Parts List - Exit JUMPARENA User Manual

Parts list

Part.Nr. Description
1 Middle tube
2 Corner tube (includes two corner tubes 2-A, two corner tubes
2-B)
3 Leg extension
4 Leg
5 Jumpmat
6 Spring (includes 80 Big springs 6-A, 4 small springs 6-B)
7 Pad
8 M6X65mm Bolt
9 M6 washer
10 M6 nut
11 Upper tube
12 Lower tube
13 Sleeve
14 Pole cap
15 End cap
16 Net
17 M4.8X16mm screw
18 Cord
19 Ladder
20 Shoe bag
