Comrex BRIC-Link Product Manual page 37

• Incoming Connection Profile - This allows users to select whether SIP calls will take place using a specific
encoding algorithm. Note: If this option is chosen, only calls using the selected algorithm are allowed.
Default is "None".
• Use SIP Proxy - This option determines whether the SIP function is "registered" to a SIP cloud server. If this
setting is enabled, then the address, user name, and password for the proxy must be added in the relevant
fields.
• SIP Proxy Address - IP address or URL of the SIP proxy used.
• SIP Username - Username for logging into registered SIP server; provided by the SIP service provider.
• SIP Password - Password for logging into registered SIP server; provided by the SIP service provider.
aDVanceD system settings
When the Show Advanced Settings option is enabled, additional options and categories are displayed.
SECURITY
Remote Control - This enables remote control and firmware update functionality. This option may be changed in the
System console only, and is View Only in the Web Interface.
Remote Diagnostics - When activated, this option allows for remote diagnostics capability. The default setting is Off.
Web Server Port - This controls the port that the UI web server uses when remote control is enabled. The default
setting is TCP 80.
AUXILIARY SERIAL
Baud Rate - Allows for controlling the Baud Rate of the serial port. Default is set to 9600.
Data Bits - Allows for the configuration of number of data bits. Default is set to 8.
Stop Bits - Configures the number of stop bits. Default is set to 1.
Flow Control - Allows for selection of the flow control method. Default is set to None with options for HW (RTS/CTS)
and SW (XON/XOFF). This has no functional effect on BRIC-Link.
Parity - Users can select parity protection with this setting. Default is set to None with the additional options for Odd
or Even.
37
