Programming 5-Tone non-selective transmissions with PTT ID (Unmuted System)

This procedure enables you to send your radio's ID when pressing PTT. The receive radio(s) will receive your
transmission and your ID will appear on its display. Radios will hear all other traffic also
The following instructions assume that frequencies, tones, and squelch are set and the radios are in PMR mode
(found in the Menu bar under Model). Additionally, the Auto Reset Timer must be enabled (Memory CH) and a
value entered (Common -> Common). These instructions apply to all Icom radios with PMR capability.
TX Radio:
Memory Ch
Field
CH Mute
Switch Action » Call
Log-In/Off
5Tone Signaling » Form
5Tone Signaling » ID
TX Code CH (under 5 Tone):
Field
Line 28
© June 2011 Icom America
Setting / Description
Mute options depend on radio model:
Cont (not muted)
Or (not muted)
Set to Audible
Set to activate PTT ID by pressing (log in) or releasing (log
off) the PTT key
Set to EIA
Set to 28. Points to 28th line in the TX Code CH window:
target Radio's 5 Tone code. You can use any line, but
setting to line 28 allows you to use lines 1-27 for other call
features.
Setting / Description
Enter this radio's ID.
This ID will always be a 5-digit number ending in the same
number for all the radios in the system. This allows all
radios to recognize each radio's PTT ID (see RX Code CH).
