Touchstone 80011 Owner's Manual

Sideline series electric fireplace heater
Hide thumbs Also See for 80011:
Table of Contents

Advertisement

Quick Links

SIDELINE SERIES ELECTRIC FIREPLACE HEATER
Model # : 80004, 80011, 80013, 80014, 80015
Read and understand this entire owner's manual, including all safety
information, before plugging in or using this product. Failure to do so could
WARNING
result in fire, electric shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this
CAUTION
product away, make sure this manual accompanies this product.
OWNER'S MANUAL
36"/50"/60"/72"
Sideline Series
Recessed Electric Fireplace
AC 110-120V 60Hz 1500W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 80011 and is the answer not in the manual?

Questions and answers

Kagel
March 2, 2025

What is weight of Touchstone 8001

0
1 comments:
Mr. Anderson
May 14, 2025

The weight of the Touchstone 80011 is 62 pounds.

This answer is automatically generated

0

Subscribe to Our Youtube Channel

Related Manuals for Touchstone 80011

Summary of Contents for Touchstone 80011

  • Page 1 SIDELINE SERIES ELECTRIC FIREPLACE HEATER Model # : 80004, 80011, 80013, 80014, 80015 OWNER’S MANUAL 36"/50"/60”/72" Sideline Series Recessed Electric Fireplace AC 110-120V 60Hz 1500W Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could WARNING result in fire, electric shock, or serious personal injury.
  • Page 2 Recessed Electric Fireplace www.touchstonehomeproducts.com 800.215.1990...

  • Page 3: Table Of Contents

    Fireplace Specifications ............................5   Dimensional Drawings ............................. 6   80004 – Sideline 50” Dimensions..........................6   80011 – Sideline 60” Dimensions..........................7   80013 – Sideline Steel 50” Dimensions........................8   80014 – Sideline 36” Dimensions..........................9   80015 – Sideline 72” Dimensions........................... 10  ...
  • Page 4 Recessed Electric Fireplace IMPORTANT SAFETY INFORMATION WARNING!  THIS FIREPLACE IS HOT WHEN IN OPERATION AND CAN CAUSE SEVERE BURNS  Do not operate fireplace before reading and understanding operating instructions. Failure to operate fireplace according to operating instructions could cause fire or injury. ...

  • Page 5: General Information

    Note: This fireplace must be electrically wired and grounded in accordance with local codes or, in the absence of local codes, with National Electric Code ANSI/NFPA 70-latest edition in the United States or the Canadian Electric Code, CSA C22.1 in Canada. Fireplace Specifications Model Number 80004 80011 80013 Description Sideline50 Sideline60 Sideline50...

  • Page 6: Dimensional Drawings

    Recessed Electric Fireplace Dimensional Drawings 80004 – Sideline 50” Dimensions www.touchstonehomeproducts.com 800.215.1990...

  • Page 7: 80011 - Sideline 60" Dimensions

    Recessed Electric Fireplace 80011 – Sideline 60” Dimensions www.touchstonehomeproducts.com 800.215.1990...

  • Page 8: 80013 - Sideline Steel 50" Dimensions

    Recessed Electric Fireplace 80013 – Sideline Steel 50” Dimensions www.touchstonehomeproducts.com 800.215.1990...

  • Page 9: 80014 - Sideline 36" Dimensions

    Recessed Electric Fireplace 80014 – Sideline 36” Dimensions www.touchstonehomeproducts.com 800.215.1990...

  • Page 10: 80015 - Sideline 72" Dimensions

    Recessed Electric Fireplace 80015 – Sideline 72” Dimensions www.touchstonehomeproducts.com 800.215.1990...

  • Page 11: Unpacking Your Fireplace

    Recessed Electric Fireplace Unpacking Your Fireplace Parts and Hardware Tools Required  Phillips screwdriver  Stud finder  Level  Tape measure  Electric drill  1/4” wood drill bit What’s in the Box Drywall anchors Wood Screws B – Wood Screws C –...

  • Page 12: Wiring

    Recessed Electric Fireplace Wiring The Sideline series recessed fireplace can either be plugged into a grounded 3-prong outlet or hard wire connection. Testing the Fireplace Prior to Installation  Before installing the fireplace, test the fireplace to make sure that it operates properly. ...

