The PCM5122/42 families of ICs are advanced segment, high-performance, software-programmable
stereo digital-to-analog converters (DACs). The PCM512x family employs fixed-function audio processing,
while the PCM514x family employs miniDSP audio processing. These devices employ internal line drivers
together with an internal PLL and BCLK reference, so that a serial clock signal (SCK) can be derived. The
advanced segment architecture enables excellent dynamic performance and an improved tolerance to
clock jitter, and the 2.1-V
The PCM5122/42EVM-U is designed to support the PCM5121, PCM5122, PCM5141 and PCM5142
DACs. The PCM5122/42EVM-U also employs the
asynchronous sample rate converter.
This User's Guide describes the operation of the PCM5122/42EVM-U and the Texas Instruments
CodecControl software. CodecControl provides a graphical user interface for supported TI audio codecs.
The software is compatible with Microsoft
1
2
3
4
5
Bill of Materials
1
2
PCM5122/42EVM-U Block Diagram
3
EVM Software Window
4
Command Dialog
..................................................................................................................
5
PurePath is a trademark of Texas Instruments.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
2
2
I
S, I
C are trademarks of NXP Semiconductors.
All other trademarks are the property of their respective owners.
SLAU444 - May 2012
Submit Documentation Feedback
ground-centered outputs eliminate the need for output dc blocking capacitors.
RMS
Windows
®
..................................................................................................................
........................................................................................................
...................................................................................................
.........................................................................................
.............................................................................................................
........................................................................................................
......................................................................................
...................................................................................................
..........................................................................................................
Copyright © 2012, Texas Instruments Incorporated
PCM5122/42EVM-U
TAS1020B
USB controller and the
XP, Vista, and Windows 7.
®
Contents
List of Figures
User's Guide
SLAU444 - May 2012
SRC4392
2
3
10
15
16
3
4
10
12
15
1
PCM5122/42EVM-U
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments PCM5122/42EVM-U
Summary of Contents for Texas Instruments PCM5122/42EVM-U
-
Page 1: Table Of Contents
USB controller and the SRC4392 asynchronous sample rate converter. This User’s Guide describes the operation of the PCM5122/42EVM-U and the Texas Instruments CodecControl software. CodecControl provides a graphical user interface for supported TI audio codecs. The software is compatible with Microsoft Windows XP, Vista, and Windows 7. -
Page 2: Introduction
CodecControl software is intended to facilitate user evaluation of TI audio codecs. It includes a wide range of features, depending on the specific codec capabilities. The PCM5122/42EVM-U works together with the CodecControl software. It connects to a PC via an available USB port and enumerates as a USB-class audio device. -
Page 3: Pcm5122/42Evm-U
PCM5122/42EVM-U Electrostatic Discharge Warning Many of the components on the PCM5122/42EVM-U are susceptible to damage by electrostatic discharge (ESD). Customers are advised to observe proper ESD handling precautions when unpacking and handling the EVM, including the use of a grounded wrist strap at an approved ESD workstation. - Page 4 PCM5122/42EVM-U www.ti.com The PCM5122/42EVM-U is divided into two sections. The left half contains the digital and USB interface, sample rate conversion, optical/SPDIF and RCA digital inputs, clock circuitry, and reset logic. The right half contains the PCM5122/42 device and the analog circuitry accompanying it. Note that this half of the PCM5122/42EVM-U is the portion required on a potential customer application.
- Page 5 PCM5122/42EVM-U www.ti.com Jumpers, Connectors, Test Points, Switches Table 1 summarizes the connectors, test points, jumpers, and switches on the PCM5122/42EVM-U. Table 1. PCM5122/42EVM-U Headers, Test Points, Jumpers, and Switches Connectors/Switch/Jumper/Test Point Description Headers C/SPI Selection. Shunt pins 1-2 for SPI, 2-3 for I C control mode C/SPI Selection.
- Page 6 SRC ready Clock Circuitry SW3 allows for MCLK selection from multiple sources. The PCM5122/42EVM-U contains an external BNC jack, J6, as well as one programmed oscillator that provides a clock frequency of 24.576 MHz. The TAS1020B also provides a MCLK output; by default, this clock is used as the master clock for the PCM5122/42EVM-U.
- Page 7 There are several use cases where the PCM5122/42EVM-U can be used. Depending on whether it is USB playback, or optical/SPDIF input, for example, there may need to be changes made in the scripts and jumper configuration to accommodate these cases.
