IN EMERGENCIES 4. Using a screwdriver or similar tool, press and hold the 5. Move the shift lever into the NEUTRAL position. override tab through the access port on the center con- 6. The vehicle may then be started in NEUTRAL. sole.
Page 517 WHAT TO DO IN EMERGENCIES 515 Wheels OFF Towing Condition 2WD Models 4WD Models the Ground See instructions in “Recreational Tow- ing” under “Starting and Operating” If transmission is operable: • Auto Trans in PARK • Trans in NEUTRAL Flat Tow NONE •...
Page 518: Two-Wheel Drive Models
516 WHAT TO DO IN EMERGENCIES If the vehicle’s battery is discharged, see Brake/ Towing Without The Ignition Key Fob Transmission Interlock Manual Override (under Starting Special care must be taken when the vehicle is towed and Operating, Automatic Transmission) for instructions with the ignition in the LOCK position.
Page 519: Four-Wheel Drive Vehicles
WHAT TO DO IN EMERGENCIES 517 If flatbed equipment is not available, and the transfer case CAUTION! is operable, the vehicle may be towed (in the forward direction, with ALL wheels on the ground), IF the transfer Towing faster than 30 mph (48 km/h) or farther than case is in NEUTRAL and the transmission is in PARK (for 15 miles (24 km) with rear wheels on the ground can automatic transmissions) or in gear (NOT in Neutral, for...
Page 521: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS Engine Compartment — 3.7L ... . . 522 Maintenance Procedures ....528 ▫...
Page 522 520 MAINTAINING YOUR VEHICLE ▫ Windshield Wiper Blades ....536 Replacement Bulbs ....564 ▫...
Page 523 MAINTAINING YOUR VEHICLE 521 ▫ Chassis ......577 Fluids, Lubricants And Genuine Parts ..576 ▫...
Page 524: Engine Compartment - 3.7L
522 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 3.7L 1 — Air Cleaner Filter 7 — Washer Fluid Reservoir 2 — Automatic Transmission Dipstick (If Equipped) 8 — Power Steering Fluid Reservoir 3 — Engine Oil Dipstick 9 — Engine Oil Fill 4 —...
Page 525: Engine Compartment - 4.7L
MAINTAINING YOUR VEHICLE 523 ENGINE COMPARTMENT — 4.7L 1 — Air Cleaner Filter 7 — Washer Fluid Reservoir 2 — Automatic Transmission Dipstick 8 — Power Steering Fluid Reservoir 3 — Engine Oil Dipstick 9 — Engine Oil Fill 4 — Brake Fluid Reservoir 10 —...
Page 526: Engine Compartment - 5.7L
524 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 5.7L 1 — Air Cleaner Filter 7 — Washer Fluid Reservoir 2 — Automatic Transmission Dipstick 8 — Integrated Power Module (Fuses) 3 — Engine Oil Fill 9 — Power Steering Fluid Reservoir 4 —...
Page 527: Onboard Diagnostic System (Obd Ii)
MAINTAINING YOUR VEHICLE 525 ONBOARD DIAGNOSTIC SYSTEM (OBD II) CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emission control system.
Page 528: Emissions Inspection And Maintenance Programs
526 MAINTAINING YOUR VEHICLE the SELECT button to turn off the message. If the Normally, the OBD II system will be ready. The OBD II problem continues, the message will appear the next time system may not be ready if your vehicle was recently the vehicle is started.
Page 529: Replacement Parts
MAINTAINING YOUR VEHICLE 527 4. Approximately 15 seconds later, one of two things will Regardless of whether your vehicle’s OBD II system is happen: ready or not, if the MIL is illuminated during normal vehicle operation you should have your vehicle serviced a.
Page 530: Dealer Service
Only do service work for which you mance. Immediately have potential malfunctions have the knowledge and the proper equipment. If examined by an authorized Chrysler Group LLC you have any doubt about your ability to perform a dealership or qualified repair center.
