Comrex BRIC-Link Product Manual page 16

DIP swItCh settIngs
BRIC-Link has a set of eight DIP switches used for audio and indicator configuration.
DIP Switch #
1
2
3
4
5
6-7
8
Reset to FaCtoRy DeFauLt usIng DIP swItChes
To factory reset your device using DIP switches, follow these steps:
1 Put DIP switch 8 up.
2 Press the RESET button once, then wait until the Left, Right, and Power LED flash red and
green (can take up to 40 seconds).
3 Put DIP switch 8 down.
4 Press the RESET button once.
16
Pin 1 Output #1
Pin 2 Output #2
Pin 3 Output #3
Pin 4 Output #4
Pin 5 Input #1
Pin 6 Input #2
Pin 7 Input #3
Pin 8 Input #4
Pin 9 Ground
Function
Analog/AES3 Input Select
Analog/AES3 Output Select
Audio Loopback*
Level LEDs TX/RX Select
Headphone out select TX/
RX
Future Use
Factory Reset
Default (Down)
Analog
Analog
Disabled
TX
TX
