General Notes - Graf Optimax Pro Installation And Maintenance Instructions

1.1 Safety
When working on the installation, the appropriate accident prevention regulations must be
followed. For safety reasons, especially when installing a tank, it is important that a second
person is present.
Furthermore, when carrying out assembly and installation work, inspection, maintenance and
repairs, all work regulations and norms must be followed. You will find the advice in the ap-
propriate sections of these instructions.
The installation of the system and/or single equipment parts must be carried out by a li-
censed installer.
The complete system must always be out of operation and guarded against unauthorised
use when carrying out work on the plant or parts of the system.
The tank cover must always remain closed except when working in the tank, otherwise there
exists a very high danger of accidents. The seating and condition of the cover must be
checked on a regular basis.
The GRAF Company offers an extensive range of accessories that are all compatible with
one another and may be used to construct a complete system. The use of other manufactur-
ers' accessories can impair the function of the system and liability for any resulting damages
will no longer be covered under the guarantee.
1.2 Labelling/Tagging obligation
All pipe work and outlets of the water systems are to be labelled with the words "Rainwater
or Non Potable in accordance with AS/NZ 3500.1." either in words or graphically, so that
after years of use, an accidental connection to the drinking water system is prevented. Even
when correctly labelled it may possibly be mistaken, for example by children. For this reason,
all the outlets of the systems process water must be fitted with vandal proof tapware.
2. Installation requirements & performance specifications
Optimax – External Filter pedestrian area
2.1
The Filter with the green telescopic attachment and cover may only be installed in garden
-
areas that are not traversed by traffic.
The amount of short-term load of the polyethylene cover is max. 150 kg, the long-term
-
area load max. 50 kg
Lockable child proof cover
-
Variable installation depth 570mm to 1050mm.
-
The Optimax Pro Filter is suitable for roof areas up to 350m² with DN100 connections
and 750sqm with DN150.
Filter insert mesh width .35mm
-
Provides over 95% water yield
-
Minimal height offset (200mm) between inlet and outlet
-
2.2 Installation and removal (lift out handle)
To facilitate removal of the filter unit in cases of deep installation,
The removal – lift out handle (supplied) should be attached to the filter
by using the screws of the upper connecting rod. See picture.