Page 531: Engine Oil
MAINTAINING YOUR VEHICLE 529 The best time to check the engine oil level is about five CAUTION! (Continued) minutes after a fully warmed up engine is shut off. • Your vehicle has been built with improved fluids Checking the oil while the vehicle is on level ground will that protect the performance and durability of improve the accuracy of the oil level readings.
Page 532 530 MAINTAINING YOUR VEHICLE NOTE: Under no circumstances should oil change CAUTION! intervals exceed 8,000 miles (13 000 km) or six months, whichever occurs first. Do not use chemical flushes in your engine oil as the chemicals can damage your engine. Such damage is Engine Oil Selection not covered by the New Vehicle Limited Warranty.
Page 533: Engine Oil Filter
MAINTAINING YOUR VEHICLE 531 Lubricants which do not have both the engine oil certi- Disposing Of Used Engine Oil And Oil Filters fication mark and the correct SAE viscosity grade num- Care should be taken in disposing of used engine oil and ber should not be used.
Page 534: Engine Air Cleaner Filter
532 MAINTAINING YOUR VEHICLE Engine Air Cleaner Filter used to assure most efficient service. MOPAR engine air Refer to the “Maintenance Schedule” for the proper cleaner filters are a high quality filter and are maintenance intervals. recommended. Maintenance-Free Battery WARNING! Your vehicle is equipped with a maintenance-free battery.
Page 535 MAINTAINING YOUR VEHICLE 533 WARNING! (Continued) CAUTION! • Battery gas is flammable and explosive. Keep • It is essential when replacing the cables on the flame or sparks away from the battery. Do not use battery that the positive cable is attached to the a booster battery or any other booster source with positive post and the negative cable is attached to an output greater than 12 Volts.
Page 536: Air Conditioner Maintenance
534 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer at the start of each warm season. This service should approved by the manufacturer for your air condi- include cleaning of the condenser fins and a performance tioning system.
Page 537: Front Driveshaft Lubrication - 2500/3500
MAINTAINING YOUR VEHICLE 535 Refrigerant Recovery And Recycling tailgate, sliding doors and hood hinges, should be lubri- R-134a Air Conditioning Refrigerant is a hydrofluoro- cated periodically with a lithium based grease, such as carbon (HFC) that is endorsed by the Environmental MOPAR Spray White Lube or equivalent, to assure Protection Agency (EPA) and is an ozone-saving product.
Page 538: Adding Washer Fluid
536 MAINTAINING YOUR VEHICLE Windshield Wiper Blades Adding Washer Fluid Clean the rubber edges of the wiper blades and the The fluid reservoir is located under the hood and should windshield periodically with a sponge or soft cloth and a be checked for fluid level at regular intervals.
Page 539: Exhaust System
MAINTAINING YOUR VEHICLE 537 If you notice a change in the sound of the exhaust system; WARNING! or if the exhaust fumes can be detected inside the vehicle; or when the underside or rear of the vehicle is damaged; Commercially available windshield washer solvents have an authorized technician inspect the complete ex- are flammable.
Page 540 538 MAINTAINING YOUR VEHICLE WARNING! CAUTION! • Exhaust gases can injure or kill. They contain • The catalytic converter requires the use of un- carbon monoxide (CO), which is colorless and leaded fuel only. Leaded gasoline will destroy the odorless. Breathing it can make you unconscious effectiveness of the catalyst as an emissions con- and can eventually poison you.
Page 541 MAINTAINING YOUR VEHICLE 539 Under normal operating conditions, the catalytic con- To minimize the possibility of catalytic converter dam- verter will not require maintenance. However, it is im- age: portant to keep the engine properly tuned to assure • Do not shut off the engine or interrupt the ignition, proper catalyst operation and prevent possible catalyst when the transmission is in gear and the vehicle is in damage.
Page 542: Cooling System
540 MAINTAINING YOUR VEHICLE Cooling System Check the coolant recovery bottle tubing for brittle rub- ber, cracking, tears, cuts and tightness of the connection WARNING! at the bottle and radiator. Inspect the entire system for leaks. You or others can be badly burned by hot coolant or With the engine at normal operating temperature (but steam from your radiator.
