Campbell RV50 Quick Deploy Manual

Part Number #35781
Revision: 04/2021
1. Introduction
NOTE:
This Quick Deploy Guide is a general reference to give the
installer an overview of the steps required to make this
system operational. The Product Manual is the definitive
source for detailed installation instructions and
information.
For best results, update to the latest data logger
operating system and version of Device Configuration
Utility.
You should have received two Quick Deploy Guides with your
RV50(X) module. The one you follow will depend on whether
your module was configured with a private dynamic or public
static IP address.
The Provisioning Report received with your Cellular Data
Service shows whether the module was configured with a
private dynamic or public static IP address. See the following
figure for an example of a Campbell Scientific Provisioning
Report. Other cellular providers should provide similar
information.
USE THIS GUIDE if your module has a public static IP address.
Sierra Wireless Airlink®
4G LTE Cellular Modem
For Public Static IP Addresses
CSL I.D - 1313
www.campbellsci.eu/rv50x
FIGURE 1-1. Static IP provisioning report
Additionally, Campbell Scientific cellular modules configured
with a public static IP address will have two stickers on the
module, as shown in the following figure. One sticker will show
the module phone number and data plan. The second sticker
will show the static IP address. USE THIS GUIDE.
Campbell Scientific cellular modules configured with a private
dynamic IP address will have one sticker on the module. It will
show the module phone number and data plan. USE THE
OTHER GUIDE.
FIGURE 1-2. Module with public static IP address
2. Campbell Scientific cellular data
service
Campbell Scientific can provide subscriptions to cellular
service through Verizon, AT&T, T-Mobile, Vodafone, Telstra,
and over 600 other providers worldwide. When this cellular
service is purchased with the module, the module will come
pre-provisioned with the required SIM card and APN. If you
have already purchased the RV50(X), call Campbell Scientific
to set up service.
1
