Exit JUMPARENA User Manual page 21

STEP 11
Lay the net (16) on the mat (5).
Make sure the enclosure door is
on the middle of 14Ft direction as
shown.
STEP 12
Insert the pole cap (14) into the strap
on the top edge of net (16) as shown.
STEP 13
Starting from the enclosure door,
insert the lower tube (12) into the top
hole of socket.
Make sure the bent sides of the
Upper Tubes (11) are facing
toward the center of the trampo-
line.
Note:
The end of the lower tubes (12)
are sharp. Use caution when as-
sembling.
Now your trampoline and enclosure
are as shown in the picture.
JumpArenA
11
14Ft/427cm
Entrance / Eintritt / Ingang / Entreé
12
14
16
Entrance / Eintritt / Ingang / Entreé
13
12
Leg
12
Trampolines
16
5
Frame Pad
Socket
7
Socket
Anschlussstelle
Aansluiting
Fente
21
