POOL PILOT
TROUBLESHOOTING AND TECHNICAL CHEAT SHEET
1. Output Lights will pulsate to indicate Chlorine production.
a. There are 7 lights to indicate output level.
b. Chlorine Production is based upon an on/off period of a 30-minute cycle.
c. If lights are solid Green this means unit is in rest mode.
d. To increase percentage of chlorine production, press UP ARROW
e. To decrease percentage of chlorine production, press DOWN ARROW
(The lights will display between 1 light up to 7 lights to reflect output level)
2. Flow Light will be Green
a. If Flow light is not on see troubleshooting section.
3. Salt Light will be Green (OK) – unit will produce chlorine
4. If Salt light is Yellow (LOW) add salt until Green Salt light comes on or check with Salt
addition chart for proper amount
5. If Salt light is Red (ADD) ---unit will engage safety cell shut off. Unit will automatically
resume operation when salt is added back to sufficient levels.
6. Pushing the BOOST BUTTON will increase chlorine production to 100% for 24 hours of
accumulative pump run time. The GREEN BOOST LIGHT will stay Solid Green
a. Holding the Boost Button down from Boost OFF mode for 8 seconds will increase the
Boost Cycle to 72 hours of accumulative pump run time. The Green Boost light will
flash
b. After Boost Cycle is complete the unit automatically reverts to the original Setting
c. Depress the Boost button in either Boost mode to deactivate Boost mode.
.
1/17/03
SOFT TOUCH
NORMAL OPERATING MODE OF SOFT TOUCH
i. The Yellow Salt light comes on at 2500 ppm and unit will still produce chlorine.
i. The Red Salt light comes on below 2000 ppm of salt.
OPERATING,
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Autopilot POOL PILOT SOFT TOUCH
Summary of Contents for Autopilot POOL PILOT SOFT TOUCH
- Page 1 POOL PILOT SOFT TOUCH OPERATING, TROUBLESHOOTING AND TECHNICAL CHEAT SHEET NORMAL OPERATING MODE OF SOFT TOUCH 1. Output Lights will pulsate to indicate Chlorine production. a. There are 7 lights to indicate output level. b. Chlorine Production is based upon an on/off period of a 30-minute cycle. c.
- Page 2 SOFT TOUCH TROUBLESHOOTING **If the service light comes on, count the number of flashes and see below 1 RED FLASH = LOW FLOW OR NO FLOW The flow light will go out and the Service light will flash once o Verify the that the filter is clean ? ? If filter is dirty, clean the filter to increase the overall flow.
- Page 3 SOFT TOUCH TROUBLESHOOTING CONT’D **If the service light comes on, count the number of flashes and see below. 3 RED FLASHES – very low amps with Salt OK o V1.4 or older - scaled cell or failed cell o Power Supply may have failed or improperly wired. ? ? Check the Power Supply for Output.
- Page 4 SOFT TOUCH TECHNICAL SPECIFICATIONS MAXIMUM CELL CURRENT (DC AMPS) SOFT REVERSAL Cell Power 1 = 5 AMPS Chlorine Production Stops 30 seconds before Cell Power 2 = 6.5 AMPS reversing polarity. Cell Power 3 = 8 AMPS WARNING: Operating on level “1” reduces cell power but extends cell life, operating on level “3” increases cell power but shortens cell life REVERSAL TIME BOOST CYCLES...
- Page 5 DIAGRAM “4A” TRI-SENSOR CABLE / WIRING DIAGRAM 1 Flow FLOW WHITE BROWN 3 Salt SALT GREEN BLACK 5 Temp BLUE TEMP. TRI-SENSOR CABLE PLUG (FEMALE CONNECTIONS) FLOW DETECTOR TEMP SENSOR SALT SENSOR TRI-SENSOR ASSEMBLY HEAD PLUG (MALE CONNECTIONS) NOTE (Perform these tests on the Tri-Sensor Assembly): - Test for continuity of the FLOW pins by attaching a continuity meter test leads to pins #1 &...
- Page 6 1/17/03...
