ChlorSync Model Cell Options
®
The ChlorSync system consists of the following components.
Part #ECP0312 Power Center- Provides power and controls communication between the power center
l
and the cell.
Three different cell options to choose from - CS30, CS40, CS50.
l
The chlorine output for each of the ChlorSync
pump run time and a salt concentration of 3,500 ppm (mg/L), is listed in the table below.
Model
®
ChlorSync
CS30
®
ChlorSync
CS40
®
ChlorSync
CS50

Power Center

WARNING - Failure to heed the following may result in permanent injury or death.
RISK OF ELECTRICAL SHOCK - All electrical connections should be made by a licensed electrician or
l
certified electrical contractor.
RISK OF ELECTRICAL SHOCK - Disconnect all AC power when installing or servicing this system.
l
Follow all state, local, and National Electrical Code(s) (provincial and Canadian Electrical Code(s) if
applicable). Use copper conductors only.
RISK OF ELECTRICAL SHOCK - Before plugging or unplugging the ChlorSync
l
first switch off the AC power to the power center.
Chlorine output lbs. (kg) per 24 hours
1.1 lbs. (0.50 kg)
1.4 lbs. (0.64 kg)
1.7 lbs. (0.77 kg)
ChlorSync
®
models, which is based on a 24 hour chlorinator/
®
Power Center
Figure 1
®
to the power center,
Page - 5