Page 543 MAINTAINING YOUR VEHICLE 541 Refer to the “Maintenance Schedule” for the proper CAUTION! (Continued) maintenance intervals. • Do not use water alone or alcohol-based engine Selection Of Coolant coolant (antifreeze) products. Do not use addi- Use only the manufacturer’s recommended engine cool- tional rust inhibitors or antirust products, as they ant (antifreeze).
Page 544 542 MAINTAINING YOUR VEHICLE Please review these recommendations for using Hybrid Please note that it is the owner’s responsibility to main- Organic Additive Technology (HOAT) engine coolant tain the proper level of protection against freezing ac- (antifreeze). When adding engine coolant (antifreeze): cording to the temperatures occurring in the area where the vehicle is operated.
Page 545 MAINTAINING YOUR VEHICLE 543 rules for your community. To prevent ingestion by ani- WARNING! mals or children do not store ethylene glycol-based • The warning words “DO NOT OPEN HOT” on engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground.
Page 546 544 MAINTAINING YOUR VEHICLE The radiator normally remains completely full, so there is If an examination of your engine compartment shows no no need to remove the radiator cap unless checking for evidence of radiator or hose leaks, the vehicle may be engine coolant (antifreeze) freeze point or replacing en- safely driven.
Page 547: Brake System
MAINTAINING YOUR VEHICLE 545 • Make sure that the radiator and coolant recovery WARNING! bottle overflow hoses are not kinked or obstructed. Riding the brakes can lead to brake failure and • Keep the front of the radiator clean. If your vehicle is possibly a collision.
Page 548 546 MAINTAINING YOUR VEHICLE With disc brakes the fluid level can be expected to fall as WARNING! the brake linings wear. However, an unexpected drop in • Use only manufacturer’s recommended brake fluid level may be caused by a leak and a system check should be conducted.
Page 549: Rear Axle And 4X4 Front Driving Axle Fluid Level
MAINTAINING YOUR VEHICLE 547 WARNING! (Continued) WARNING! (Continued) • To avoid contamination from foreign matter or • Do not allow petroleum based fluid to contami- moisture, use only new brake fluid or fluid that nate the brake fluid. Brake seal components could has been in a tightly closed container.
Page 550: Transfer Case
548 MAINTAINING YOUR VEHICLE axles. The fluid level should be 5/8 in (16 mm) below the encountered in some off-highway types of service, will fill hole on 9 1/4 in manufacturer’s rear axles. require draining and refilling the axle to avoid damage. For all 2500/3500 Model axles, the fluid level should be Limited-Slip Differentials 1/4”...
Page 551: Automatic Transmission
MAINTAINING YOUR VEHICLE 549 Lubricant Selection CAUTION! Refer to “Fluids, Lubricants, and Genuine Parts” in • Do not use chemical flushes in your transmission “Maintaining Your Vehicle” for further information. as the chemicals can damage your transmission Fluid Level Check components.
Page 552 550 MAINTAINING YOUR VEHICLE Special Additives Fluid Level Check – 42RLE/545RFE Automatic Transmission Fluid (ATF) is an engineered Check the fluid level while the transmission is at normal product and its performance may be impaired by supple- operating temperature 82°C (180°F). This occurs after at mental additives.
Page 553 MAINTAINING YOUR VEHICLE 551 5. Remove the dipstick, wipe it clean and reinsert it until (upper) reference holes when the transmission reaches seated. 180°F (82°C). Remember it is best to check the level at the normal operating temperature. 6. Remove the dipstick again and note the fluid level on both sides.
Page 554: Appearance Care And Protection From Corrosion
552 MAINTAINING YOUR VEHICLE Automatic Transmission Fluid And Filter Change road surfaces on which the vehicle is operated, extreme Refer to the “Maintenance Schedule” for the proper hot or cold weather and other extreme conditions will maintenance intervals. have an adverse affect on paint, metal trim, and under- body protection.
Page 555 MAINTAINING YOUR VEHICLE 553 Washing CAUTION! • Wash your vehicle regularly. Always wash your ve- • Do not use abrasive or strong cleaning materials hicle in the shade using MOPAR Car Wash or equiva- such as steel wool or scouring powder which will lent, or a mild car wash soap and rinse the panels scratch metal and painted surfaces.
