Technical Features; Maintenance - Controlli MVE2 Series Manual

Globe valves actuators
Table of Contents

Advertisement

TECHNICAL FEATURES

Supply voltage F N
Power consumption (running)
13 VA / 6 W
Power consumption (Holding)
11 VA / 5 W
Running time
Modulating 5-15 mm
Modulating 15-25mm
Modulating 25-60 mm
Increase/decrease (s)
Stroke (mm)
Force (N)
Duty cycle
Voltage 0-10 V - impedance > 100 KΩ (range:
Analog input Y M
Digital inputs Y1-Y2
Output V+
Output U
Ambient temperature
Ambient Humidity
Protection degree
Emission/Immunity EMC 2004/108/CE according
Standard
Material
Color
Weight (Kg)
Dimensions (mm)
ASSEMBLING
The actuator can be mounted with any orientation but never
up-side down. When the fluid temperature exceed 120°C the
actuator shall be mounted leaning 45°.
To mount the actuator on to a valve, position the valve stem to
the bottom of its travel, slide the actuator onto the valve neck,
adjusting with the manual override the screw jack position so
the square nut on the valve spindle fits into the groove on the
cross bar. Then slide the brace into the groove on the valve
neck and secure the nuts.
1
st
Issue
ISO 9001
MVE206/S
MVE210/S
MVE215/S
230Vac ±10%, 50-60Hz
18 VA / 8W
21 VA / 11W
11 VA / 5 W
13 VA/7W
15 (s)
20 (s)
30 (s)
60
5-60 mm
600
1000
max 50%/60 minutes
0-10/2/10 0-5/2-6 5-10/6-10)
500 Ω (range 4-20mA)
Connection of Y1, Y2 to M
Voltage 16 Vdc ± 0,5 V
Max Load 25 mA,
Voltage 2-10 Vdc (0-100%)
Max Load 2 mA
Operation and storage -10 / +50 °C
max 90% RH
IP54
to EN 61326-1:2006 standard
LVD 2006/95/CE according to EN61010-1
standard
Housing: Aluminum - Cover: ABS plastic
Aluminum / White
1.5 kg
Refer to the picture on the page 6
11/12
1500
See mounting instructions for full details (MVE2xx_DIM205).

MAINTENANCE

The actuator is free of maintenance. For further information re-
lating to the use of the actuator, please contact our Technical
Dept.
ACCESSORIES
DMVE
Endpoint Auxiliary Switches
248
Yoke Heater (Suggested when the fluid temperature
is below 0°C)
Linkage
Current Controlli valves
(except for 2TGB.F/3TGB.F PN16)
2TGB.F/3TGB.F PN16
Controlli valves with threaded M40
connections
(except for VMB/VSB/VSBF/VMBF PN16)
VMB/VSB/ VSBF/VMBF PN16
Other manufacturers
Landis *
Danfoss (VR/VF (S) models)
TAC DN15-V298
TAC DN15-V2XX/V3XX
Honeywell**
Airtek
Johnson Controls code VB7816-2111
Johnson Controls code BM-3018-3300
Tac Venta
(/) this model can not be assembled
(*) valid for following models: VVF31... DN 25–80/VVF45... DN 50/VVG41... DN
15-50/VXG41... DN 15-50/VVF51... DN 15-40/VVF52... DN 15-40/VXF31... DN
25–80/VXF61... DN 15–50/VVF61... DN 15–50/VXG11... DN 25–40/VVG11...
DN 25–40/VFG34... DN 25–40
(**) valid for the followign models: M6: V176A. B, V538C
1/4": V5011A
2
MVE
MVES
(not required)
/
/
(not required)
AG51
/
AG52
AG63
AG 60-03
/
AG60-07
/
AG 60-08
/
AG 60-09
/
AG 60-10
/
AG 60-11/AG60-
/
12
AG 66
/
AG 67
/
(not required)
/
DBL394e
