Hydraulic connection of the ContaminationSensor
Observe the following sequence when connecting the sensor to the hydraulic
system:
1.
Connect the return line to the OUTLET of the CS. G1/4 ISO 228
threaded connection, recommended diameter of line ≥ 4 mm.
2.
Then connect the other end of the return line to the system tank, for
example.
3.
Check the pressure at the measurement location. Note the maximum
operating pressure.
4.
Connect the measurement line to the INLET port of the CS.
Connector threads G1/4 ISO 228. We recommend an internal Ø ≤
4mm for the line in order to prevent particle deposits (sedimentation).
systems, install a protective screen upstream from the
ContaminationSensor. (e.g. CM-S)
5.
Connect the other end of the measurement line to the measurement
point on the hydraulic system.
connected with the pressure line.
6.
The hydraulic connection is complete.
ContaminationSensor CS 1939
BeWa CS1939 3978342c V100 en-us 2019-10-08.docx
If particles ≥ 400 µm are anticipated in the hydraulic
Oil begins to flow as soon as the ContaminationSensor is
en
Assembly, installation and commissioning
Page 29 / 48
2019-10-08
