Nesting cart
EB-BASE-C
Elliptical cart
EB-BASE
Elliptical stand
40"
60" - [33/27]*
72" - [36/36]*
84" - [42/42]*
Poles are available in single or pair, black or chrome, full length or cut-in-half length [actual cut lengths]*.
9500434 v1.0
publ. 07/22/20
DUAL POLE CARTS AND STANDS
DUAL POLE CARTS AND STANDS
Lightweight stand
Floor stand (back to back)
POLE LENGTH OPTIONS
Poles and splice collar (PSD-EXT), Sold separately.
TL-BASE
TS-BASE
Floor stand
CS-BASE
Installation Guide
PSD-HDCA
Dual pole adapter
includes with all base
(except CS-BASE)
+
PSD-DPB
Back to back adapter
includes with CS-BASE
PSD-EXT*