  • Page 13: Hard Wire Connection

    Recessed Electric Fireplace Hard Wire Connection If it is necessary to hard wire this appliance, a qualified electrician must remove the cord connection, and wire the appliance directly to the house hold wiring. This appliance must be electrically connected and grounded in accordance with local codes, if hard wired. In the absence of local codes, use the current ANSI/NFPA 70 NATIONAL ELECTRICAL CODE in the United States or the current CSA C22.1 CANADIAN ELECTRICAL CODE in Canada.

  • Page 14: Installation

    Recessed Electric Fireplace Installation WARNINGS  Due to high temperatures, keep the fireplace out of high traffic locations.  Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 36” away from the front of the fireplace. ...

  • Page 15: Removing The Glass Panel

    Recessed Electric Fireplace Removing The Glass Panel Prior to installation, it is best to remove the glass panel. Please remove glass panel as per instructions below: Instructions 1. There are 2 screws in the top vent opening, one on the far left and one on the far right. Remove both screws from the glass panel.

  • Page 16: Recessed Installation

    2. Create opening in the wall that is no more than ¼” larger than metal firebox portion of fireplace. Firebox Dimensions Model (Width) (Height) (Depth) 80004 46.85” 20.2” 5.2” 80011 46.85” 20.2” 5.2” 80014 32.5” 20.2” 5.2” 80015 68.4” 20.2”...

  • Page 17: Crystal Ember Installation

    Recessed Electric Fireplace Recessed Installation – cont. 3. With the help of a second person, insert fireplace into wall opening and secure with mounting screws provided. 4. Once the fireplace is installed in the wall, place crystal embers or fire log in the fireplace. a.

  • Page 18: Recessed Installation - Cont

    Recessed Electric Fireplace Recessed Installation – cont. b. Fire log Installation 1. Place fire log in fireplace as illustrated below. 5. Once completed installing crystal embers or fire log, reinstall glass panel. The hooks on the back of the glass panels fit into the slots on the side of the firebox.

  • Page 19: Wall Mounted Installation

    3. Place the unit face down on a soft, non-abrasive surface. Remove the bracket from the back of the unit by removing the screws holding the bracket to the back of the fireplace. 80004/80011/80014 Wall Bracket Removal (1 bracket) 80015 Wall Bracket Removal (2 brackets) www.touchstonehomeproducts.com...
  • Page 20 Recessed Electric Fireplace Wall Mounted Installation – cont. 4. Mark location of bracket on wall and then mount the bracket to the wall using the supplied screws and dry wall anchors. The hooks in the bracket MUST be pointed away from the wall, upward, and level. Note: Mount bracket to at least 2 studs.
  • Page 21 Recessed Electric Fireplace Wall Mounted Installation – cont. 5. With the wall mounting bracket installed, have 2 people lift the fireplace up and insert the 2 hooks on the bracket into the back of the fireplace. The 2 hooks on the mounting bracket will line up with the 2 holes on the back of the fireplace.

  • Page 22: Operating Fireplace

    Recessed Electric Fireplace Operating Fireplace Once the fireplace has been plugged into a grounded outlet, the fireplace is now ready for operation. Ensure that the house circuit breakers for the power supply are turned on. Power Plug the power cable into a 110v 15 amp grounded outlet. Make sure the outlet is in good condition and that the plug is not loose.

  • Page 23: Remote Control Operation

    Recessed Electric Fireplace Remote Control Operation  This remote control uses two AAA batteries (Not included).  Instructions for battery installation are located in the remote control battery compartment.  To improve operation of the remote control, aim the remote control at the front of the fireplace. DO NOT PRESS the buttons too quickly.

  • Page 24: Care And Maintenance

    Recessed Electric Fireplace Care and Maintenance Cleaning  ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving the fireplace. Failure to do so could result in electric shock, fire, or personal injury. ...

  • Page 25: Warranty

    Touchstone Home Products, Inc warrants our electric fireplaces to be free of defects in material and workmanship for one year from date of purchase. Touchstone will repair or replace any fireplace or fireplace part that is deemed defective or becomes defective during normal use within one year after the date of purchase.
  • Page 26 Recessed Electric Fireplace www.touchstonehomeproducts.com 800.215.1990...
  • Page 27 Recessed Electric Fireplace www.touchstonehomeproducts.com 800.215.1990...
  • Page 28 Recessed Electric Fireplace www.touchstonehomeproducts.com 800.215.1990...
