Alba Regular - Divider Unit, White
L4465
Assembly Difficulty
one-person job
easy
- medium - hard
Thank you for shopping with GLTC, we hope you enjoy
having this product in your home.
We know assembling furniture, toys or accessories is not everyone's
favourite way to spend their time, so we've tried to make assembling
this item as quick and painless as possible.
Hopefully our efforts will have been worthwhile and you'll sail
through the whole process. But if it all feels a bit too much
like hard work, then we do have an assembly company we
can recommend: the Flatpack Construction Company offers a
nationwide service and can be contacted on 0843 289 4951 or
www.flatpackconstruction.co.uk.
A few important pointers before you start:
•
Please read the instructions right through before you start, and check
that all the components have been included in the pack; we find
separating all the hardware into piles makes it easier to be sure that
everything is present and correct.
•
Make sure you have the right tools. Allen keys are provided if required,
but screw drivers and other tools are not. You'll find details of the tools
you need at the beginning of the instructions.
•
Do not throw away any packing materials until assembly is complete,
just in case you accidentally discard smaller parts or hardware.
V1
29/05/2019
1
Advertisement
Table of Contents
Related Manuals for Great Little Trading Alba L4465
Summary of Contents for Great Little Trading Alba L4465
- Page 1 Thank you for shopping with GLTC, we hope you enjoy having this product in your home. We know assembling furniture, toys or accessories is not everyone’s favourite way to spend their time, so we’ve tried to make assembling this item as quick and painless as possible. Hopefully our efforts will have been worthwhile and you’ll sail Alba Regular - Divider Unit, White through the whole process.
- Page 2 Safety Warnings: • Check all fixtures and fittings regularly and tighten as necessary. Please read these instructions carefully before assembly. • Warning! Not suitable for children under 3 years due to small parts • Remove all packaging before allowing your child to use the product. which may become detached and present a choking hazard.
- Page 3 Component Check List Component Check List 8x Cam Dowels 12x Wooden Dowels 35mmL 25mmL 1x RH Side panel 1x LH Side Panel 8x Cam Locks 14x Domed Head Screw 15mmL dia 14mmL 1x Base Panel 1x Top Panel You will need (not supplied) 8x Shelf Supports Philips Head Screwdriver...
- Page 4 STEP 2: Hardware for Step 1: Take top panel C and insert 2x wooden dowels (#2) in the central holes as shown. This panel should be positioned with the drill holes facing towards the 8x #1 Cam Dowels panel you are connecting it to and the grooved edge on the floor. Connect panel E with panel C.
- Page 5 STEP 3: Hardware for Step 4: Take panel A and insert 4x wooden dowels (#2) into the holes at the edges of the panel as shown. Position with the grooved edge on the floor and the protruding end pointing in the same direction as the large drill holes on the 4x #2 Wooden Dowels underside of panels C &...
- Page 6 STEP 6: Hardware for Step 5: Stand the unit upright and insert the 4x shelf supports (#5) in EACH side of the unit at the desired shelf level. 14x #4 Domed Head Screws Insert the shelves (panel G). STEP 5: Hardware for Step 6: Carefully turn unit over, please do this with a second person if necessary.
- Page 7 This unit should NOT be used on it’s own, it must be used with an appropriate Alba REGULAR base unit. Copyright© 2019 G.L.T.C. Ltd. All rights reserved. Great Little Trading Company and GLTC are registered trade marks of G.L.T.C. Limited.