Page 556 554 MAINTAINING YOUR VEHICLE • If you detect any stone chips or scratches in the paint, Wheel And Wheel Trim Care touch them up immediately. The cost of such repairs is All wheels and wheel trim, especially aluminum and considered the responsibility of the owner. chrome-plated wheels should be cleaned regularly with a mild soap and water to prevent corrosion.
Page 557 MAINTAINING YOUR VEHICLE 555 • Blot any remaining stain with a clean, damp towel. MOPAR Total Clean or equivalent is specifically recom- mended for leather upholstery. • For tough stains, apply MOPAR Total Clean or equivalent, or a mild soap solution to a clean, damp Your leather upholstery can be best preserved by regular cloth and remove stain.
Page 558 556 MAINTAINING YOUR VEHICLE Cleaning Headlights cleaner. Use caution when cleaning the inside rear win- Your vehicle is equipped with plastic headlights and fog dow equipped with electric defrosters or the right rear lights (if equipped) that are lighter and less susceptible to quarter window equipped with the radio antenna.
Page 559 MAINTAINING YOUR VEHICLE 557 Seat Belt Maintenance rinse all loose dirt from your truck bed and clean your Do not bleach, dye or clean the belts with chemical truck at least twice per year using the MOPAR solvents or abrasive cleaners. This will weaken the fabric. Spray-On Bedliner Conditioner available at your local Sun damage can also weaken the fabric.
Page 560: Fuses
558 MAINTAINING YOUR VEHICLE to cover the metal exposed by the scratch is required. To WARNING! repair a tear or gouge, follow the directions provided in the MOPAR Quick Repair Kit. Do not use silicon-based protection products to clean your bedliner. Silicon-based products can become FUSES slippery and may result in personal injury.
Page 561 MAINTAINING YOUR VEHICLE 559 Cavity Cartridge Mini Description Fuse Fuse 30 Amp Diesel Powertrain Pink Control Module – If Equipped 25 Amp Driver Door Node Natural 25 Amp Passenger Door Natural Node 40 Amp Antilock Brakes Green Pump/Stability Control System Totally Integrated Power Module 30 Amp Antilock Brakes...
Page 562 560 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 60 Amp Main Ignition Off 20 Amp Front Washer Con- Yellow Draw (IOD) Fuse Blue trol 20 Amp Trailer Tow 25 Amp Sunroof Module Blue Lamps/Park Lamps Natural...
Page 563 MAINTAINING YOUR VEHICLE 561 Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 20 Amp Hands Free Yellow (Domestic Only) Yellow Module/Vanity 20 Amp Power Seat Lamp/Universal Yellow Module(s)/Audio Garage Door Telematics/Daytime Opener Module Running Lights 10 Amp Climate Control Relay/Instrument System...
Page 564 562 MAINTAINING YOUR VEHICLE Cavity Cartridge Mini Description Cavity Cartridge Mini Description Fuse Fuse Fuse Fuse 20 Amp Automatic Shut- 15 Amp J1962 Diag Connec- Yellow down 3 Blue 10 Amp Horns (Low/High) 10 Amp Airbag Module – Right 10 Amp Horns (Low/High) 10 Amp Powertrain Control...
Page 565: Vehicle Storage
MAINTAINING YOUR VEHICLE 563 Cavity Cartridge Mini Description CAUTION! (Continued) Fuse Fuse • When replacing a blown fuse, it is important to System Module/ use only a fuse having the correct amperage rating. Stoplamp Switch The use of a fuse with a rating other than indicated 25 Amp All Door Lock may result in a dangerous electrical system over-...
Page 566: Replacement Bulbs
564 MAINTAINING YOUR VEHICLE • As an alternative to the above steps you may discon- (or check to see if the fuse is blown) to ensure that it is nect the negative cables from both batteries. fully seated. When the IOD fuse is extracted, the instrument cluster in the odometer window will dis- •...
