WiFi-RDM01 is the RDM master control, which browsing
and setting corresponding parameters of the equipment
with RDM protocol through the RDM standard protocol.
WiFi-RDM01 uses the WiFi module, which can wireless
control by the phone's APP and support to upgrade the
firmware remotely. which is convenient for customers'
using the most functional and latest firmware version.
WiFi-RDM01 can be compatible with other brand's
product with RDM protocol, and it does not affect the
normal operation of other products when hangs on
the bus.
Points: support parameters setting and
firmware upgrade by App.
Address programmable
Convenience testing
Advertisement
Table of Contents
Related Manuals for Ltech WiFi-RDM Series
Summary of Contents for Ltech WiFi-RDM Series
- Page 1 Product features Fast searching Address programmable Long-range maintenance Convenience testing Firmware upgrade WiFi-RDM01 is the RDM master control, which browsing and setting corresponding parameters of the equipment with RDM protocol through the RDM standard protocol. WiFi-RDM01 uses the WiFi module, which can wireless control by the phone's APP and support to upgrade the firmware remotely.
-
Page 2: Package Content
Package content Product parameters Model: WiFi-RDM01 Name: LED controller Input voltage: 5~24Vdc Output signal: DMX512 / RDM LED controller 1pcs Wireless type: 2.4GHz Wi-Fi , 802.11b/g/n -30°C~55°C Working temp.: Warranty: 5 years Product size: 125×33×20mm(L×W×H) Power conversion line 1pcs Packing size: 127×35×24mm(L×W×H) Weight(G.W.): 110g... -
Page 3: Product Structure
Product structure Product installation DC+ DC- socket DC socket (5~24Vdc) (φ5.5mm×φ2.5mm) (5~24Vdc) Power conversion line Setting button WiFi-RDM01 Power light Communication light Power bank Lamp Lamp Lamp DMX/RDM Connect resistance on the terminal. signal output The unit can connect with multiple RDM function decoders. Power light: red light is on (power is normal). - Page 4 Connect & match Search & add device Scan QR code to download the APP via mobile phone. After setting, click " + " in the upper right corner, “Search” and “Add” button will pop-up. iOS / Android Connect the device as follow, then power on it, make sure the communication light is off.
- Page 5 4. Devices 5. Parameters editing interface Setting the frequency, bit, curve, modes, dimming range, The device can be edited after searching successfully. screen saver, etc, in parameter interface. a: Click”Add”, edited the address in corresponding box. (for different model, the parameter is different, b: Click”ID”, get more product details.
-
Page 6: Address Setting
7. Testing and device upgrade 6. Address setting Click “Test” in “More” interface, enter “Test”interface, Click the “ ”on the top left of home page, enter testing the lamp types and single channel. Click “More” interface, and click “DMX address” to set the “upgrade”, enter “upgrade”... - Page 7 5. Ensure all wire connections and polarities are correct before applying power to avoid any damages to the LED lights. www.ltech-led.com 6. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
