Electrical installation/assembly
Pin assignment
Pin
Assignment
1
9-36 V DC Supply voltage
2
CAN H (SAE J1939)
3
GND power supply
4
CAN L (SAE J1939)
5
HSI (HYDAC Sensor Interface)
There is contact between the plug housing and the housing.
ContaminationSensor CS 1939
BeWa CS1939 3978342c V100 en-us 2019-10-08.docx
Assembly, installation and commissioning
en
Page 30 / 48
2019-10-08