Page 567: Bulb Replacement
MAINTAINING YOUR VEHICLE 565 BULB REPLACEMENT Fog Lamp ......9145 Dual Headlamp ......H13 Dual or Quad Headlamp/Front Park and Turn Quad Headlamp –...
Page 568 566 MAINTAINING YOUR VEHICLE 6. Remove the two headlamp assembly attachment 8. Reach through the access hole of the wheel house screws. splash shield and lift the slide lock upward far enough to disengage it from the lock post on the back of the front lamp unit housing.
Page 569: Fog Lamps
MAINTAINING YOUR VEHICLE 567 10. Disconnect the wiring harness connectors from the Fog Lamps bulb socket. 1. Reach under and behind the front bumper to access 11. Replace bulb(s) as necessary. the back of the front fog lamp housing. 2. Disconnect the fog lamp wiring harness connector CAUTION! from the fog lamp bulb.
Page 570: Rear Tail/Stop, Turn Signal And Backup Lamps
568 MAINTAINING YOUR VEHICLE Rear Tail/Stop, Turn Signal and Backup Lamps 2. Pull the outboard side of the lamp rearward far enough to unsnap the two receptacles on the outboard 1. Remove the two screws that pass through the bed side of the lamp housing from the two plastic snap post sheetmetal.
Page 571: Center High-Mounted Stoplamp (Chmsl) With Cargo Lamp
MAINTAINING YOUR VEHICLE 569 4. Rotate the bulb socket counterclockwise 1/4 turn to Center High-Mounted Stoplamp (CHMSL) With unlock it from the housing. Cargo Lamp 5. Pull the bulb straight out of the socket. 1. Remove the two screws holding the housing/lens to the body as shown.
Page 572 570 MAINTAINING YOUR VEHICLE 2. Separate the connector holding the housing and wir- ing harness to the body. CAUTION! Do not contaminate the bulb glass by touching it 3. Turn the desired bulb socket ⁄ turn and remove the with your fingers or by allowing it to contact other socket and bulb from housing.
Page 573: Cab Top Clearance Lamps - If Equipped
MAINTAINING YOUR VEHICLE 571 • Inside Bulb: Center High-Mounted Stop Lamp 2. Rotate the socket ⁄ turn and pull it from the lamp assembly. 5. Reverse the procedure for installation of bulbs and housing. Cab Top Clearance Lamps — If Equipped 1.
Page 574: Rear Lamp Bar Id Marker (Dual Rear Wheels) - If Equipped
572 MAINTAINING YOUR VEHICLE 3. Pull the bulb straight from it’s socket and replace. 2. Turn the socket ⁄ turn counterclockwise to access the bulb. Rear Lamp Bar ID Marker (Dual Rear Wheels) — If Equipped 3. Pull the bulb straight out from the socket. 1.
Page 575: Side Marker Lamps (Dual Rear Wheels) - If Equipped
MAINTAINING YOUR VEHICLE 573 Side Marker Lamps (Dual Rear Wheels) — If 1. Push rearward on the side marker lamp assembly. Equipped 2. Pull the entire assembly from the fender. 3. Turn the socket ⁄ turn counterclockwise and remove from assembly to access the bulb. 4.
Page 576: Fluid Capacities
574 MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 1500 Regular Cab Shortbed/Crew Quad Cab Models 26 Gallons 98 Liters 1500 Regular Cab Longbed/Crew Quad Cab Models 32 Gallons 121 Liters (Optional) 2500/3500 Shortbed Models 34 Gallons 129 Liters 2500/3500 Longbed Models 35 Gallons 132 Liters...
