Alba Corner Base Unit & Top Shelf
L4472
Assembly Difficulty
two-person job
easy
- medium
- hard
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.flatpackconstruction.co.uk.
A few important pointers before you start:
•
Please read the instructions right through before you start, and check
that all the components have been included in the pack; we find
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required,
but screw drivers and other tools are not. You'll find details of the tools
you need at the beginning of the instructions.
•
Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
V1
13/06/2019
1
Advertisement
Related Manuals for Great Little Trading Alba L4472
Summary of Contents for Great Little Trading Alba L4472
- Page 1 Thank you for shopping with GLTC, we hope you enjoy having this product in your home. We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling this item as quick and painless as possible. Hopefully our efforts will have been worthwhile and you’ll sail Alba Corner Base Unit &...
-
Page 2: Safety Warnings
Safety Warnings: Customer Service: Please read these instructions carefully before assembly. • If you find that any components are missing or damaged, please do not begin assembly and do not use the item. Please contact GLTC • During assembly children should be kept away from the product due Customer Services on 0344 848 6000 immediately. -
Page 3: Component Checklist
Component Check List Component Check List 1x Top Shelf - LH Base Panel 1x Top Shelf - RH Base Panel 1x Base Unit - LH Top Panel 1x Base Unit - RH Top Panel 1x Top Shelf - LH Side Panel 1x Top Shelf - RH Side Panel 1x Base Unit - LH Base Panel 1x Base Unit - RH Base Panel... - Page 4 Component Check List 23x Cam Dowels 30x Wooden Dowels 35mmL 25mmL 24x Domed Head Screws 35x Cam Locks 14mmL 15mmL dia 6x Double Ended Cam Dowels 1x Anti-tip kit You will need (not supplied) Philips Head Screwdriver...
- Page 5 Hardware for Step 1: Hardware for Step 2: 2x #2 Wooden Dowels 7x #1 Cam Dowels 4x #3 Cam Locks 2x #5 Double Ended Cam Dowels Using Cam Locks: When inserting into the panel, ensure that each cam lock’s arrow is pointing towards the drill hole on the side edge of the panel &...
- Page 6 STEP 3: Create the upstand. Take panel F and connect to panel E. Insert 1x cam lock into Hardware for Step 3: the large hole by the connection and turn clockwise to lock. Ensure the large drill holes on both panels 1x #3 cam lock are facing outwards as shown.
- Page 7 STEP 7: The top shelf is now ready for use. STEP 6: Insert 2x wooden dowels (#2) into the innermost Hardware for Step 5: holes on the edges of panels A & B. These will insert into the larger holes on panels C & D. 4x #2 Wooden Dowels Attach the side panels and secure using 3x cam locks (#3) on BOTH sides.
- Page 8 Hardware for Step 8: 4x #2 Wooden Dowels STEP 9: STEP 8: Carefully turn joined panels K & L over, 8x #3 Cam Locks Repeat Step 1 to join the corner panels to show the small set of drill holes in the Hardware for Step 9: together.
- Page 9 Hardware for Step 11: 8x #2 Wooden Dowels 2x #3 Cam Locks BASE STEP 11: Take the K/L base panel and insert 4x wooden dowels into the remaining holes in the corner. Position back support panel N first, it needs to be flat on the floor. The large drill holes on the panel to be It is important that these facing the floor and the small pilot...
- Page 10 BASE STEP 12: STEP 13: Take side panel H and insert 4x wooden dowels in the remaining drill holes. Keeping the unit in the same position, repeat step Hardware for Step 12: Hardware for Step 13: 12 with panel G. Line up the grooved edge on panel H with the grooved edges of the corner panels and push on to This time, ensure the grooved edge is facing the...
- Page 11 24x #4 Domed Head Secure with 12x domed head screws (#4). Screws 1x #6 Anti-Tip Kit Copyright© 2019 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
