TOUCHSTONE LUMENEX SERIES
ELECTRIC FIREPLACE HEATER
Model # : 87026, 87028, 87030
87032, 87034, 87036, 87040
OWNER'S MANUAL
26", 28", 30", 32", 34", 36", 40"
Recessed Electric Fireplace
AC 110-120V 60Hz 1500W
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
WARNING
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
Advertisement
Table of Contents
Related Manuals for Touchstone TOUCHSTONE LUMENEX Series
Summary of Contents for Touchstone TOUCHSTONE LUMENEX Series
- Page 1 TOUCHSTONE LUMENEX SERIES ELECTRIC FIREPLACE HEATER Model # : 87026, 87028, 87030 87032, 87034, 87036, 87040 OWNER’S MANUAL 26”, 28”, 30”, 32”, 34”, 36”, 40” Recessed Electric Fireplace AC 110-120V 60Hz 1500W Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product.
- Page 2 Lumenex Series Electric Fireplace www.touchstonehomeproducts.com 800.215.1990...
-
Page 3: Table Of Contents
Lumenex Series Electric Fireplace Table of Contents General Information ..............................5 Fireplace Specifications............................5 ETL Approval Listing Information ........................... 5 Dimensional Drawing ............................... 6 Unpacking Your Fireplace ............................7 Parts and Hardware ..............................7 Tools Required ..............................7 What’s in the Box ..............................7 Unpacking and Setup .............................. - Page 4 Lumenex Series Electric Fireplace IMPORTANT SAFETY INFORMATION WARNING! • THIS FIREPLACE IS HOT WHEN IN OPERATION AND CAN CAUSE SEVERE BURNS • Do not operate fireplace before reading and understanding operating instructions. Failure to operate fireplace according to operating instructions could cause fire or injury. •...
-
Page 5: General Information
Lumenex Series Electric Fireplace General Information Fireplace Specifications Model Number 87026 87028 87030 87032 Description Lumenex 26” Lumenex 28” Lumenex 30” Lumenex 32” Voltage 120v AC 120v AC 120v AC 120v AC Watts Max 1500W Max 1500W Max 1500W Max 1500W Amps 15 AMP 15 AMP... -
Page 6: Dimensional Drawing
Lumenex Series Electric Fireplace Dimensional Drawing PRODUCT DIMENSIONS Model Number 16 ½” 5 ½” 87026 26” 22 11/16” 15 7/16” 9 3/8” 20 7/8” 16 ½” 5 ½” 87028 28” 24 11/16” 15 7/16” 9 3/8” 22 7/8” 16 ½” 5 ½”... -
Page 7: Unpacking Your Fireplace
Lumenex Series Electric Fireplace Unpacking Your Fireplace Parts and Hardware Tools Required • Phillips screwdriver • Stud finder • Level • Tape measure • Electric drill • 1/4” wood drill bit What’s in the Box Wood Screws Drywall Anchors Fireplace Faux Fire Log Crystal Strip Unpacking and Setup... -
Page 8: Wiring
Lumenex Series Electric Fireplace Wiring The LUMENEX series recessed fireplace can either be plugged into a grounded 3-prong outlet or hard wire connection. Testing the Fireplace Prior to Installation • Before installing the fireplace, test the fireplace to make sure that it operates properly. •... -
Page 9: Hard Wire Connection
Lumenex Series Electric Fireplace Hard Wire Connection If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. This appliance must be electrically connected and grounded in accordance with local codes, if hard wired. In the absence of local codes, use the current ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in the United States or the current CSA C22.1 CANADIAN ELECTRICAL CODE in Canada. -
Page 10: Installation
Lumenex Series Electric Fireplace Installation WARNINGS • Never install the fireplace where it may fall into a bathtub or other body of water. • Wear safety gloves and safety glasses for protection during installation. Broken glass may cause injury or harm. -
Page 11: Removing The Glass Panel
Lumenex Series Electric Fireplace Removing The Glass Panel Prior to installation, it is best to remove the glass panel. Please remove the glass panel as per instructions below: Instructions 1. Remove the 2 screws securing the glass panel to the fireplace. 2. - Page 12 Lumenex Series Electric Fireplace Removing The Glass Panel – cont. 3. After removing screws, lift glass panel UP and STRAIGHT OUT toward you to remove from fireplace. Place glass panel in a soft, dry place. CAUTION: It is recommended that 2 people remove the glass panel to minimize change of breakage. www.touchstonehomeproducts.com 800.215.1990...
-
Page 13: Recessed Installation
Lumenex Series Electric Fireplace Recessed Installation • Due to many different finish materials use on walls, it is highly recommended that you consult your local builder before you install this fireplace in the wall. • Never install fireplace into load-bearing walls. When recessing fireplace in a wall, recess into non-load bearing walls ONLY! Instructions: 1. -
Page 14: Crystal Ember Installation
Lumenex Series Electric Fireplace Recessed Installation – cont. 3. With the help of a second person, insert fireplace into wall opening and secure with mounting screws provided. 4. Once the fireplace is installed in the wall, place crystal embers or fire log in the fireplace. a. -
Page 15: Fire Log Installation
Lumenex Series Electric Fireplace Recessed Installation – cont. b. Fire log Installation 1. Place fire log in fireplace as illustrated below. 5. Once completed installing crystal embers or fire log, reinstall glass panel. The hooks on the back of the glass panels fit into the slots on the side of the firebox. - Page 16 Lumenex Series Electric Fireplace Recessed Installation – cont. 6. Reinstall the 2 mounting screws to lock the glass panel in place, so it does not move during travel. www.touchstonehomeproducts.com 800.215.1990...
-
Page 17: Operating Fireplace
Lumenex Series Electric Fireplace Operating Fireplace Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that the house circuit breakers for the power supply are turned on. Power Plug the power cable into a 110v 15 amp grounded outlet. Make sure the outlet is in good condition and that the plug is not loose. -
Page 18: Remote Control And Touch Panel Functions
Lumenex Series Electric Fireplace Remote Control and Touch Panel Functions BUTTON FUNCTION ACTION & INDICATION ON: Enables control panel functions and remote control. Turns 1. Press once. Indicator light turns on. on the flame effect. Power turns on. All functions enabled. OFF: Disables control panel functions and remove control. -
Page 19: Troubleshooting
Lumenex Series Electric Fireplace Troubleshooting Problem Possible Cause Solution 1. Fireplace turns off 1. Fireplace has overheated 1. Reset switch by turning main power off and will not turn on. and safety devise has caused and waiting turning it back on or breaker thermal switch to disconnect circuit breaker. -
Page 20: Care And Maintenance
Lumenex Series Electric Fireplace Care and Maintenance Cleaning • ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving the fireplace. Failure to do so could result in electric shock, fire, or personal injury. •... -
Page 21: Warranty
Touchstone Home Products®, Inc warrants our electric fireplaces to be free of defects in material and workmanship for one year from date of purchase. Touchstone will repair or replace any fireplace or fireplace part that is deemed defective or becomes defective during normal use within one year after the date of purchase. -
Page 22: Notes
Lumenex Series Electric Fireplace Notes: www.touchstonehomeproducts.com 800.215.1990... - Page 23 Lumenex Series Electric Fireplace www.touchstonehomeproducts.com 800.215.1990...
- Page 24 Lumenex Series Electric Fireplace www.touchstonehomeproducts.com 800.215.1990...