Page 577 MAINTAINING YOUR VEHICLE 575 U.S. Metric Cooling System 3.7L Engine (MOPAR Antifreeze/Coolant 5 14 Quarts 13 Liters Year/100,000 Mile Formula or equivalent) 4.7L Engine (MOPAR Antifreeze/Coolant 5 14 Quarts 13 Liters Year/100,000 Mile Formula or equivalent) 5.7L Engine — 1500 Models (MOPAR Antifreeze/ 16 Quarts 15 Liters Coolant 5 Year/100,000 Mile Formula or equivalent)
Page 578 576 MAINTAINING YOUR VEHICLE FLUIDS, LUBRICANTS AND GENUINE PARTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant MOPAR Antifreeze/Coolant 5 Year/100,000 Mile Formula HOAT (Hybrid Organic Additive Technology) or equivalent. Engine Oil Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 579 MAINTAINING YOUR VEHICLE 577 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Transfer Case MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Transfer Case – BW44–44 Only MOPAR BW44–44 Transfer Case Fluid or equivalent.
Page 581 MAINTENANCE SCHEDULES CONTENTS ▫ Required Maintenance Intervals ..582 Maintenance Schedule ....580...
Page 582 580 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Based on engine operation conditions the oil change The Scheduled Maintenance services listed in this indicator message will illuminate. This means that ser- manual must be done at the times or mileages specified vice is required for your vehicle. Have your vehicle to protect your vehicle warranty and ensure the best serviced as soon as possible, within the next 500 miles vehicle performance and reliability.
Page 583 MAINTENANCE SCHEDULES 581 Your authorized dealer will reset the oil change indicator Once A Month message after completing the scheduled oil change. If a • Check tire pressure and look for unusual wear or scheduled oil change is performed by someone other damage.
Page 584 582 MAINTENANCE SCHEDULES The spark plugs located under the coils are a standard CAUTION! plug and must be changed every 48,000 miles (78 000 km). Failure to perform the required maintenance items may result in damage to the vehicle. The spark plugs located on the side of the engine are a premium plug and must be changed every 96,000 miles Required Maintenance Intervals (156 000 km).
Page 585 MAINTENANCE SCHEDULES 583 8,000 Miles (13,000 km) or 16,000 Miles (26,000 km) or 12 Months Maintenance Service 6 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 586: Service Schedule
584 MAINTENANCE SCHEDULES 24,000 Miles (39,000 km) or 32,000 Miles (52,000 km) or 24 Months Maintenance Service 18 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 587 MAINTENANCE SCHEDULES 585 40,000 Miles (65,000 km) or 48,000 Miles (78,000 km) or 36 Months Maintenance Service 30 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 588 586 MAINTENANCE SCHEDULES 56,000 Miles (91,000 km) or 42 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 56,000 miles (91 000 km). ❏...
Page 589 MAINTENANCE SCHEDULES 587 64,000 Miles (104,000 km) or 48 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 64,000 miles (104 000 km). ❏...
Page 590 588 MAINTENANCE SCHEDULES 72,000 Miles (117,000 km) or 80,000 Miles (130,000 km) or 60 Months Maintenance Service 54 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 591 MAINTENANCE SCHEDULES 589 88,000 Miles (143,000 km) or 66 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 88,000 miles (143 000 km). ❏...
Page 592 590 MAINTENANCE SCHEDULES 96,000 Miles (156,000 km) or 72 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 96,000 miles (156 000 km). ❏...
Page 593 MAINTENANCE SCHEDULES 591 104,000 Miles (169,000 km) or 112,000 Miles (182,000 km) or 84 Months Maintenance Service 78 Months Maintenance Schedule ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 594 592 MAINTENANCE SCHEDULES 120,000 Miles (195,000 km) or 90 Months Maintenance Service Schedule ❏ Change the engine oil and engine oil filter. ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before 120,000 miles (195 000 km). ❏...
Page 595 MAINTENANCE SCHEDULES 593 128,000 Miles (208,000 km) or 96 Months Maintenance Service 136,000 Miles (221,000 km) or Schedule 102 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 596 594 MAINTENANCE SCHEDULES 144,000 Miles (234,000 km) or 108 Months Maintenance Service 152,000 Miles (247,000 km) or Schedule 114 Months Maintenance ❏ Change the engine oil and engine oil filter. Service Schedule ❏ Rotate the tires, rotate at the first sign of irregular wear, even if it occurs before ❏...
