10.5 Optical data
Laser
Wavelength
Pulse frequency
Duty cycle
Average power
Laser class
Beam diameter
FLDK110x1003/Sxx
at emission point
40 mm beneath sensor
FLDK110x1005/Sxx
FLDK110x1006/Sxx
at emission point
100 mm beneath sensor
Focus position
FLDK110x1003/Sxx
FLDK110x1005/Sxx
FLDK110x1006/Sxx
Optical receiver
Manual SCATEC-2
Version 2011-05
10.6 Application data
Measuring range
FLDK110x1003/Sxx
FLDK110x1005/Sxx
FLDK110x1006/Sxx
Mounting height
FLDK110x1003/Sxx
FLDK110x1005/Sxx
FLDK110x1005/Sxx
Object speed
Minimum object spacing
Counting rate
Product orientation
Output pulse length
Dead time
Pulse issue time
FLDK110x1003/Sxx
FLDK110x1005/Sxx
FLDK110x1006/Sxx
Manual SCATEC-2
Version 2011-05
650nm - 680 nm (visible red)
50 kHz
50%
< 0.5 mW
2 (to IEC 60825-1 / 2007)
about 2.5 mm
Line focus, 2 mm long, perpendicular to the Scatec housing
about 2.5 x 4 mm
Line focus, 3 mm long, perpendicular to the Scatec housing
40 mm beneath sensor
100 mm beneath sensor
equipped with NIR suppression filter and
daylight suppression filter
27
www.baumer.com
0 to 60 mm beneath sensor
0 to 120 mm beneath sensor
40 mm above conveyor
100 mm above conveyor
2 m/s maximum (5 m/s maximum for thicker edges)
10 mm @ v = 1 m/s and output pulse length 10 ms, or
proportional to the speed and output pulse length
600,000 maximum copies/h
Fold facing laser beam
5, 10, (15, 20) ms selected by DIP switch
0 ms with inactive false pulse suppression, otherwise 18%
of the average product spacing time
at the end of the edge
at the beginning of the edge
depending on the selected running direction
28
www.baumer.com