- Page 8 # 24bit I2S, Master mode, DIR source, at mute # Divide by 256, MCLK input source w E0 03 69 w E0 04 0B #----- Setup DIR ------# PCM5122/42EVM-U SLAU444 – May 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
- Page 9 # Disable All Function power down (all blocks set by local control) w E0 01 3F NOTE: For characteristic performance graphs, refer to the PCM5122/42 data sheet. SLAU444 – May 2012 PCM5122/42EVM-U Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
-
Page 10: Codeccontrol Software
CodecControl software. This configuration occurs automatically once an EVM is detected by the CodecControl software. Figure 3 illustrates the CodecControl software with the PCM5122/42EVM-U window as an example of the CodecControl software in operation. Figure 3. EVM Software Window PCM5122/42EVM-U SLAU444 –... - Page 11 The CodecControl software executes an initialization script when a supported TI audio codec is detected. To show or edit the initialization script, choose View->Init Script… from the main window menu bar. Click the Run button to run the script again. SLAU444 – May 2012 PCM5122/42EVM-U Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
- Page 12 The one-line text edit field on the left bottom allows single command execution. • The Record check box enables recording of commands generated by the control software. PCM5122/42EVM-U SLAU444 – May 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
- Page 13 <register> is the register that is written to in hexadecimal format. <data…> is a sequence of bytes that are written to the <register> in auto-increment mode. Each byte is in hexadecimal format. SLAU444 – May 2012 PCM5122/42EVM-U Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
- Page 14 D3 = don’t care, D2 = 0, D1 = 1, D0 = don’t care. [optional timeout] specifies how long (milliseconds) the command interpreter polls the device if the data do not match the <mask>. PCM5122/42EVM-U SLAU444 – May 2012 Submit Documentation Feedback Copyright © 2012, Texas Instruments Incorporated...
-
Page 15: Pcm5122/42Evm-U Schematic
PCM5122/42EVM-U Schematic www.ti.com PCM5122/42EVM-U Schematic Figure 5 shows the schematic for the PCM5122/42EVM-U. PCM51XXEVM-U GPIO4 TP11 GPIO5 White White White TP12 White White White TP13 White White White TP14 White White White TP10 TP15 White White White GPIO4/GPIO4/MAST GPIO5/GPIO5/ATT0 MOSI... - Page 16 Bill of Materials www.ti.com Bill of Materials Table 3 lists the bill of materials (BOM). Table 3. PCM5122/42EVM-U Bill of Materials CUST. VALUE DESIGNATORS PKG/CASE T.COEFF/ VOLT DESC. DIST. DIST P/N MFR. MFR. PART # PART PART # RATED 11360...
- Page 17 Bill of Materials www.ti.com Table 3. PCM5122/42EVM-U Bill of Materials (continued) CUST. VALUE DESIGNATORS PKG/CASE T.COEFF/ VOLT DESC. DIST. DIST P/N MFR. MFR. PART # PART PART # RATED 11470 75 Ω R19, R24 0603 1/10W 150 V Resistors Digi-Key...
- Page 18 Bill of Materials www.ti.com Table 3. PCM5122/42EVM-U Bill of Materials (continued) CUST. VALUE DESIGNATORS PKG/CASE T.COEFF/ VOLT DESC. DIST. DIST P/N MFR. MFR. PART # PART PART # RATED 11048 Test Loop TP1, TP2, TP3, 0.040 Test Equipment Heilind 5002...
- Page 19 Any exceptions to this are strictly prohibited and unauthorized by Texas Instruments unless user has obtained appropriate experimental/development licenses from local regulatory authorities, which is responsibility of user including its acceptable authorization.
- Page 20 FCC Interference Statement for Class B EVM devices This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 21 Also, please do not transfer this product, unless you give the same notice above to the transferee. Please note that if you could not follow the instructions above, you will be subject to penalties of Radio Law of Japan. Texas Instruments Japan Limited (address) 24-1, Nishi-Shinjuku 6 chome, Shinjuku-ku, Tokyo, Japan http://www.tij.co.jp...
- Page 22 FDA Class III or similar classification, then you must specifically notify TI of such intent and enter into a separate Assurance and Indemnity Agreement. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2012, Texas Instruments Incorporated...
- Page 23 IMPORTANT NOTICE Texas Instruments Incorporated and its subsidiaries (TI) reserve the right to make corrections, modifications, enhancements, improvements, and other changes to its products and services at any time and to discontinue any product or service without notice. Customers should obtain the latest relevant information before placing orders and should verify that such information is current and complete.
- Page 24 Mouser Electronics Authorized Distributor Click to View Pricing, Inventory, Delivery & Lifecycle Information: Texas Instruments PCM5142EVM-U PCM5122EVM-U...
