Campbell AirLink RV50 Quick Deploy Manual

Part Number 31887
Revision: 12/2018
1. Introduction
NOTE:
This Quick Deploy Guide is a general reference to give the
installer an overview of the steps required to make this sys-
tem operational. The Product Manual is the definitive
source for detailed installation instructions and inform-
ation.
A public static IP account must be used when the module is set
up in serial server mode. Private dynamic IP accounts do not
support the serial server mode.
The Provisioning Report received with your Cellular Data Ser-
vice shows whether the module was configured with a private
dynamic or public static IP address.
USE THIS GUIDE if you have a public static IP address. See
FIGURE 1-1 (p. 1). See the RV50 Manual if you have a private
dynamic IP address.
www.campbellsci.com/rv50
FIGURE 1-1. Static IP provisioning report
2. Campbell Scientific cellular data
service
Campbell Scientific can provide subscriptions to cellular ser-
vice through Verizon, AT&T, T-Mobile, Vodafone, Telstra, and
over 600 other providers worldwide. When this cellular service
is purchased with the module, the module will come pre-pro-
visioned with the required SIM card and APN. If you have
already purchased the RV50, call Campbell Scientific to set up
service.
3. Install the SIM card
NOTE:
If you purchased cellular service from Campbell Scientific
with the module, it will come with the SIM (Subscriber Iden-
tity Module) card already installed.
1. Remove the SIM card cover.
2. Note the location of the notched corner for correct
alignment. The gold contact points of the SIM face
down when inserting the SIM card as shown in
3-1 (p. 2). Gently slide the card into the slot until it stops
and locks into place. To eject the SIM card, press it in
slightly and release.
3. Replace the SIM card cover.
FIGURE
