USB TO UART DATA COMMUNICATION & REPORT GENERATION SOFTWARE
A) Verify if Windows 7 is installed on Target PC. Nucleonix provides support only for Windows 7.
In case, for whatever reason, it is required to demonstrate the software on Windows XP, install the Service
Pack 3 (if it is not already installed).
1. Double click on "windowsxp-kb936929-sp3-x86-enu._u5Kng" file in "windows xp service pack3" folder.
B) Login with Administrator privileges on your PC.
Insert NucSoft software CD and run NucSoft.bat to start installation. The Batch file automatically installs the
necessary files.
C) NucSoft.bat should have installed NucSoft.xls and NucSoftLogin.xls automatically in C:\.
In case you do not find these files in C:\, Copy NucSoft.xls and NucSoftLogin.xls to c:\
D) NucSoft.bat should have installed USB_Serial Bridge drivers automatically.
In case it is not installed, Install by
1. Double Clicking on driver.exe in BAFOProlific_USBSerialBridge_Driver folder in CD and follow the steps.
E) NucSoft.bat should have installed dotNET framework automatically.
In case it is not installed, Install dotNET framework by
1. Double Clicking on dotNetFx40_Client_x86_x64.exe in dotNETClient folder in CD and follow the steps.
F) NucSoft.bat should have installed Setup.exe for NucSoft automatically.
To verify this, click on Start --> All Program --> Nucleonix Systems. If you do not find NucSoft shortcut, then it
means, NucSoft is not installed. Run NucSoft Setup by double clicking on "Setup.exe" application in Debug
folder.
G) NucSoft should have installed Skype automatically. In case it is not installed,
Run Skype Setup by Double clicking on "Skype Setup" in Skype Setup folder. Internet Connectivity is required.
Skype is required for Remote technical support.
H) In case your PC does not have Windows Live Movie Maker / Windows Media Player, Run Windows Live Movie
maker Setup by Double clicking on "windowsLiveMovieMakersetup-web" in WindowsLiveMoviemakersetup
folder. Internet Connectivity is required.
Windows Live Movie Maker is required to play Movie files (Documentation).
I) Go through the following Videos to understand the working of NucSoft, before running the application. To
locate the Videos, click on Start --> All Programs --> Nucleonix Systems.
1. NucSoft_AboutUs
2. NucSoft_UserManual_SystemRequirements
3. NucSoft_UserManual_MakingConnections
4. NucSoft_UserManual_IdentifyingCOMPOrt
5. NucSoft_UserManual_SoftwareFeatures
J) Connect the micro USB cable to the unit
K) Default Login and password for NucSoft software is 'admin' and 'Nucleonix'.
Note : Data cable should not be connected when the RAD check
CHAPTER – VII
meter is in switch ON condition
Page 15 of 49
