WARNING — HIGH PRESSURE — WARNING
INTRODUCTION
The Binks MACH 3SL HYDRAULICALLY-
ASSISTED HVLP SPRAY GUN combines the proven
HVLP efficiency of Binks best-selling MACH 1 gun
with hydraulically-assisted atomization to yield a
reliable, carefully engineered special-purpose spray gun.
The MACH 3SL provides consistent coatings with
difficult materials by "pre-atomizing" pressurized fluid
through a constrictive carbide nozzle. Specially designed
air nozzles further promote material atomization and
ensure consistent, uniform finishes.
The MACH 3SL operates at high transfer efficiencies,
and fully complies with all government regulations for
HVLP "High Volume, Low Pressure" airspray guns.
The MACH 3SL makes use of special features to ensure
this compliance by converting the air inside the gun
from high pressure inlet air to high volume low
pressure atomizing air to create a highly transfer
efficient soft spray."
To gain the optimum performance from your new
MACH 3SL HVLP spray gun, please read all
instructions carefully.
MACH 3SL Hydraulically-
Assisted HVLP Spray Gun
UP TO 6000 POUNDS PER SQUARE INCH
SPECIFICATIONS
Maximum Fluid Pressure
Maximum Air Pressure
Gun Body
Fluid Path
Fluid Shut-off Type
Seat Material
Fluid Inlet Size
Air Inlet Size
Gun Weight
NOTE
IMPORTANT REGULATORY NOTE regarding
the use of this product appears on page 10.
6000 PSI
50 PSI
Forged Aluminum Alloy
Stainless Steel and
Tungsten Carbide parts
Ball and Seat
Tungsten Carbide
1/4 NPS thread
1/4 NPS thread
23 Ounces
Replaces
Part
Part Sheet
Sheet
2666R
2666R-1
Advertisement
Related Manuals for Binks MACH 3SL
Summary of Contents for Binks MACH 3SL
- Page 1 NOTE HVLP “High Volume, Low Pressure” airspray guns. The MACH 3SL makes use of special features to ensure IMPORTANT REGULATORY NOTE regarding the use of this product appears on page 10. this compliance by converting the air inside the gun...
- Page 2 When using this pump with parts that do not comply with the minimum specifications and safety devices of Binks, the user • Use Binks NO-WIRE conductive hose in all airless spraying assumes all risks and liabilities. operations. Be sure the gun and hose have continuity. Check continuity weekly with ohmmeter.
-
Page 3: Troubleshooting
SPRAY GUN SET-UP 1. Connect your high-pressure airless fluid hose to the 8. Turn on the side port control air. Slowly increase gun gun fluid inlet and tighten securely. air pressure until the “tails” disappear and the fluid is 2. Connect your air hose to the gun air connection and well atomized. -
Page 4: Spray Gun Maintenance
SPRAY GUN MAINTENANCE 6. Loosen ferulok nut (40) and slide over fluid tube. CAUTION Remove screw (43) and trigger guard assembly (42) Never use metal instruments to clean or scrape fluid or from gun. Loosen and remove trigger stud (15), trig- air nozzles. - Page 5 Volatile Organic Compounds (VOC) into the containers. atmosphere when cleaning a spray gun. Binks recom- mends that you comply with these new air quality laws Be sure to disassemble and thoroughly clean the filter by following one of the two methods below when assembly each time you clean the spray gun.
- Page 6 MACH 3SL HYDRAULICALLY-ASSISTED HVLP SPRAY GUN...
-
Page 7: Parts List
FLUID NOZZLE BODY ....20-5928 SCREW ..Pan Head, 6-32 x 5/16 Long 54-3543 HEAD INSERT ........ 54-3765 TRIGGER ASSEMBLY ..... 54-3746 MACH 3SL HANDLE ASSEMBLY... FERULOK NUT ......5/16 54-4359 TRIGGER STUD ......FERRULE ........5/16 82-126 TRIGGER SCREW ...... - Page 8 ARTICULATED TRIGGER ADJUSTMENT Material Valve Control Knob (29) 1/16" Clearance Wire and Ball Wire Assembly (11) Upper Link Chuck (27) Spring (28) Wire and Ball Assembly (11) Spindle Chuck Lock (26) Assembly (23) Lower Trigger Figure 5 Refer to assembly drawing on page 6 to locate wire and ball assembly (11), pull the trigger (39) numbered items.
- Page 9 ARTICULATED TRIGGER ADJUSTMENT Figure 6 Figure 7 Gun in closed (untriggered) position Air Valve opens and Upper Link of Trigger remains stationary Figure 9 Figure 8 Fluid Ball unseats (approx. 1/32") Full open air and fluid. Upper Link remains stationary Upper Link moves with Lower Trigger...
- Page 10 Achieving a fine spray finish without the use of a good oil and water extractor is virtually impossible. A Binks regulator/extractor serves a double purpose. It eliminates blistering and spotting by keeping air free of oil and water and it gives precise air pressure control at the gun.
- Page 11 NOTES...
- Page 12 Sales and Service Through a Nationwide Network of Industrial Distributors. Customer Service in USA / 1-800-992-4657 Technical Support in USA / 1-888-992-4657 2666R-1 Revisions: (P7) Changed Item (4) to Part No. 54-3745, changed Item (17) to 54- 4343, added footnote referring to Spare Parts Kit 54-3745-5, added footnote referring to 54-3781 Seal, changed all Part Nos.
