Detector (options)
Calibration Accuracy
Acquisition mode
Dose Rate (mode)
Over Range
Alarms
Preset level
Data Storage
Display Indication
Sensitivity
Serial Port (optional)
User Interface
Power
Dimensions
Weight
Cable Details
Note: Detector probe should not be connected when the RAD check
CHAPTER - IV
SPECIFICATIONS
(a) Nal (Tl) Scintillator, 1"d x1"h coupled to a Photomultiplier
Tube. Detector assembly is inside the survey meter enclosure.
:
(b) External unit through 1mtr cable
(a)
:
(b)
CPS: 0-50000
CPM: 0-5000
:
0.1-10000 µR/hr
10nSv/hr - 100k nSv/hr
:
This instrument will show over range above the 10,000 µR/hr
:
Provision for audio/visual alarms of dose rate exceeds preset level
:
User selectable in modes
:
Can store up to 1000 data readings. Stored data can be recalled
back on to display.
:
Dot Matrix LCD display for dose rate / cum dose.
:
1 micro-R/hr or 0.01µSv/hr
:
Built-in serial port facilitates data down loading into PC. Data
Communication Software with connecting cable can be provided
:
at extra cost as an additional option.
Power ON/OFF, START, STOP, PROG, REC, INC, DEC command
buttons for setting of parameters & operation of the instrument.
:
6 volts DC, BPL Excel or DURACELL ULTRA, Size AA, MN1500
LR6 (4 X 1.5 Volts), Alkaline cells.
:
106W x 196L x 105Ht in mm (Approx.)
:
1. External unit (without probe) : 1.5kg
2. External probe (1"x1" NaI) : 2.1kg
:
3. External unit with probe : 3.6kg
5 Pin I/O
:
meter is in switch ON condition
Better than +/-10% (specified with a Cs-137
Standard source) from 100 mR/hr onwards
with in +/-20% up to 200 mR/hr
