CHAPTER 2. TECHNICAL SPECIFICATIONS
to improve understanding. The manufacturer part number of each connector can
be found in the following table.
7
1
3
4
Indicator
1
2
3
4
5
6
7
*Mates with 1/4" faston receptacle. Fan connector assemble is optional.
Figure 2.2: Connectors
Connectors part numbers
Description
Serial
Communication
Frequency input
Drop in
AC input (L+N)
AC Fan*
Additional Drop
in (optional)
Safety Earth
Part number
S3P-VH (LF)
(SN)
S2P-VH (LF)
(SN)
1217754-1
1217754-1
MSLO 9402 -
002 - 00A - 960
- 000 - 00
1217754-1
63849-1
12
5
2
6
Insulation
Reinforced
Reinforced
Functional
Functional
–
Functional
Basic