Page 597 MAINTENANCE SCHEDULES 595 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 599: If You Need Consumer Assistance
Reporting Safety Defects ....602 ▫ Chrysler Group LLC Customer Center ..600 ▫ In The 50 United States And Washington, D.C.
Page 600 598 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... 605 Department Of Transportation Uniform Tire Quality Grades ......605 ▫...
Page 601: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 599 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 602: Chrysler Group Llc Customer Center
• Vehicle delivery date and mileage This is why you should always talk to an authorized dealer’s service manager first. Most matters can be re- Chrysler Group LLC Customer Center solved with this process. P.O. Box 21–8004 • If for some reason you are still not satisfied, talk to the Auburn Hills, MI 48321–8004...
Page 603: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 601 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 604: Warranty Information
See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 605: In Canada
IF YOU NEED CONSUMER ASSISTANCE 603 If NHTSA receives similar complaints, it may open an In Canada investigation, and if it finds that a safety defect exists in If you believe that your vehicle has a safety defect, you a group of vehicles, it may order a recall and remedy should contact the Customer Service Department imme- campaign.
Page 606 Chrysler Group LLC ve- taining, servicing, and repairing Chrysler Group LLC hicles. Included are starting, operating, emergency vehicles.
Page 607 IF YOU NEED CONSUMER ASSISTANCE 605 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
Page 608 606 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 609 INDEX...
Page 610 608 INDEX Adding Engine Coolant (Antifreeze) ..541 Alarm System (Security Alarm) ....18 Adding Fuel ......448 Alarm, Panic .
Page 611 INDEX 609 Fluid Level Check ....549,550 Brake Control System, Electronic ... . . 392 Fluid Type .
Page 612 610 INDEX Caps, Filler Child Seat ......68,74 Oil (Engine) ......530 Cigar Lighter .
Page 613 INDEX 611 Coolant Pressure Cap (Radiator Cap) ..542 Defroster, Rear Window ....179 Cooling System .
Page 614 612 INDEX DVD Player Hazard Warning Flasher ....487 (Video Entertainment System™) ... . . 284 Jump Starting .
Page 615 INDEX 613 Temperature Gauge ....208 Fuel Requirements ....444,446 Enhanced Accident Response Feature .
Page 616 614 INDEX Fuel ....... . . 439 Gas Cap (Fuel Filler Cap) ....450,525 Adding .
Page 617 INDEX 615 GVWR ....... 450 Heater, Engine Block ..... 309 High Beam/Low Beam Select (Dimmer) Switch .
Page 618 616 INDEX Instrument Panel and Controls ....203 Lane Change and Turn Signals ....129 Instrument Panel Lens Cleaning .
Page 619 INDEX 617 Center Mounted Stop ....569 Passing ......129 Check Engine (Malfunction Indicator) .
Page 620 618 INDEX Lower Anchors and Tether for CHildren (LATCH) . . 72 Outside ......94 Lubrication, Body .
Page 621 INDEX 619 Trip ......212,213 Opener, Garage Door (HomeLink®) ... 152 Off-Pavement Driving (Off-Road) .
Page 622 620 INDEX Phone, Hands-Free (uconnect™) ... . . 101 Radial Ply Tires ......415 Pickup Box .
Page 623 INDEX 621 Remote Control Safety Tips ......81 Starting System ......26 Safety, Exhaust Gas .
Page 624 622 INDEX Folding Floor ......180 Automatic Transmission ....311,316 Heated .
Page 625: Vehicle
INDEX 623 Starting ......26,307 Synthetic Engine Oil ..... . 531 Automatic Transmission .
Page 626 624 INDEX Dual ......426,504 Tow Hooks, Emergency ....511 General Information .
Page 627 INDEX 625 Electronically Shifted ....328,334 Uniform Tire Quality Grades ....605 Fluid .
Page 628 626 INDEX Warnings and Cautions ..... 6 Usage ......368 Warranty Information .
Page 629 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 630 Chrysler Group LLC Fifth Edition 11D241-126-AE Printed in U.S.A.

This manual is also suitable for:

2011 ram truck 2500 2011 ram truck 3500 2500 2011 3500 2011 2011 1500
