CHAPTER 1. INTRODUCTION

1.2 VNE compressor series description

Product descripton
1.
1-
Fence cover
2-
OLP
3-
3/4 OLP
4-
Cord anchorage
5-
Screw
6-
Grommets
7-
Compressor shell
8-
Process tube
9-
Discharge tube
10-
Suction tube
2
1
! !
WARNING
! ! ! !
CAUTION
NOTICE
3
4
• Before you begin your installation observe
technical specifications and proper connec-
tions.
• Check if product is properly identified and if
it's enclosure is without cracks.
7
8
6
5
3
9
10
